Lake Lite LL-SPL-PAG-WBA Quick Start Manual

SOLAR PAGODA LITE
MODEL: LL-SPL-PAG-WBA
SOLAR PAGODA LITES
The Solar Pagoda Piling Light provides the classic
Florida dock appearance without electrical
wires. A super bright LED illuminates the fixture
to provide a soft, ambient glow that is not
blinding at eye level.
Our new patented magnet technology allows
a quick change of LED intensity for adjustment
of the 7-brightness settings. Fast and simple
brightness setting for seasonal weather
conditions. Available in white powder coat finish
with White, Blue or Amber LED.
LIGHT CHARACTERISTICS
Light Source
Lumens output
Available LED Colors
Light Mode Options
Visible Range
Horizontal Output (degrees)
Vertical Divergence (degrees)
LED Life Expectancy (hours)
ELECTRICAL CHARACTERISTICS
Circuit Protection
Nominal Voltage (v)
Autonomy (hours)
Temperature Range
SOLAR CHARACTERISTICS
Solar Module Type
Power (watts)
Solar Module Efficiency (%)
POWER SUPPLY
Battery Type
Battery Size
Battery Capacity (mAh)
Nominal Voltage (v)
Battery Service Life
Battery Service Access
PHYSICAL CHARACTERISTICS
Body Material
Lens Material
External Lens Design
Internal Lens design
Water Proof Rating
Mounting
Height
Width / Diameter
Weight
OPTIONS
Custom Options, Sizes, & Colors
Custom Hardware & Mounting
* Information subject to change without notice
Phone: 260-918-2758
PO BOX 414
Fax:
105 W. Simon St.
E-mail sales@lakelite.com
Laotto, IN 46763
2-Ultra-High intensity Cree XBD LED
(White/Amber/Blue)
3/7/12/17/23/28/35 *Varies with Color &
Power / Brightness Settings
White, Amber & Blue
Constant
0.1-0.5 Nautical Mile *Varies with LED color
& Brightness Settings
360°
100-180° Various with Mounting
> 100,000 hrs
Integrated
3.2v
6-24hrs *On full Charge * Varies With
Brightness Settings & Conditions
14 to 158° Fahrenheit
Multicrystalline or Monocrystalline
0.6w
16-17%
High Capacity LiFePo4 18500 1000mA
18500
1000mA
3.2v
1-3 years (Varies with local Environment)
Yes: User Changeable / Replaceable
Marine Grade Aluminum + Powder Coat
UV-Stabilized Polycarbonate
NA
NA
IP 68
Fits on Pilings or flat surfaces 5" diameter
and Larger
9.75"
10"
4.0 lbs
Please Contact
Please Contact
260-918-3540
www.lakelite.com
35*
Lumens
