Page 4
The content of this manual is furnished for informational use only, is subject to change without notice and should not be construed as a commitment by Kemper GmbH. Kemper GmbH assumes no responsibility or liability for any errors or inaccuracies that may appear in this book.
Wah Pedal ................................... 15 Morph Pedal ..................................16 More Fun with Pedals ..............................17 Lock Function ..................................18 Setting up KEMPER Power Kabinet.........................19 Keeping your PROFILER up to date with Rig Manager .................. 21 Documentation and Video Tutorials ........................24 Support and User Forum ............................. 25 Important Safety Instructions ...........................26...
OUTPUT (either XLR or TS) to the inputs of the receiving device. Do not forget to connect the power cable to a power outlet. The PROFILER Stage is designed for voltages between 100 and 230 Volts! Power the unit on by pressing the On/Off Button in the upper left corner of the front panel.
PROFILER STAGE QUICKSTART SWITCHING RIGS The PROFILER comes with numerous guitar amp setups, including effects. These are called “Rigs”, and the library of Rigs stored on your PROFILER is called the “Rig pool”. The BROWSE knob at the top middle of the unit is used to browse the Rig pool.
10 PROFILER STAGE QUICKSTART EDITING AND STORING RIGS You can tweak the current Rig and store any changes you want to keep – for instance, if you want to boost Treble, turn the All Rigs Sorted by Name Store Snapshot...
PROFILER STAGE QUICKSTART NOISE GATE In order to adjust the input Noise Gate intensity, press the INPUT button and adjust the corresponding soft knob below the display. INPUT Section [Page 1/2] Set the volume of your guitar all the way up and put your palm 0.0dB...
12 PROFILER STAGE QUICKSTART ADDING EFFECTS The PROFILER features eight effects modules. Four are located before the amplifier module (pre), and four are located after it (post). Modules A, B, C and D are pre amplifier and X, MOD, DLY and REV are post amplifier.
PROFILER STAGE QUICKSTART TOGGLING EFFECTS ON/OFF WITH EFFECT BUTTONS The PROFILER Stage offers four dedicated Effect Buttons (I to IIII) to activate effect modules. Each can toggle a single module or a combination of modules. To assign one of the effect modules to an Effect Button: »...
14 PROFILER STAGE QUICKSTART TUNER You can check your guitar’s tuning at any time by watching the three TUNER LEDs close to the TUNER button. Press the TUNER button to activate Tuner Mode. Enable “Mute Signal” via the corresponding soft button, if you prefer the guitar input to be muted whenever Tuner Mode is activated.
So-called “expression pedals”, which are optimized for digital devices like the PROFILER, should be used for all pedal functions. Connect your expression pedal to the PEDAL 1 input socket on the rear side of the PROFILER Stage. You will be able to control volume right away.
16 PROFILER STAGE QUICKSTART MORPH PEDAL Morphing allows you to change any number of continuous parameters like Gain level, Delay Mix or Delay Feedback simultaneously – all with a single expression pedal. Moving the pedal is equivalent to turning all those knobs at the same time to move between one sound and another.
PROFILER STAGE QUICKSTART MORE FUN WITH PEDALS Here a few tips related to linking and checking pedal controllers: Press the PEDALS button to access several pages of global settings. These are settings that don’t vary by Rig. Use the <PAGE> buttons to navigate through these pages. Locate the WahPedal >...
18 PROFILER STAGE QUICKSTART LOCK FUNCTION Certain aspects of a Rig can be locked to prevent them changing when you load another Rig. Find a Rig which features a wah effect, then select the wah while holding the LOCK button. Now, load a different Rig.
240 Volts! Turn VOLUME on the Power Kabinet all the way down. Use an instrument cable to connect the input of the KEMPER Power Kabinet with one of the MONITOR OUTPUTS on the rear side of your Instrument Cable Stage.
