GW100

Owner's Guide

Need help?

Do you have a question about the GW100 and is the answer not in the manual?

Page 1 GW100 Owner’s Guide...
Page 2 Overview Power / Action Volume Up / Action Volume Down / Action Charging Light Line-In Charging Port...
Page 3 Power Long Press: Power On / Off Battery Saver: If unpaired for 10 minutes, GW100 will power off. Blue: Fully Charged Blue: Powered On Red: Charging Red: Low Battery Charging: Plug the Micro USB cable into the charging port and connect the other end to a compatible USB port of a computer or wall charger.
Page 4 Bluetooth. After a few seconds, you will see “Grado GW100”. Tap to pair. When the paired device’s Bluetooth is turned off or out of range, the GW100 can connect to a second device. Blue & Red: Ready to Pair...
Page 5 Volume / Music Short Press: Play / Pause Short Press: Increase Volume Long Press: Next Song Short Press: Decrease Volume Long Press: Previous Song...
Page 6: Phone / Voice
Phone / Voice Short Press: Answer / Hang Up Long Press: Reject Call Double Press: Voice Assistant Short Press: Increase Volume Short Press: Decrease Volume...
Page 7: Specifications
Specifications Bluetooth Version: 4.2 with apt-X Working Distance: 10m Battery Life: 15 hours* Charging Time: 2 hours Frequency Response: 20Hz~20KHz Mic Sensitivity: 42dB +/- 3dB Battery Capacity: 320mAH Methods of pairing to Bluetooth may vary depending on the specific device. Please refer to the device’s manual for further details. *Battery life will vary depending on the listening volume and genre of music played.
