SuperLightingLED PLLD-T Series User Manual

Important: Read all instructions prior to installation.
LED Parking Lot/Area Light
PLLD-T150K240-H3P
(with PLLD-T1SF mount)
Specifications
Environmental Specifications
Operating Temperature
IP Rating
Wiring Diagram
Line
Neutral
Ground
Mounting Options
Dim (+)
Adjustable Square/Round Pole Mount (PLLD-T1APM)
Dim (-)
Adjustable Slip-fitter/Pole Mount (PLLD-T1SF)
-40°–113° F(-40°–45° C)
IP65
120–277 VAC Input
L L
N N
GND GND
Purple
+ +
- -
Safety and Notes
• Product should be installed and serviced by a certified electrician in accordance
with applicable national, state, and local building and electrical codes.
• To reduce the risk of electric shock, ensure that the main power source and
circuit breakers are switched off before performing any installation or wiring
procedures. Do not install while inclement weather, such as rain storms, may
increase the chances of electrical hazard.
• Avoid looking directly into lamp when illuminated.
Slip fitter
• Ensure all mounts are securely attached and will support the weight of the
fixture. Failure to properly support fixture may result in damage or injury, for
which the manufacturer does not assume responsibility.
Check product label for specific electrical
specifications related to installation.
Line
Improper installation will void warranty.
Neutral
Ground
square/round pole mo
Dim (+)
Black
Dim (-)
White
Green
Fixed Square/Round Pole Mount (PLLD-T1FPM)
Gray
fixed square/round po
Wall/Trunnion Mount (PLLD-T1WM)
trunnion
Rev Date: V2.0 03/12/2021
4400 Earth City Expy, St. Louis, MO 63045
User Manual
PLLD-T Series
Black
L L
White
N N
Green
GND GND
1–10 V Dimming
Purple
+ +
Gray
- -