Page 20
Directivity More detailed information regarding the various options and settings for the KEMPER Kone can be found in the Main Manual. If you are on stage, or in a studio, you won’t require a microphone to pick up your sound, so you should connect the mixing desk to the MAIN OUTPUT XLR outs.
KEEPING YOUR PROFILER UP TO DATE WITH RIG MANAGER KEMPER Rig Manager™ is a free software companion for your PROFILER. The application helps you to: » Get access to more than 17,000 free Rigs and dozens of additional high-quality Rig packs.
Page 22
22 PROFILER STAGE QUICKSTART » Make sure you register your PROFILER at the same time, as this way you get access to software updates and more. You need the serial number to register, which can be found on a sticker on the underside of the product.
Page 23
Be aware that this reformatting will delete all data from the memory stick! » Point your internet browser to: www.kemper-amps.com/start, choose “Updates”, proceed to the downloads section and select the category “Operating System Updates”. Download the update and open the archive. Copy the file “kaos.bin”...
24 PROFILER STAGE QUICKSTART For any critical application we recommend using the latest release version. The Main Manual contains more about the advantages and disadvantages of software beta versions. DOCUMENTATION AND VIDEO TUTORIALS We hope you will find operating the PROFILER straightforward, but if you need more information please check out our manuals.
PROFILER STAGE QUICKSTART SUPPORT AND USER FORUM Even though we do our best to address everything you need to know in these manuals and videos, we would like to invite you to contact our support team at any time using the contact form on our website: www.kemper-amps.com/contact...
26 PROFILER STAGE QUICKSTART IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. » Do not use this apparatus near water. Clean only with dry cloth. » Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
PROFILER STAGE QUICKSTART » Do not operate the apparatus below 5° C (41° F) or above 45° C (113° F). Avoid using the apparatus in direct sunlight. » Always use the correct AC line voltage. Refer to the information at the power socket.
28 PROFILER STAGE QUICKSTART COMPLIANCE STATEMENT KEMPER PROFILER Stage complies with the following standards regulating interference and EMC: FCC Verification procedure – 47CFR §15.107+109 and contains FCC ID: 2AC7Z-ESPWROOM02. This device contains SRRC approved radio module CMIIT ID 6DP3252 Other Class B digital devices and peripherals:...
Page 29
Nosotros, Kemper GmbH, Königswall 16-18, 45657 Recklinghausen Alemania, Tel: +49 (0) 2361 970970, declaramos bajo nuestra exclusiva responsabilidad que el producto PROFILER Stage cumple con la Parte 15 de las Reglas de la FCC. La etapa Profiler contiene FCC ID: 2AC7Z-ESPWROOM02.
Page 32
Lizenzvertrag. Diese Vertragsbestimmungen wurden bei der Erstellung dieses Handbuchs eingehalten. Der Inhalt dieses Handbuchs ist rein informell und kann zu jeder Zeit, ohne Vorankündigung von der Kemper GmbH geändert werden. Die Kemper GmbH haftet nicht für inhaltliche Fehler. Ohne schriftliche Genehmigung der Kemper GmbH ist es nicht zulässig, diese Publikation oder Teile davon zu reproduzieren und/oder in schriftlicher- und/oder elektroni-...
Page 33
Wah-Pedal ..................................43 Morph-Pedal ..................................44 Noch mehr Spass mit Pedalen ..........................45 Lock-Funktion ................................. 46 Anschliessen eines KEMPER Power Kabinets ....................47 Den PROFILER mit Rig Manager auf dem neusten Stand halten .............49 Dokumentation und Video-Tutorials ........................52 Support und User-Forum ............................53 Wichtige Sicherheitshinweise ............................54...
WAS IST EIGENTLICH EIN PROFILER? Zuerst einmal vielen Dank, dass Sie sich für das KEMPER PROFILER Stage™ entschieden haben. Wir sind sicher, dass Sie genauso begeistert sein werden wie wir, sobald Sie herausfinden, was dieses Gerät leisten kann. Unser Ziel war es, mit dem PROFILER einen Verstärker auf den Markt zu bringen, der sämtliche Bedürfnisse von Gitarristen erfüllt...
