DTC P0560 - Redundant Power Supply Fault
Orion Product
Orion BMS [Original] (24 - 180 Cell)
Orion BMS 2 (24 - 180 Cell)
Orion JR (16 Cell)
FAULT DESCRIPTION
The Orion BMS has multiple input power sources for operation. The A lways On Power (Pin 1)
power supply input provides the BMS with the ability to enter a low power sleep while the
main power sources are off to keep power consumption to a minimum. This sleep mode
allows for a faster boot-up sequence as well as the retention of certain information. If the
BMS detects that this supply line is no longer available (and the power supply is enabled in
the BMS profile settings) it will set a fault code to alert the operator.
IMPORTANT NOTE: The Always On power supply is not required on the Orion BMS and can
be disabled in the BMS profile settings on the "General Settings" tab. If the power supply is
disabled then the fault code will not be set.
Fault Code
Always On Power (Pin 1) is not energized when
P0560:
Subcode 1
the power supply is enabled in the BMS profile
settings.
Always On Power (Pin 1) is energized AND
P0560:
Subcode 2
Ignition Signal (Pin 13) is energized but neither
Document Revision: 1.0
Last Updated: 10/18/2017
Fault Description
Fault Supported
YES
YES
NO
Possible Trouble Area
●
Main I/O Wire Assembly
●
Power Supply Fuse
●
Configuration Settings
●
Main I/O Wire Assembly
●
Power Supply Fuse
●
Configuration Settings
Ewert Energy Systems, Inc
161 E. St Charles Rd. Carol Stream, IL 60188
Phone: (630) 868-3173
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ewert Energy Systems Orion BMS
Summary of Contents for Ewert Energy Systems Orion BMS
- Page 1 Orion JR (16 Cell) FAULT DESCRIPTION The Orion BMS has multiple input power sources for operation. The A lways On Power (Pin 1) power supply input provides the BMS with the ability to enter a low power sleep while the main power sources are off to keep power consumption to a minimum.
- Page 2 Power nor Ready Power are energized then the BMS assumes one of the primary power sources has failed. Document Revision: 1.0 Ewert Energy Systems, Inc 161 E. St Charles Rd. Carol Stream, IL 60188 Last Updated: 10/18/2017 Phone: (630) 868-3173...
- Page 3 If there is no (F) next to the fault, there is no stored freeze frame available and this step can be skipped. Steps to download the Freeze Frame: 1) Connect to the BMS using the Orion BMS utility. 2) Click the “Diagnostic Trouble Codes” tab at the top. Document Revision: 1.0 Ewert Energy Systems, Inc 161 E.
- Page 4 Please contact the company or reseller that the BMS was originally purchased from for additional questions, warranty claims, repair requests and technical support. Document Revision: 1.0 Ewert Energy Systems, Inc 161 E. St Charles Rd. Carol Stream, IL 60188 Last Updated: 10/18/2017 Phone: (630) 868-3173...
