  • Page 1 Stereo-mixer-preamplifier owners manual...
  • Page 2: Phantom Power

    CONNECTIONS All the XLR inputs and output sockets on the SC 2311 have the following pin configurations: 1 - GND, 2 - HOT (+), 3 - COLD (-). All the TRS sockets on the back panel have the following pin configurations: TIP - HOT (+), RING - COLD (-), SLEEVE - GND.
  • Page 3 PC soundcard is connected. The PC earthing may not always be proper and we strongly suggest that you use AUX2 only, for ensured system protection - page 2 - SC 2311...
  • Page 4 Fig 1: Front Panel · Fig 2: Rear Panel - page 3 - SC 2311...
  • Page 5: Troubleshooting

    (A) Check that the earth terminal of the utility AC socket is connected to the earth bus (B) Check that the earth is not shared with any other ‘noisy’ equipments like light dimmers, arc lamps etc - page 4 - SC 2311...
  • Page 6 LED power-on indicator. Protection shall be provided by a rear panel mounted glass cartridge fuse and fuse holder. The preamplifier shall be the SONODYNE model SC 2311. - page 5 -...
  • Page 7: Specifications

    230 V AC @ 50 Hz POWER CONSUMPTION 15 V A max DIMENSIONS (W x H x D) mm 483 x 44 x 168 NET WEIGHT 2.3 Kg Due to continuous improvements, specifications may change - page 6 - SC 2311...
  • Page 8 A product of Mukherjee Innovation Centre Manufactured by Sonodyne Electronics Co Pvt Ltd, 98 NB Block E New Alipore, Kolkata 700053, INDIA Tel: +91 33 23990418, 23983406; Fax: +91 33 23967243; E-mail: response@sonodyne.com Please visit us at www.sonodyne.com...