TS-Klinkenkabeln mit den Eingängen des betreffenden Gerätes. Vergessen Sie nicht das Netzkabel mit einer Steckdose zu verbin- den. Der PROFILER Stage ist für Netzspannungen zwischen 100 und 230 Volt ausgelegt. Schalten Sie das Gerät mit dem Taster in der linken oberen Ecke ein.
PROFILER STAGE QUICKSTART RIGS WECHSELN Der PROFILER wird mit einer Menge Gitarrenverstärker-Profilen ausgeliefert. Einen Sound bestehend aus einem Verstärkerprofil plus Effekten nennen wir „Rig“. Die Gesamtheit aller Rigs, die auf Ihrem PROFILER gespeichert sind, bezeichnen wir als den „Rig Pool“.
38 PROFILER STAGE QUICKSTART RIGS VERÄNDERN UND SPEICHERN Sie können das gerade geladene Rig vielfältig verändern und Ihre eigenen Fassungen davon abspeichern. Wenn Sie z. B. die Höhen All Rigs Sorted by Name Store Snapshot Nitro 2015 A LOOP Nitro 2015 B FastRedPonyCar etwas anheben möchten, drehen Sie unter dem Display den Regler...
PROFILER STAGE QUICKSTART NOISE GATE Um die Intensität des Noise Gates einzustellen, drücken Sie den INPUT-Taster und justieren den betreffenden Soft-Regler unter dem Display. INPUT Section [Page 1/2] 0.0dB 0.0dB Front Input Noise Gate Clean Sense Distortion Sense Input Source Intensity Drehen Sie die Lautstärke an Ihrer Gitarre bis zum Anschlag auf...
40 PROFILER STAGE QUICKSTART EFFEKTE HINZUFÜGEN Der PROFILER verfügt über acht Effektmodule. Vier befinden sich vor dem Verstärkermodul und vier weitere dahinter. Die Module vor dem Verstärker werden als A, B, C und D bezeichnet. Die Module hinter dem Verstärker heißen X, MOD, DLY und REV.
PROFILER STAGE QUICKSTART AN- UND ABSCHALTEN VON EFFEKTEN MITTELS DER FUSSTASTER Der PROFILER Stage besitzt vier spezielle Fußtaster bezeichnet mit „I“ bis „IIII“, um Effektmodule ein- und auszuschalten. Jeder einzelne dieser vier Effekttaster kann gleichzeitig eine Kombination von Effektmodulen schalten.
42 PROFILER STAGE QUICKSTART TUNER Sie können die Stimmung Ihrer Gitarre jederzeit anhand der drei TUNER-LEDs in der Nähe des TUNER-Tasters kontrollieren. Drücken Sie den TUNER-Taster, um den Tuner-Modus zu aktivieren. Mit der Option „Mute Signal“ können Sie bestimmen, ob das Gitar- rensignal stummgeschaltet werden soll, solange der Tuner-Modus aktiviert ist.
Dieser Automatismus lässt sich im Tuner-Modus abschalten. WAH-PEDAL Verbinden Sie das Expression-Pedal mit dem Anschluss „PEDAL 2“ am PROFILER Stage. Ab jetzt steuert das Pedal Effekte, wie z.B. Wah-Effekte, die Tonhöhe von Pedal-Pitch-Effekten sowie Morphing. Was Morphing ist, erklären wir im nächsten Abschnitt.
44 PROFILER STAGE QUICKSTART MORPH-PEDAL Mit Morphing kann man eine ganze Reihe kontinuierlicher Parameter wie z. B. Gain, Delay Mix oder Delay Feedback gleichzeitig verändern – mittels eines einzigen Expression-Pedals. Indem man das Pedal bewegt, verändern sich alle diese Regler gleichzeitig zwischen dem Basis-Sound und dem sogenannten Morph-Sound. Hier ein einfaches...
