FPLD-11
Pneumatic Deck Scaler Light Duty
FPHD-11
Pneumatic Deck Scaler Heavy Duty
Read this manual carefully before installing, operating or servicing this equipment. It's the responsi-
bility of the employer to ensure this manual is read by the operator. Please preserve this manual.
This document is issued with Product Serial No
Operation and Maintenance Guide
FPHD - 11
Advertisement
Table of Contents
Related Manuals for Teryair FPLD-11
Summary of Contents for Teryair FPLD-11
- Page 1 Operation and Maintenance Guide FPLD - 11 FPHD - 11 Models Descriptions FPLD-11 Pneumatic Deck Scaler Light Duty FPHD-11 Pneumatic Deck Scaler Heavy Duty Read this manual carefully before installing, operating or servicing this equipment. It’s the responsi- bility of the employer to ensure this manual is read by the operator. Please preserve this manual.
-
Page 2: Table Of Contents
Table of Contents Introduction Technical Data Safety Instructions Operating Instructions Suggested Lubricants Diassembly and Re-assembly for FPLD-11 Bill of Materials for FPLD-11 Exploded View for FPLD-11 Diassembly and Re-assembly for FPHD-11 Bill of Materials for FPHD-11 Exploded View for FPHD-11... -
Page 3: Introduction
Operation and Maintenance Guide Pneumatic Deck Scalers Page 3 Introduction Teryair Pneumatic Deck Scalers are perfect for preparation of floor surfaces. These machines are ideally used for removal of floor coating like paint, chemical & corrosion. Pistons are tungsten tipped & easily replaceable. -
Page 4: Operating Instructions
Page 4 Operating Instructions Warning This Pneumatic Piston Scabbler is not de- This floor scaler can be used for removing scales signed for use in an explosive environment. and surface paint from ship deck. Tungsten Car- Caution bide Tipped Cruciform cutter head is threaded Completely turn off the Pneumatic Piston on to the pistons to make use of scalers on steel Scabbler and disconnect air supply line before... -
Page 5: Suggested Lubricants
Operation and Maintenance Guide Pneumatic Deck Scalers Page 5 Hoses Daily before operation check the hoses for dam- age or leaks. Use genuine Teryair spares and if possible men- tion the serial number of the Pneumatic Piston Scabbler when ordering spares. Suggested Lubricants Brand... -
Page 6: Diassembly And Re-Assembly For Fpld-11
Page 6 Diassembly and Re-assembly for FPLD-11 a. Shut off air supply and allow residual Pres- tor (34) & unscrew Male Adaptor (34) sure to bleed off. from Armoured Hose (35) to replace it with new ones. (If found damaged/worn- b. -
Page 7: Bill Of Materials For Fpld-11
Operation and Maintenance Guide Pneumatic Deck Scalers Page 7 Bill of Materials for FPLD-11 Illustration Part Number Description FPLD-11 Number 128 21 01 Cylinder 128 21 02 Piston 128 21 03 Screwed Cap 128 21 04 Spring Seat 128 21 05... -
Page 8: Exploded View For Fpld-11
Page 8 Exploded View for FPLD-11 DETAIL B DETAIL A FF-MM-403-REV - 00... - Page 9 Operation and Maintenance Guide Pneumatic Deck Scalers Page 9 Exploded View Detail-A for FPLD-11 FF-MM-403-REV - 00...
- Page 10 Page 10 Exploded View Detail-B for FPLD-11 FF-MM-403-REV - 00...
-
Page 11: Diassembly And Re-Assembly For Fphd-11
Operation and Maintenance Guide Pneumatic Deck Scalers Page 11 Diassembly and Re-assembly for FPHD-11 a. Shut off air supply and allow residual Pres- h. Unscrew Cruciform Cutter Heads (3) from sure to bleed off. Piston (2) to replace it with new ones. i. -
Page 12: Bill Of Materials For Fphd-11
Page 12 Bill of Materials for FPHD-11 Illustration Part Number Description FPHD-11 Number 130 21 04 CYLINDER 130 21 05 PISTON (THREADED) 130 21 06 BUSH HAMMER CUTTER HEAD 130 40 23 BRUSH SEAL 130 40 24 O' RING 130 30 14 TOP PLATE 130 30 15 CYLINDER BLOCK... - Page 13 Operation and Maintenance Guide Pneumatic Deck Scalers Page 13 Exploded View for FPHD-11 DETAIL B DETAIL A FF-MM-403-REV - 00...
-
Page 14: Exploded View For Fphd-11
Page 14 Exploded View Detail-A for FPHD-11 DETAIL A FF-MM-403-REV - 00... - Page 15 Operation and Maintenance Guide Pneumatic Deck Scalers Page 15 Exploded View Detail-B for FPHD-11 DETAIL B FF-MM-403-REV - 00...
-
Page 16: Repair Kits
Page 16 Repair Kits For FPLD - 11 Illu. No. Part No. Description 1269700 126 21 05 CRUCIFORM CUTTER HEAD 126 40 23 BRUSH SEAL 121 21 18 HEXAGON PLUG 121 40 12 SEALING WASHER 126 90 36 HEX HEAD BOLT 342 90 24 PLAIN WASHER 23.24.80.1.2... -
Page 17: Test Certificate Of Materials, Performance
Operation and Maintenance Guide Pneumatic Deck Scalers Page 17 TEST CERTIFICATE OF MATERIALS, PERFORMANCE Date : Model number : Part description & s.No. : We hereby certify that the above referenced product has tested and inspected in accordance with our standard test procedures and meets the specifications for material and performance values as published in our literature. -
Page 18: Eu Declaration Of Conformity
Palghar – 401208, Maharashtra, India. CE certification registration no – C E 16832 Issued by – BMQR Certifications Pvt Ltd. www.cemarking-india.com Valid Till – 03/11/2021 Signed for and on behalf of TERYAIR EQUIPMENT PVT. LTD. Place of Issue: Date: FF-MM-403-REV - 00... -
Page 19: Warranty Certificate
Teryair; (vii) the issue with a Product is directly or indirectly attributable to, or directly or indirectly results from or arises out of, compliance with any design, specification or other specific requirement of Dealer/End User;... - Page 20 Page 20 This page is intentionally Left blank. FF-MM-403-REV - 00...
