Colour Television
Contents
Waveforms
©
Copyright 2008 Philips Consumer Electronics B.V. Eindhoven, The Netherlands.
All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system or transmitted, in any form or by any means, electronic,
mechanical, photocopying, or otherwise without the prior permission of Philips.
Published by JH 0862 BU CD Consumer Care
Page
2
5
6
7
19
20
Diagram PWB
[S-A01] 21
37
[S-A02] 22
37
[S-A03] 23
37
[S-A04] 24
37
37
[S-A06] 26
37
[S-A07] 27
37
[S-A08] 28
37
[S-A08] 29
37
[S-A09] 30
37
[S-A10] 31
37
[S-A11] 32
37
[S-A12] 33
37
[S-A13] 34
37
37
[S-A15] 36
37
38
39
[P] 40
n.a.
41
Printed in the Netherlands
Contents
Subject to modification
Chassis
QCS1.0S
LA
H_17540_000.eps
140108
Page
43
46
50
51
EN 3122 785 17540
Advertisement
Table of Contents
Related Manuals for Philips QCS1.0S
Summary of Contents for Philips QCS1.0S
-
Page 1: Table Of Contents
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips. Published by JH 0862 BU CD Consumer Care... -
Page 2: Technical Specifications, Connections, And Chassis Overview
EN 2 QCS1.0S LA Technical Specifications, Connections, and Chassis Overview 1. Technical Specifications, Connections, and Chassis Overview Index of this chapter: 1.1.3 Miscellaneous 1.1 Technical Specifications 1.2 Connection Overview Power supply: 1.3 Chassis Overview - Mains voltage (V : 100 - 240... - Page 3 Technical Specifications, Connections, and Chassis Overview QCS1.0S LA EN 3 Connection Overview AUDIO IN 1 AUDIO IN 2, 3 AUDIO OUT EXTERNAL CONTROL RS-232 (OUT) (IN) COMPOSITE VIDEO IN COMPOSITE VIDEO BNC (IN) (OUT) SPEAKER CONNECTIONS POWER SUPPLY RGB 1...
- Page 4 EN 4 QCS1.0S LA Technical Specifications, Connections, and Chassis Overview Cinch: Audio - Out - CTS Clear To Send Rd - Audio - R 0.5 V / 10 kohm - RI Ring Indicator Wh - Audio - L 0.5 V...
-
Page 5: Safety Instructions, Warnings, And Notes
Keep • Use only lead-free soldering tin Philips SAC305 with order components and tools also at this same potential. code 0622 149 00106. If lead-free solder paste is required, •... -
Page 6: Directions For Use
EN 6 QCS1.0S LA Directions for Use 2.3.5 Alternative BOM identification MADE IN BELGIUM MODEL 32PF9968/10 The third digit in the serial number (example: 220-240V 50/60Hz AG2B0335000001) indicates the number of the alternative 128W VHF+S+H+UHF PROD.NO: AG 1A0617 000001 B.O.M. (Bill Of Materials) that has been used for producing the specific TV set. -
Page 7: Mechanical Instructions
Mechanical Instructions QCS1.0S LA EN 7 4. Mechanical Instructions Index of this chapter: 4.1 Cable Dressing Notes: 4.2 Service Positions • Figures below can deviate slightly from the actual situation, 4.3 Assy/Panel Removal due to the different set executions. 4.4 Set Re-assembly •... - Page 8 EN 8 QCS1.0S LA Mechanical Instructions Assy/Panel Removal 4.3.1 Back Cover Warning: Disconnect the mains power cord before you open the set. Required for sets 42" E_06532_018.eps 171106 Figure 4-2 Foam bars I_17540_014.eps 280108 Figure 4-3 Back Cover removal Refer to figure “Back Cover removal” for details.
- Page 9 Mechanical Instructions QCS1.0S LA EN 9 4.3.2 Front Cover and Shielding I_17540_013.eps 280108 Figure 4-4 Front Cover and Shielding removal [1/2] Refer to figure “Front Cover and Shielding removal” for details. 4.3.3 LED / IR Panel 1. Remove screws [1].
- Page 10 EN 10 QCS1.0S LA Mechanical Instructions 2. Remove the fixation screws [1] from the rim and remove it. 3. Now the clips that hold the power switch can be released via the backside of the switch. When defective, replace the whole unit.