PROFILER STAGE QUICKSTART NOCH MEHR SPASS MIT PEDALEN Hier noch ein paar Tipps zum Verlinken und der Prüfung der Pedal-Controller: Drücken Sie auf die Taste, die mit „PEDALS“ bezeichnet ist. Es öffnet sich ein Menü mit mehreren Seiten globaler Einstellungen.
46 PROFILER STAGE QUICKSTART LOCK-FUNKTION Einige Bereiche eines Rigs können gesperrt werden, sodass sie beim Laden eines anderen Rigs erhalten bleiben. Laden Sie z. B. irgendein Rig mit einem Wah-Effekt. Öffnen Sie den Wah-Effekt und halten Sie gleichzeitig den LOCK-Taster. Wenn Sie jetzt andere Rigs laden, werden Sie feststellen, dass der Wah-Effekt immer an seiner Position erhalten bleibt.
ANSCHLIESSEN EINES KEMPER POWER KABINETS Verbinden Sie Ihr KEMPER Power Kabinet mittels des mitgelieferten Netzkabels mit einer Steckdose. Das KEMPER Power Kabinet ist für Netzspannungen zwischen 100 und 240 Volt ausgelegt! Regeln Sie VOLUME am Power Kabinet kom- plett zurück.
Page 48
48 PROFILER STAGE QUICKSTART Drücken Sie den OUTPUT-Taster am Stage. Navigieren Sie mit den <PAGE>-Tastern zur Seite „KEMPER Kone“ und aktivieren Sie dort die Option „KEMPER Kone“ mit dem Kemper Kone Monitor Stereo Monitor Cab O Bass Boost entsprechenden Soft-Taster über dem Display.
Anschließend gibt es zwei alternative Verfahren, Ihren PROFILER zu aktualisieren. Falls ein Computer mit Internetzugang in der Nähe ist, können Sie KEMPER Rig Manager™ verwenden, um Ihren PROFILER auf dem neusten Stand zu halten. In allen anderen Situationen kopieren Sie das Update auf einen USB-Stick und stecken diesen dann in die entsprechende USB-Buchse am PROFILER.
Page 50
50 PROFILER STAGE QUICKSTART » Klicken Sie auf „Not a member yet? Sign Up“ und geben Sie die erforderlichen Daten ein. » Registrieren Sie bei der Gelegenheit am besten gleich Ihren PROFILER. Dadurch erhalten Sie u. a. Zugriff auf Software-Updates. Zur Registrierung müssen Sie die Seriennummer des Geräte eingeben, die Sie auf einem Auf- kleber auf dem Gehäuseboden finden.
Page 51
PROFILER STAGE QUICKSTART Sie in Ihrem Benutzerkonto hinterlegt haben. Nutzen Sie die Option „Test your Login Credentials”, um zu prüfen, ob Rig Manager auf Ihr Benutzerkonto zugreifen kann. SOFTWARE-UPDATE VIA RIG MANAGER Um Ihren PROFILER auf den neusten Stand zu bringen, müssen Sie ihn nur wie abgebildet mittels eines USB-Kabels mit Ihrem Compu- ter verbinden.
52 PROFILER STAGE QUICKSTART » Richten Sie Ihren Internet Browser auf: www.kemper-amps.com/start, wählen Sie die Option „Updates“. Im Download-Bereich wählen Sie die Kategorie „Operating System Updates“ aus. Laden Sie das Update-Archiv herunter und öffnen Sie es anschließend. Kopieren Sie die Datei „kaos.bin” aus dem Archiv in den Ordner „OS Updates“...
