Summary of Contents for RhinoVac RH20LW
- Page 1 U S E R G U I D E RH20LW Shop Vacuum...
-
Page 2: Table Of Contents
RH20LW User Guide Table of contents: 1- Machine Components ..........3 2- Before Assembly and Starting Operation ....4 3- Technical Data ............5 4- Overview of Nozzles ...........5 5- Assembly ..............6 6- Wet Vacuum Cleaning ..........7 7- Dry Vacuum Cleaning..........8 8- Blowing ...............9 9- Maintenance Cleaning ..........9... -
Page 3: 1- Machine Components
16- Paper dust bag 3- Top section 10- Cloth bag 17- Floor brush 4- Latch 11- Safety float valve 18- Crevice tool 5- Vacuum hose connector 12- Filter basket 6- Tank 13- Sponge filter 7- Accessories holder 14- Plastic tube RH20LW User guide... -
Page 4: 2- Before Assembly And Starting Operation
• Do not operate a defection unit • Servicing only by an authorized after-sales service point • Use only for operations for which the unit is intended • Take great care when cleaning stairs • Use only manufacturer attachments and spare parts RH20LW User guide... -
Page 5: 3- Technical Data
3. Technical Data Rated voltage:....120 V Normal frequency: ..60 Hz Rated power: ....1000 W Capacity: ......20 L 4. Overview of Nozzles RH20LW User guide... -
Page 6: 5- Assembly
8. Make the clips locking on the cover 9. Insert the suction hose in the hole on the side of the tank,turn the hose connector and it is ready to work 10. Slide the brush at the end of the wand RH20LW User guide... -
Page 7: 6- Wet Vacuum Cleaning
6. After working or when the bin is full, what significantly decreases the suction power,remove the plug from the electrical socket and clean the drum 7. To do this,unhook the two locks and remove the suction unit and filter RH20LW User guide... -
Page 8: 7- Dry Vacuum Cleaning
7. After working or when the bin is full,what significantly decreases the suction power,remove the plug from the electrical socket and clean the drum.To do this,unhook the two locks and remove the suction unit and filter.Usually,when the paper dustbag to be full, throw it into the ash bin RH20LW User guide... -
Page 9: 8- Blowing
2. Remove the plug from the electrical socket and clean the drum 3. To do this, unhook the two locks and remove the suction unit and filter. 4. Clean the drum 5 Wash the sponge filter with clean water and soft soap. Rinse well User guide RH20LW... - Page 10 RH20LW User guide...
- Page 11 RH20LW User guide...
- Page 12 PARTS, ACCESSORIES & VACUUM BAGS VISIT OUR WEBSITE AT w w w. r h i n o - v a c . c o m...