- Page 11 Mechanical Instructions QCS1.0S LA EN 11 I_17540_010.eps 280108 Figure 4-12 SSB...
- Page 12 EN 12 QCS1.0S LA Mechanical Instructions 4.3.8 Main Supply Panel I_17540_045.eps 310108 Figure 4-13 Main supply panel. 1. Refer to figure “Main supply panel”. 2. Unplug connectors [1]. 3. Remove the grounding screw [2]. 4. Remove the fixation screws [3].
- Page 13 Mechanical Instructions QCS1.0S LA EN 13 4.3.9 LCD Panel Important: Be sure to work in a dust free environment during the following activities. In addition, the use of (fabric) hand gloves is advised. I_17540_001.eps 280108 Figure 4-14 Plasma panel disassembly 1.
-
Page 14: Service Modes, Error Codes, And Fault Finding
Figure 5-1 Remote control. remote control press “-”, ”-”, “+”, “+”, “-”, “+”, “-”, “+”, “SET”, “MENU”. • Please note that this set does not respond on the standard Philips remote controllers, but only responds to the with the set supplied remote control. - Page 15 Service Modes, Error Codes, and Fault Finding QCS1.0S LA EN 15 5.2.2 Repair flow chart No Image appear Not OK LED Bright ? Orange Check CN7 pin6 = 5 V? Check LED status Not OK Green Check cable from Not OK...
- Page 16 EN 16 QCS1.0S LA Service Modes, Error Codes, and Fault Finding No Audio Is Audio Input Source selection correct? Not OK Is Mute and volume setting Select correct Audio Input Source Not OK Not OK Check CN2 cable Reset mute...
- Page 17 Service Modes, Error Codes, and Fault Finding QCS1.0S LA EN 17 Remote No Function Check Battery Not correct Check cable from CN14(MB) Change Battery connection OK, Well connection Replace IR/LED Board Button Key No Function Check cable from CN3(MB) connection...
- Page 18 EN 18 QCS1.0S LA Service Modes, Error Codes, and Fault Finding Personal Notes: E_06532_012.eps 131004...
-
Page 19: Block Diagrams, Test Point Overview, And
Block Diagrams, Test Point Overview, and Waveforms QCS1.0S LA 6. Block Diagrams, Test Point Overview, and Waveforms Wiring Diagram WIRING DIAGRAM I_17540_016.eps 310108... -
Page 20: Block Diagram
Block Diagrams, Test Point Overview, and Waveforms QCS1.0S LA Block Diagram BLOCK DIAGRAM L C D P A N E L(LK460D3LZ18) Phone Jack (CN16) Audio D-SUB VGA Audio1 IN Power (CN6) AUDIO SW Module NJW1411M Audio2 IN Audio VIDEO BUFFER... -
Page 21: Circuit Diagrams And Pwb Layouts
Circuit Diagrams and PWB Layouts QCS1.0S LA 7. Circuit Diagrams and PWB Layouts Scaler Board: Power SCALER BOARD: POWER S-A01 S-A01 +5V_SW KHB0805R121SA +5VS +5VSB 200/1% KHB0805R121SA/NC +3.3V_SW KHB0805R121SA +5V_VD +5V_SW +5V_VD KHB0805R121SA KHB0805R121SA KHB0805R121SA 0.1uF +5VS +5V_SW VOUT KHB0805R121SA/NC... -