PROFILER STAGE QUICKSTART SUPPORT UND USER-FORUM Obwohl wir uns mit diesen Handbüchern und den Video-Tutorials größte Mühe geben, können Sie sich jederzeit an unser Support-Team wenden, indem Sie das Kontaktformular auf unserer Web-Seite ausfüllen: www.kemper-amps.com/contact Diejenigen, die Ihre Fragen und Anregungen gerne mit anderen Anwendern austauschen möchten, sind herzlich ein- geladen, sich aktiv an unserem User-Forum zu beteiligen: www.kemper-amps.com/forum...
54 PROFILER STAGE QUICKSTART WICHTIGE SICHERHEITSHINWEISE Bitte lesen Sie die Sicherheitshinweise. Behalten Sie die Sicherheitshinweise auf. Folgen Sie allen Hinweisen. » Verwenden Sie dieses Gerät niemals in der Nähe von Wasser. Reinigen Sie das Gehäuse nur mit einem trockenen Tuch.
Sonneneinstrahlung aus. » Betreiben Sie das Gerät ausschließlich mit der passenden Netzspannung, die neben dem Netzanschluß des Gerä- tes angegeben ist. » Das Gerät darf nicht technisch verändert werden. Ansonsten erlöschen Garantie und Haftung der Kemper GmbH. TECHNISCHE ANFORDERUNGEN Netzspannung: »...
56 PROFILER STAGE QUICKSTART ERKLÄRUNG ZUR EINHALTUNG VON BESTIMMUNGEN Dieses Gerät, der KEMPER PROFILER Stage™, erfüllt folgende Auflagen im Zusammenhang mit Einstreuungen und elektromagnetischer Kompatibilität: Verfahren für den FCC-Nachweis – 47CFR §15.107+109 und enthält FCC ID 2AC7Z-ESPWROOM02.. Das Gerät enthält das SRRC freigegebene Radio Modul: CMIIT ID 6DP3252 Andere Class B digital devices und Zubehör:...
Page 57
Das Produkt erfüllt die Anforderungen von IEC 60950-1:2005 (2. Ausgabe); Am 1:2009 KONFORMITÄTSERKLÄRUNG Hiermit erklärt die Kemper GmbH, Königswall 16-18, 45657 Recklinghausen, Deutschland, Tel: +49 (0) 2361 970970, in alleiniger Verantwortung, dass das Produkt PROFILER Stage übereinstimmt mit Teil 15 der amerikanischen FCC- Be- stimmungen.
Page 58
58 PROFILER STAGE QUICKSTART trotzdem Interferenzen auftreten können. Sollte dieses Gerät schädliche Interferenzen erzeugen und dadurch den Rundfunk- und Fernsehempfang stören (was man sehr leicht nachprüfen kann, indem man das Gerät bei Störungen aus- und wieder einschaltet), kann der Anwender die Interferenzen mit einem der folgenden Verfahren beseitigen: Richten Sie ihre Empfangsantenne anders aus oder stellen Sie sie an einen anderen Ort.
Page 60
Kemper GmbH. Kemper GmbH no asume ninguna responsabilidad por cualquier error o imprecisión que pueda aparecer en este documento. Exceptuando los límites indicados en esta misma licencia, ninguna parte de esta publicación puede reproducirse, almacenarse en un sistema de recuperación ni transmitirse en cualquier forma o por cualquier medio,...
Page 61
Pedal Morph ..................................72 Más diversión con los pedales ........................... 73 Función Lock ..................................74 Configuración del KEMPER Power Kabinet ......................75 Mantener tu PROFILER actualizado con Rig Manager .................. 77 Documentación y tutoriales en vídeo ........................80 Atención al cliente y foro de usuarios ........................81 Instrucciones de seguridad importantes ......................82...
VALE, ¿QUÉ ES LO QUE HE COMPRADO? En primer lugar, gracias por elegir el KEMPER PROFILER Stage™. No nos cabe duda de que, cuando te des cuenta de todo lo que puede hacer, te encantará tanto como a nosotros. Nuestro principal objetivo es ofrecer una solución completa para las necesidades de los guitarristas, y por ello hemos decidido que no quedes limitado a un grupo predefinido de modelos digitales de amplificador.
