- Page 1 MEMO SERVICE PROGRAMMER v1.1 user manual MEMO MANAGER MEMO PROGRAMMER SOFTWARE v1.1 user manual automation systems...
-
Page 2: Table Of Contents
4. Receiver management through the MEMO ....... . . 4... -
Page 3: Memo - Service Programmer
I. MEMO - SERVICE PROGRAMMER 1. GENERAL INFORMATION MEMO is a service programmer designed to work with selected DTM System receivers. Using the programmer allows you to save remote controllers memory or telephone numbers memory from the receiver to a file, enter remote controllers or telephone numbers to the receiver memory from a file, and update the receiver firmware. -
Page 4: Receiver Management Through The Memo
When the highest number 99999 is busy, MEMO will report an error and the remotes / numbers will fail to register. In this case, you must organize the files in memory using the MEMO MANAGER program - rename... -
Page 5: Remotes / Numbers Write To Receiver
ź flash to indicate that the programmer is ready for operation. press the WRITE button. MEMO will first create an emergency backup of the receiver's memory. It is ź signaled by a fast pulsing of the green BACKUP diode and lighting of the red WRITE diode. Then, the process of saving remote controls / numbers to the receiver's memory will start. - Page 6 (see the MEMO MANAGER instruction). If no file is set as the main one, the MEMO programmer will use the remotes / numbers file with the highest number for saving, i.e. the file of recently remembered remotes / numbers.
-
Page 7: Receiver Software Update
In the software update procedure, the MEMO programmer always selects the latest firmware version available on the device. If the receiver firmware version is newer than available in the MEMO programmer memory, the programmer expects confirmation of the operation of uploading the older version of the software. -
Page 8: Registration Of Operations
5. REGISTRATION OF OPERATIONS Each operation performed by the MEMO programmer is recorded in the log.txt file, available after connecting MEMO to the computer. The file contains basic information about the course of operations, such as: receiver type, firmware version, file name, operation status, type and error code. -
Page 9: Memo Code Table
6. MEMO PROGRAMMER CODE TABLE In the case of errors during the backup operation to the MEMO, write to the receiver, firmware updates, one of the LEDs BACKUP, WRITE, or UPDATE (depending on the operation being performed) will periodically blink, the blink indicates the amount of the type of error (Table 1). The error code is recorded in the log.txt file (see item 5). -
Page 10: Memo Manager - Memo Software
MEMO MANAGER is a computer program designed to support the MEMO service programmer. The program allows you to manage files used in working with the MEMO service programmer and edit the contents of remote memory / number files. MEMO MANAGER software ensures full compatibility between systems thanks to the support of remote controls files from various receiver models. - Page 11 On the right, files stored in the MEMO programmer's memory are displayed. Connection of the MEMO programmer and proper communication of the program with a computer is indicated by the icon, the lack of connection is indicated by the icon.
-
Page 12: Control Gsm Tab
MEMO to write to the receiver when the WRITE function is used... -
Page 13: Editing Numbers And Receiver Configuration
5.1.1. EDITING NUMBER FILES AND CONFIGURATION OF THE RECEIVER The MEMO MANAGER program allows you to modify the contents of the subscriber numbers memory and receiver configuration in a file. After pressing the EDIT button, the file editing window appears with two tabs: SUBSCRIBERS TAB- from the tab level you can add, edit or delete subscribers. - Page 14 DEVICE SETTINGS TAB - from the tab you can configure the settings of the receiver. ź Fig. 5. View of the CONTROL GSM receiver settings edition window. When creating and editing a file for a Control GSM receiver, make sure that both the Subscribers and Device settings tabs contain the correct values.
-
Page 15: Radio Receivers Tab
MEMO to write to the receiver when the WRITE function is used... -
Page 16: Editing Remote Control Files
5.2.1. EDITING REMOTE FILES The MEMO MANAGER program allows you to modify the contents of remotes memory contained in the file. After pressing the EDIT button, the remote controls file editing window appears, from which you can: - delete remote controls... - Page 17 Description of buttons and functions of the „File edition”: adds remotes from another file to the list saves the current file activates the remote edit buttons displays the remote control editing window in which you can change the position of the remote control in the memory and configure links between remote control buttons and the receiver channels copies the remote control to the program clipboard copies the remote control to the clipboard and removes it from the list...
-
Page 18: Firmware Tab
5.3.FIRMWARE TAB From the FIRMWARE tab you can download the latest receiver firmware available on DTM System servers and manage these files. The downloaded firmware can be downloaded to the appropriate radio receiver. Fig. 8. Main window view - FIRMWARE tab. - Page 19 WARRANTY CONDITIONS DTM System provides operational and ready to use devices. The producer gives 24 months warranty from the selling date to the end customer. This time is counted according to the producer warranty labels or serial numbers placed on every product.