Page 22: Scaler Board: Hdmi Input
Circuit Diagrams and PWB Layouts QCS1.0S LA Scaler Board: HDMI Input SCALER BOARD: HDMI INPUT S-A02 S-A02 P0_CBL5V DDC_VCC DDC_VCC DDC_VCC APHD APHD APHD 24LC02B_SOP_8P P0_CBL5V R649 BAV70 APDDC-SDA APDDC-SDA 0R/NC EDID_WP APDDC-SCL +5VS APDDC-SCL 1K/NC 1K/NC ADVI_SCL HDMI0 APHD_CRL... -
Page 23: Scaler Board: Hdmi Switch
Circuit Diagrams and PWB Layouts QCS1.0S LA Scaler Board: HDMI Switch SCALER BOARD: HDMI SWITCH S-A03 S-A03 +3V3-TMDS341 BPR0XC- BPR0XC- BPR0XC+ BPR0XC+ BPR0X0- BPR0X0- BPR0X0+ BPR0X0+ BPR0X1- +3V3-TMDS341 BPR0X1- BPR0X1+ BPR0X1+ BPR0X2- BPR0X2- BPR0X2+ TMDS_/OE BPR0X2+ EQ_S0 EQ_S1 DDC_VCC R662... -
Page 24: Scaler Board: Analog Input
Circuit Diagrams and PWB Layouts QCS1.0S LA Scaler Board: Analog Input SCALER BOARD: ANALOG INPUT S-A04 S-A04 VGA_5V +5VS +5VS VGA_5V : 16 BAV70 L110 DSUB_RIN L111 DSUB_GIN L112 DSUB_BIN DSUB_HIN SMTVCC DSUB_VIN 0.1uF 0.1uF DDC_VGA_SCL R184 R185 DDC_VGA_SDA NC7S14... -
Page 25: Scaler Board: Analog Switch & Output [S-A05]
Circuit Diagrams and PWB Layouts QCS1.0S LA Scaler Board: Analog Switch & Output SCALER BOARD: ANALOG SWITCH & OUTPUT S-A05 S-A05 R213 R214 MTM_MM1470AJBE_SSOP_34P/NC SW_BLU_A BLUEOUT 47uF/25V/NC R215 DSUB_BLU_IN GND: 8mil at least SW_GNDB GND_OUTB DSUB_BIN 0.01uF 0.01uF R271 C159... -
Page 26: Scaler Board: Scaler [S-A06]
Circuit Diagrams and PWB Layouts QCS1.0S LA Scaler Board: Scaler SCALER BOARD: SCALER S-A06 S-A06 +3.3AVDD +3.3AVDD +3.3AVDD C144 C143 C142 C141 C140 C139 C138 pin66,162,182 2.5V_MEM VDDM VDDC 1.8V_MST pin86,102,1 13,125,139,154 KHB0805R121SA KHB0805R121SA KHB0805R121SA 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF... -
Page 27: Scaler Board: Ddr-Sdram [S-A07]
Circuit Diagrams and PWB Layouts QCS1.0S LA Scaler Board: DDR-SDRAM SCALER BOARD: DDR-SDRAM S-A07 S-A07 2007/02/28 2.5V_MEM DDR_Q2.5V 2.5V_MEM DDR_Q2.5V C184 C185 C186 C187 C188 C189 C190 C191 C193 C194 C195 C196 C197 C198 C199 C200 C201 C202 L124 0.1uF 0.1uF... -
Page 28: Scaler Board: Mcu [S-A08]
Circuit Diagrams and PWB Layouts QCS1.0S LA Scaler Board: MCU SCALER BOARD: S-A08 S-A08 MCUVCC MCUVCC 2007/04/12 L125/NC MCUVCC_3V3 +5VS MCUVCC MCUVCC KHB0805R121SA NC7SZ04P5X_SC70_5P MCUVCC L125 KHB0805R121SA/NC MCUVCC ROM_CE C203 C204 C205 C206 KHB0805R121SA 47uF/25V 0.1uF 0.1uF 0.1uF R329 R330... -
Page 29: Scaler Board: Fan Control-Rtc [S-A08]
