PREMIER TECH REWATEC PHT-390 Owner's Manual And Installation Manual page 5

Tank model
PHT-390
PHT-660
Note: Use only non-corrosive materials.
Step 2b – Bedding preparation and tank placing
• Level and compact the material used for the base.
• Handle the holding tank using the rope on the top.
•
Put the holding tank in place.
•
Make sure to put the inlet and outlet in the right place.
Step 3 – Connecting the holding tank
• Hook up the plumbing connections at the inlet of the holding tank.
• All holding tanks must be ventilated using a pipe at least 100 mm (4") in
diameter or one that is connected to the dwelling's ventilation pipe.
Step 4 – Initial backfill
• Backfill up to the shoulder of the holding tank.
• Note that the backfill material must be deposited and not dumped. As
such, a bulldozer should not be used.
• The backfill material must not contain any organic matter or impervious soil,
stones, debris or particles larger than 20 mm (¾") or any object that could
damage the holding tank.
Note: It is essential to backfill evenly each side of the holding tank.
Step 5 – Extra riser installation
Proceed as follows to install an extra riser:
• Clean the rim of the holding tank access (where the 4 holes are located for
the lag screws).
• Place the rubber seal on the access rim.
•
Put the riser in place, aligning the holes in the base of the riser with the
cavities of the riser preassembled on the tank.
•
Tighten the riser in place using the 4 lag screws and washers provided for
this purpose.
Step 6 – Final backfill
• Before the final backfill, it is strongly recommended that the holding tank
and access be insulated to prevent freezing. Insulating panels should be
used for this purpose.
• Backfill up to the desired level.
•
The thickness of the backfill over the holding tank must not exceed 90 cm
(36").
• The PSR-060 riser is provided and must be used.
• Secure the lid onto the holding tank or onto the riser using the supplied
lag screws.
Installation guide and Owner's manual
Holding tanks
Table showing the load of the holding tank's anchoring system
Resistance/Strap
1,000 kg
1,000 kg
90 cm (36") max.
Page 4/6
Total weight of concrete
3,400 kg
5,700 kg
Rope for handling
Shoulder of the
tank holding
Riser PSR-060 150 mm (6")
or PSR-140 355mm (14'')
Rubber seal
4 X 304 stainless steel lag screws
and 4 washers
Item # 324310
20200615
