FLOS ROMEO SOFT F/T1 TAVOLINO Instruction For Correct Installation And Use

INSTRUCTION FOR
INSTALLATION AND USE

WARNING!

The safety of this fitting can only be
guaranteed if these instructions are
observed, during both installation and
use. Please retain these instructions
safety.

Remarks:

- When installing and whenever acting
on the appliance, ensure that the power
supply has been switched off;
- The unit has a protective fuse located in
the intensity regulator housing. Check
that it is intact in the event the unit fails
to operate;
- The symbol marked on the
appliance indicates the need to use
self-protected bulbs;
- The appliance may in no way be
modified or tampered with, any
modification may compromise safety
causing the appliance to become
dangerous. FLOS
responsibility for products that are
modified.
- Should the external trailing cable get
damaged,it must be replaced by FLOS
or by qualified personnel in order to
avoid any danger.
Fig. 1 Rest the support ring (A) on the
cup (B) and fasten it with the pins
provided (C).
Fig. 2 Insert the diffuser (D).
Fig. 3 Insert the light bulb (E).
Fig. 4 Unscrew the small fixing rollers
(Q) from the hooked screws (R) of
the farbic crown.
Fig. 5 Position the fabric crown (F) on the
support ring (A) taking care to
insert the hooked screws (R) into
the specially holes in the ring (A),
screw up the fixing rollers again
(Q). Rest the covering ring (G) on
the pins (C).

TECHNICAL DATA

- Incandescent halogen bulb MAX 150W,
E26 fitting, type HSGS/F.
- Line fuse 2.6A.

CLEANING INSTRUCTIONS

- Use only a soft cloth to clean the
appliance, dampened with water and
soap or mild cleanser if needed for
resistant dirt. Warning: do not use
alcohol or other solvents.
FLOSUSA
ROMEO SOFT F/T1 TAVOLINO
CORRECT
A
declines all
R
F
G
C
C
B
FIG. 1
R
E
Q
FIG. 3
Q
A
FIG. 5
cod. 09464
D
FIG. 2
FIG. 4
01-07-2004