MAIN OUTPUT (ya sean XLR o TS) a las entradas del dispositivo receptor. No olvides conectar el cable de alimentación a una toma de corriente. El PROFILER Stage está diseñado para tensiones desde 100V hasta 230V. Enciende el dispositivo pulsando el botón de encendido/apagado en la esquina superior izquierda del panel frontal.
PROFILER STAGE – INICIO RÁPIDO CAMBIAR DE RIG El PROFILER incluye numerosas configuraciones de amplificador de guitarra, incluyendo efectos. Se conocen con el nombre de “Rigs”, y la biblioteca de Rigs almacenada en tu PROFILER se llama “Rig Pool”. El mando BROWSE de la parte superior central del equipo se utiliza para navegar por el Rig Pool.
66 PROFILER STAGE – INICIO RÁPIDO EDITAR Y ALMACENAR RIGS Puedes modificar el Rig actual y almacenar los cambios que deseas conservar. Por ejemplo, si deseas aumentar los agudos, gira All Rigs Sorted by Name Store Snapshot Nitro 2015 A...
PROFILER STAGE – INICIO RÁPIDO NOISE GATE Para ajustar la intensidad de la puerta de ruido de entrada, pulsa el botón INPUT y ajusta el mando programable correspondiente situado debajo de la pantalla. INPUT Section [Page 1/2] 0.0dB 0.0dB Front Input...
68 PROFILER STAGE – INICIO RÁPIDO AÑADIR EFECTOS El PROFILER cuenta con ocho módulos de efectos. Cuatro de ellos están situados antes del módulo amplificador (pre) y cuatro después de él (post). Los módulos A, B, C y D son pre amplificador, mientras que X, MOD, DLY y REV son post amplificador.
ACTIVAR/DESACTIVAR EFECTOS CON LOS CONMUTADORES DE PEDAL DE EFECTOS El PROFILER Stage ofrece cuatro conmutadores de pedal de efecto específicos (I~IIII) para activar los módulos de efecto. Cada uno de ellos puede alternar un solo módulo o una combinación de módulos.
70 PROFILER STAGE – INICIO RÁPIDO AFINADOR Puedes comprobar la afinación de tu guitarra en cualquier momento mirando los tres LED TUNER situados cerca del conmutador de pedal TUNER. Pulsa el conmutador de pedal TUNER para activar el Modo afinador.
PEDAL DE WAH Conecta el pedal de expresión a la entrada PEDAL 2 de tu PROFILER Stage. A partir de ahora, este pedal controlará la expresión de un efecto. Por ejemplo, la posición de tu efecto wah o el tono de los efectos de cambio de tono. Este pedal también se puede usar para controlar el Morphing, del cual hablaremos en el párrafo siguiente.
72 PROFILER STAGE – INICIO RÁPIDO PEDAL MORPH El Morphing te permite cambiar simultáneamente cualquier número de parámetros continuos, como el nivel de ganancia, la mezcla de delay o el feedback de delay, con un único pedal de expresión. Mover el pedal equivale a girar todos esos mandos al mismo tiempo para pasar de un sonido a otro.
PROFILER STAGE – INICIO RÁPIDO MÁS DIVERSIÓN CON LOS PEDALES Estos son algunos consejos relacionados con el enlace y la comprobación de los controladores de pedal: Pulsa el botón PEDALS para acceder a varias páginas de los ajustes globales. Estos ajustes no varían según el Rig. Utiliza los botones <PAGE>...
74 PROFILER STAGE – INICIO RÁPIDO FUNCIÓN LOCK Ciertos aspectos de un Rig pueden bloquearse para evitar que cambien cuando cargues otro Rig. Encuentra un Rig que disponga de un efecto de wah y selecciona el wah manteniendo pulsado el botón LOCK.
