Sollatek GMC5-2W Installation & Operating Instructions

This instructions contains important safety instructions. Before using this product please read all instructions carefully.
I N T E L L I G E N T
R E F R I G E R A T I O N C O N T R O L S
GMC5-2W
2G AND WI-FI TRACKER WITH PRIMARY BATTERY
DIMENSIONAL DRAWING
Sollatek (UK) Ltd. Sollatek House, Waterside Drive, Langley, Slough, SL3 6EZ, UK Tel: +44 (1753) 214 500 Technical Support: sollateksupport@sollatek.com Sales: sales@sollatek.com www.sollatek.com
The GMC5 is a ready to go smart tracking device ideal
for small to medium assets. The GMC5 uses Wi-Fi
for precise geo-location and GSM for transmitting
its location to the online portal.
There are three operational modes (stationary,
movement and post-movement) to maximise
battery life whilst ensuring you know your asset's
exact location. Transmission intervals can be fully
customised.
The GMC5 is fully sealed and IP65 rating so can be
mounted in the harshest of environments.
Installation & Operating Instructions
TECHNICAL SPECIFICATION
Battery
Battery Type
Nominal Voltage
Capacity
Expected life
Cellular Connectivity
Target Region
Antenna
Type
Category
Frequency Band
Wi-Fi Geo-location
Frequency Range
Protocol
Accelerometer
Measurement Direction
Measurement Scale
Status Indicators
LED
Environmental
IP Rating
Operating Temperature
Operating Humidity
Certifi cation / Standards
Product Certifi cation
Mechanical
Mounting 2 x self-tapping pozidriv screws or double sides adhesive pad
Unit Dimensions
Unit weight
Lithium-Thionyl Choride (Li-SOCl )
2
3.6 V
3500 mAh
Approx. 7 years (based on weekly update)
Global
Internal
2G
EDGE, GSM, GPRS
850 / 900 / 1800 / 1900
2.4 GHz
802.11 b/g/n
3-axis
±2G / ±4G / ±8G / ±16G
2 x LEDs
Green: GSM Power Status ; Red: Transmitting status
IP65 Sealed Enclosure
-20°C to +60°C (-4°F to +140°F)
<90% RH non-condensing
CE
77.6 x 49.6 x 30.0 mm
50 g