Circuit Diagrams and PWB Layouts QCS1.0S LA Scaler Board: Fan Control-RTC SCALER BOARD: FAN CONTROL-RTC S-A09 S-A09 +12V_SW FANVCC KHB0805R121SA/NC +5VS RTCVCC KHB0805R121SA MMBT3906 C221 C222 C226 0.1uF 0.1uF R427 47uF/25V/NC FANVCC R429 R426 R428 C227 FANVCC R431 1F_5.5V 4.7K... -
Page 30: Scaler Board: Panel Interface [S-A09]
Circuit Diagrams and PWB Layouts QCS1.0S LA Scaler Board: Panel Interface SCALER BOARD: PANEL INTERFACE S-A10 S-A10 +12V_SW +5V_SW KHB0805R121SA PANEL_POWER +5V_SW R452 KHB0805R121SA/NC 220 OHM C440 C233 R453 PANEL_POWER SELFD_PPWR 100uF/25V C234 C235 C236 C237 0.1uF 2200pF R454 0.1uF/NC 0.1uF... -
Page 31: Scaler Board: Audio Amplifier [S-A10]
Circuit Diagrams and PWB Layouts QCS1.0S LA Scaler Board: Audio Amplifier SCALER BOARD: AUDIO AMPLIFIER S-A11 S-A11 +5V_REF C240 10uF/50V L108 R673 HeadPh one Jack R468 C242 10uF/50V CN17 L109 R674 R675 H PR YDA138 100K R676 C239 100K A-OUT_L29... -
Page 32: Scaler Board: Board Diagram [S-A11]
Circuit Diagrams and PWB Layouts QCS1.0S LA Scaler Board: Board Diagram SCALER BOARD: BOARD SCHEMATIC DIAGRAM S-A12 S-A12 CVBSIN JACK1 RCA_CVBS_IN R496 +5V_VD R497 R498 C266 KHB0805R121SA C267 C268 22uF/50V 100uF/25V AV_YIN R499 100pF 75_1/2W C269 EZJZ0V800AA/NC 0.1uF C270 47uF/25V... -
Page 33: Scaler Board: Audio Input [S-A12]
Circuit Diagrams and PWB Layouts QCS1.0S LA Scaler Board: Audio Input SCALER BOARD: AUDIO INPUT S-A13 S-A13 R524 120/1% PHONEJACK STEREO R525 C288 Near to JACK2 A9VOUT PC_LIN +12V_SW VOUT PC_RIN KHB0805R121SA KHB0805R121SA KHB0805R121SA C290 C291 JACK2 ADJ/GND C293 C294... -
Page 34: Scaler Board: Video Decoder
Circuit Diagrams and PWB Layouts QCS1.0S LA Scaler Board: Video Decoder SCALER BOARD: VIDEO DECODER S-A14 S-A14 +3.3V_SW +3.3VD pin1, 11, 26, 44, 53, 88, 98, 109, 120, 132 +1.5VDD +1.5VD pin16,23, 27, 32, 39, 48, 57, 70, 76, 81, 92, 103, 115, 125, 133... -
Page 35: Scaler Board: Video Decoder Sdram [S-A14]
Circuit Diagrams and PWB Layouts QCS1.0S LA Scaler Board: Video Decoder SDRAM SCALER BOARD: VIDEO DECODER SDRAM S-A15 S-A15 SDRDQ[15..0] SDRDQ[15..0] +3.3V_SW +3.3V_DDR SDRA[11..0] SDRA[11..0] +3.3V_DDR +3.3V_DDR 16MbitSDRAM SÉ SDRDQ0 SDRDQ15 RÉ SDRDQ1 SDRDQ14 RÉ RÉ SDRDQ2 SDRDQ13 RÉ SDRDQ3 Ш... -
Page 36: Scaler Board: Rs232
Circuit Diagrams and PWB Layouts QCS1.0S LA Scaler Board: RS232 SCALER BOARD: RS232 S-A16 S-A16 TEKCON_1297_000_410_52_18P Control Near to J2 I N-terminal O UT-terminal Pins MODE SP3243 RXD TXD L102 0R R593 RXD_OUT RXD_OUT T1OUT T1IN TXD_IN T2OUT T2IN L103 0R... - Page 37 Circuit Diagrams and PWB Layouts QCS1.0S LA Layout Scaler Board (Top Side) I_17540_034.eps 310108...
