Quoizel Q1770F Assembly Instruction Sheet

6 CORPORATE PARKWAY
, .
GOOSE CREEK SC 29445
. .
www quoizel com
Quoizel, Inc.
6 Corporate Parkway
Goose Creek, SC 29445
Customer Service
Phone 631.273.2700
Fax 631.231.7102
www.quoizel.com

Warnings and Cautions

Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing the fixture. We strongly
recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool before removal. Do not subject
glass parts to any shock while in operation or shattering July result.

Package Contents

Loop
A
x 1
Shade
B
x 1
-
STEP 1 Install Rods, Center Column
and Socket Assembly
A. Thread the Socket Assembly (C), the
Center Column (D), the Rod with
Connector (E), the Rod (F) and the Base
(G) together as shown. Hand tighten until
snug.
B. Pull the cord from the Base (G) as you
assemble the parts together to remove
the excess cord between parts.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
2015 QuoizelInc.
Assembly Instruction Sheet #IS-Q1770F
For Styles Q1770F,Q1771FPN,Q1772FB
Please go to www.quoizel.com
Tools Required: Flathead screwdriver, Phillips screwdriver, pliers, wire cutters, wire strippers, electrical tape,
safety glasses.
Light Source: (3) A19 Medium Base 60W Bulb Maximum, Alternate bulb (3) 13W CFL
Estimated Assembly Time: 30-45 minutes
Preparation: Identify and inspect all parts before beginning installation. Check package content list and diagrams
below to be sure all parts are present. If any parts are missing or damaged, do not attempt to assemble, install, or
operate the fixture. Contact customer service for replacement parts.
C
Rod with
Connector E
x 1
D
Rod
F
x 1
Base
G
x 1
E
F
Figure 1
G
Thank you for purchasing a Quoizel product.
or visit us on-line at www.quoizel.com
for product cleaning tips. Go to the
-
STEP 2 Install Shade
A. Attach the Shade (B) over the nipple
on the top center of the Socket
Assembly (C) and secure with the
Socket
Loop(A). Hand tighten until snug.
Assembly
x 3
Center
Column
-
STEP 3 Install Bulb
x 1
A. This fixture uses standard bulb with
medium base . Maximum 60 watts.
B. Insert bulb and screw snugly into
place.
Your fixture is now assembled and
ready to use. Enjoy!
C
D
Cord
1of2
Care + Maintenance selection.
Figure 3
A
B
C
Figure 2
Bulb
July2015
