Hazard Alert Messages
8 Maintenance
Read and observe all Warning and Caution hazard alert messages in
this publication. They provide information that can help prevent
serious personal injury, damage to components, or both.
WARNING
To prevent serious eye injury, always wear safe eye protection
when you perform vehicle maintenance or service.
During lubrication procedures, if grease flows from the seal
near the camshaft head, replace the seal. Remove all grease
or oil from the camshaft head, rollers and brake linings.
Always replace linings contaminated with grease or oil, which
can increase stopping distances. Serious personal injury and
damage to components can result.
ASBESTOS AND NON-ASBESTOS
FIBERS WARNING
Some brake linings contain asbestos fibers, a cancer and lung
disease hazard. Some brake linings contain non-asbestos
fibers, whose long-term effects to health are unknown. You
must use caution when you handle both asbestos and
non-asbestos materials.

Lubrication

Brake Assembly Components

Refer to Table C for grease specifications.
Table C: Cam Brake Grease Specifications
Components
Retainer Clips
Anchor Pins
Rollers, Journals Only
Camshaft Bushings
Camshaft Splines
*Do not mix Meritor specification O-637 grease, part number 2297-U-4571, a calcium-base, rust-preventive grease, with other greases.
Meritor Specification NLGI Grade
O-616-A 1
O-617-A 1
O-617-B 2
O-645 2
O-692 1 and 2
Any of above Refer to above
O-637* 1-1/2
O-641 —
Grease Type Outside Temperature
Clay Base Down to –40°F (–40°C)
Lithium 12-Hydroxy Refer to the grease
Stearate or Lithium manufacturer's
Complex specifications for the
temperature service limits.
Synthetic Oil, Clay Base Down to –65°F (–54°C)
Lithium Base Down to –40°F (–40°C)
Refer to above Refer to above
Calcium Base Refer to the grease
manufacturer's
Anti-Seize
specifications for the
temperature service limits.
