DTC P0A0C - Highest Cell Voltage Too High Fault
Product Family
Orion BMS [Original] (24 - 180 Cell)
Orion BMS 2 (24 - 180 Cell)
Orion JR (16 Cell)
FAULT DESCRIPTION
IMPORTANT WARNING: Immediately disconnect any battery chargers or charge controllers from
the battery pack to prevent further overcharging the batteries.
This fault code is triggered if the voltage of an individual cell (as measured by the BMS) exceeds the
programmed maximum allowed cell voltage. This fault code will only trigger after a number of samplings
over the period of 10 seconds to prevent false positives.
This fault can be caused by incorrect cell tap wiring, a loose or disconnected cell tap, a blown fuse inside
the BMS, a high resistance or loose busbar, a cell which is actually over voltage, or from internal damage
to the BMS unit due to previous wiring faults. This fault code should always be immediately investigated
as the cells are likely being over-charged.
SAFETY WARNING: C ells which have been over-charged or over-discharged may not be safe to
use even after bringing the voltage into a correct range. A cell which has previously been
over-charged or over-discharged at any time may develop internal damage, compromising the
safety of the cell. Always consult the cell manufacturer for advice on whether a cell can be safely
used after an over-charge or over-discharge event.
Document Revision: 1.0
Last Updated: 1/9/2018
Fault Supported
NO
YES
YES
Ewert Energy Systems, Inc
161 E. St Charles Rd. Carol Stream, IL 60188
Phone: (630) 868-3173
Advertisement
Table of Contents
Related Manuals for Ewert Energy Systems Orion BMS
Summary of Contents for Ewert Energy Systems Orion BMS
- Page 1 DTC P0A0C - Highest Cell Voltage Too High Fault Product Family Fault Supported Orion BMS [Original] (24 - 180 Cell) Orion BMS 2 (24 - 180 Cell) Orion JR (16 Cell) FAULT DESCRIPTION IMPORTANT WARNING: Immediately disconnect any battery chargers or charge controllers from the battery pack to prevent further overcharging the batteries.
- Page 2 If the BMS is unable to stop or inhibit charging the battery pack then it will not be able to protect cells from being overcharged. This mechanism should be Document Revision: 1.0 Ewert Energy Systems, Inc 161 E. St Charles Rd. Carol Stream, IL 60188 Last Updated: 1/9/2018...
- Page 3 If there is no (F) next to the fault, there is no stored freeze frame available and this step can be skipped. Steps to download the Freeze Frame: 1) Connect to the BMS using the Orion BMS utility. 2) Click the “Diagnostic Trouble Codes” tab at the top. Document Revision: 1.0 Ewert Energy Systems, Inc 161 E.
- Page 4 Please contact the company or reseller that the BMS was originally purchased from for additional questions, warranty claims, repair requests and technical support. Document Revision: 1.0 Ewert Energy Systems, Inc 161 E. St Charles Rd. Carol Stream, IL 60188 Last Updated: 1/9/2018 Phone: (630) 868-3173...