-
Page 38: Keyboard Panel
Circuit Diagrams and PWB Layouts QCS1.0S LA Keyboard Panel KEYBOARD PANEL KEY_5V KEY_5V KHB0805R121SA ADC_IN3 ADC_IN2 10K/1%/0603 ADC_IN1 0.1uF EIC_4510_E05N ADC_IN1 0.1uF 0.1uF 0.1uF TOUCH SWITCH 4P TOUCH SWITCH 4P SMD SWITCH MUTE KEY_5V KEY_5V 4.7K Package STSB5 10K/1%/0603 10K/1%/0603... -
Page 39: Ir & Led Panel
Circuit Diagrams and PWB Layouts QCS1.0S LA IR & LED Panel IR & LED PANEL Part modified 3801_1.25pitch_6pin REMO_V33 SMD Connector IR_DATA JP/RC0603 0.1uF GREEN ROHM_SML020MLTT86 OPTO_FM_1040FN_F_5NR_REV_4P IR_DATA R16 47 GREEN REMO_V33 3.3K MLTT86 Package SMD IR Sensor 10uF Packag e : REV_4P... -
Page 40: Power Board [P]
Circuit Diagrams and PWB Layouts QCS1.0S LA Power Board POWER BOARD I_17540_041.eps 310108... -
Page 41: Speaker Board
Circuit Diagrams and PWB Layouts QCS1.0S LA Speaker Board SPEAKER BOARD FIX16 CN12 FIX_MASK FIX17 FIX_MASK 4500-E04N CN13 FIX18 TEKCON_5110-855-310-52_4P DIP Packag e : 5110_4pin FIX_MASK 330pF 330pF 330pF 330pF I_17540_035.eps 310108... - Page 42 Circuit Diagrams and PWB Layouts QCS1.0S LA Personal Notes: E_06532_013.eps 131004...
-
Page 43: Alignments
Alignments QCS1.0S LA EN 43 8. Alignments Index of this chapter: Setting Range Default value 8.1 General Alignment Conditions Black level 0 to 100 8.2 Hardware Alignments Noise reduction 8.3 Software Alignments Tint 0 to 100 8.4 Option Settings 8.5 Software update... - Page 44 EN 44 QCS1.0S LA Alignments Setting Range Default value Setting Range Default value Language English Tiling Submenu Panel saving Submenu Date and time Submenu Color system Schedule Submenu Configuration Submenu Monitor ID Submenu reset DDC/CI On/off Factory reset Submenu Advanced...
- Page 45 Alignments QCS1.0S LA EN 45 Option Settings Setting Range Default value Version Submenu Not applicable. Submenu Note: Software update 1. This function turns enables a monitor to burn in without an input signal by showing the following burn in pattern cycle: 8.5.1...
-
Page 46: Circuit Descriptions, Abbreviation List, And Ic Data Sheets
EN 46 QCS1.0S LA Circuit Descriptions, Abbreviation List, and IC Data Sheets 9. Circuit Descriptions, Abbreviation List, and IC Data Sheets JRC NJW1141 Audio Processor Index of this chapter: 9.1 Mstar MST5251A scaler 9.2 NEC uPD64015 Video Decoder The NJW1141 is a sound processor includes all of the 9.3 TI PCM1753 Audio DAC... - Page 47 Circuit Descriptions, Abbreviation List, and IC Data Sheets QCS1.0S LA EN 47 Sipex SP3243 RS-232 transceiver 9.13 NXP PCF8563 RTC The SP3243 transceivers meet the EIA/TIA-232 and ITU-T The PCF8563 is a CMOS real-time clock/calendar optimized V.28/V.24 communication protocols. Generates 5.5V RS-232 for low power consumption.
- Page 48 Committee LATAM. LATin AMerica C-FRONT. Chrominance front input LC04. Philips chassis name for LCD TV 2004 CBA. Circuit Board Assembly (or PWB) project Constant Level: audio output to LCD. Liquid Crystal Display connect with an external amplifier LED.
- Page 49 Sound right SCART2 out SNDS-VL-OUT. Surround sound left variable level out SNDS-VR-OUT. Surround sound right variable level out SOPS. Self Oscillating Power Supply S/PDIF. Sony Philips Digital InterFace SRAM. Static RAM STBY. Stand-by SVHS. Super Video Home System Sub Woofer / SoftWare THD.
-
Page 50: Spare Parts List
EN 50 QCS1.0S LA Spare Parts List 10. Spare Parts List Set Level BDL4631V/00 0001 9965 100 10746 Front bezel assembly 0003 9965 100 10747 Back cover assembly 0012 9965 100 10736 46" LK46D3LZ1 1080P 0020 9965 100 10749 Main Board [S-A]... -
Page 51: Revision List
Revision List QCS1.0S LA EN 51 11. Revision List Manual xxxx xxx xxxx.0 • First release.
