- Page 1 USER GUIDE Cordless Vacuum Cleaner A powerful vacuum cleaner, light and maneuverable...
-
Page 2: User Guide
RH22 ASSEMBLY Read and save the safety precautions located at page 3 User Guide - 2 -... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS 1. This appliance can be used by children aged from 8 years and above and people with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 4 COMPONENTS 1. 3 IN 1 TOOL 10. ON / OFF indicator 2. Charging base 11. Main body JV222BASE - OPTIONAL 12. Dust cup 3. Aluminum tube 13. Li-ion battery 4. Power head 14. Battery lock 5. Brush clip 15. Wall-mounted tool 6.
-
Page 5: Technical Data
TECHNICAL DATA Model RH22 Rated voltage 22.2V d.c. Unpacking and Assembling Check that all the parts in the box. (See page. 4) Step 1. Install the battery as shown in the drawing below. Step 2. Insert the power brush carefully in the aluminum tube as shown in the drawing below. - Page 6 Step 3. Insert the aluminum tube with the power brush into the vacuum as shown in the drawing below. Step 4. Insert the 3 in one accessory to the aluminum tube or to the vacuum as shown in the drawing below. Simply push out the tip Push and slide Result...
- Page 7 The adaptor may become warm during charging : this is normal. Your cordless vacuum cleaner RH22 may come with a charging station : this is optional. If it so, put the battery on the charging base, always away from heat sources and wet places.
- Page 8 HOW EMPTYING / CLEANING 1. Remove the accessories from the body by pressing the release button provided to that purpose as shown in the drawing below. 2. Press the release button to open the dust hatch, then drop out the dust into a trash pan as shown in the drawing below.
- Page 9 FOR CLEAN OR REPLACE THE FILTER 4. Press the button to open the front cover and take out the filter. Wash the filter under flowing water. Let it completely dry before reusing it again (Make sure the filter is dry before next time using). To replace with a new filter, press the button to open the front cover and take out the use filter and put a new filter as shown in the drawings blow.
- Page 10 HOW TO CLEAN THE ROLLER BRUSH If the roller brush becomes blocked or jammed with debris, the vacuum will shut down, or be less efficient. The roller brush may then need to be cleaned. Switch off the device first and then carefully use a pair of scissors or a sharp knife to remove any items such as hairs that may have become entangled.
- Page 11 If your vacuum cleaner comes with a OPTIONAL charging station, insert the handheld vacuum cleaner into the station, then put the aluminum tube into the hook as shown in the drawing. NOTE: THE CHARGING STATION IS OPTIONAL. Basic Technical Data BATTERY: 22.2 V 2200 mah Li-ion ADAPTER: Input 100~240V 50Hz OUTPUT:27V 800 mah...
- Page 12 Extension VISIT OUR WEBSITE AT www.rhino-vac.com...