100V hasta 240V. Gira VOLUME en el Power Kabinet al mínimo. Usa un cable de instrumento para conectar la entrada del KEMPER Power Kabinet a uno de los conectores MONITOR OUTPUTS de la Instrument Cable parte posterior del Stage.
Page 76
76 PROFILER STAGE – INICIO RÁPIDO Pulsa el botón OUTPUT en tu PROFILER Stage. Utiliza los botones <PAGE> para navegar hasta la página “Kemper Kone” y activa “Kemper Kone” con el correspondiente botón Kemper Kone Monitor Stereo Monitor Cab O Bass Boost programable situado encima de la pantalla.
CON RIG MANAGER KEMPER Rig Manager™ es un software gratuito que es el complemento ideal de tu PROFILER. La aplicación te ayuda a: » Obtener acceso a más de 17.000 Rigs gratuitos y a decenas de Packs de Rigs adicionales de alta calidad.
Page 78
78 PROFILER STAGE – INICIO RÁPIDO » Registra siempre tu PROFILER al mismo tiempo para obtener acceso a actualizaciones de software y mucho más. Para registrarte necesitarás el número de serie impreso en un adhesivo pegado en la parte inferior del producto.
Page 79
Debes tener presente que el formateo elimina todos los datos de la unidad de memoria. » Desde el navegador de Internet, visita: www.kemper-amps.com/start, selecciona “Updates”, visita la sección de descargas y selecciona la categoría “Operating System Updates”. Descarga la actualización y abre el archivo comprimido.
80 PROFILER STAGE – INICIO RÁPIDO Para cualquier aplicación importante, recomendamos utilizar la última versión publicada. En el Manual principal encontrarás más información acerca de las ventajas y desventajas de las versiones beta del software. DOCUMENTACIÓN Y TUTORIALES EN VÍDEO Esperamos que puedas empezar a utilizar tu PROFILER sin más problemas, pero si necesitas más información,...
PROFILER STAGE – INICIO RÁPIDO ATENCIÓN AL CLIENTE Y FORO DE USUARIOS A pesar de todos nuestros esfuerzos por tratar la mayoría de los temas en estos manuales y en los vídeos, no dudes en ponerte en contacto con nuestro equipo de atención al cliente mediante el formulario de contacto que encontrarás en nuestro sitio web:...
82 PROFILER STAGE – INICIO RÁPIDO INSTRUCCIONES DE SEGURIDAD IMPORTANTES Lee estas instrucciones. Conserva estas instrucciones. Ten en cuenta todas las advertencias. Sigue todas las instrucciones. » No utilices este equipo cerca del agua. Límpialo únicamente con un paño seco.
PROFILER STAGE – INICIO RÁPIDO » El equipo debe conectarse a una toma de corriente debidamente conectada a tierra. Comprueba que, bajo cualquier circunstancia, puedas acceder fácilmente al enchufe de corriente. » El equipo no puede utilizarse al aire libre.
84 PROFILER STAGE – INICIO RÁPIDO DECLARACIÓN DE CONFORMIDAD KEMPER PROFILER Stage cumple con los siguientes estándares que regulan la interferencia y EMC: Procedimiento de verificación FCC - 47CFR §15.107 + 109 y contiene FCC ID: 2AC7Z-ESPWROOM02. Este dispositivo contiene un módulo de radio aprobado por SRRC CMIIT ID 6DP3252 Otros dispositivos y periféricos digitales de Clase B:...
Page 85
Nosotros, Kemper GmbH, Königswall 16-18, 45657 Recklinghausen Alemania, Tel.: +49 (0) 2361 970970, declaramos bajo nuestra exclusiva responsabilidad que el producto PROFILER Stage cumple con el Apartado 15 de las Reglas de la FCC. El funcionamiento está sujeto a las dos condiciones siguientes: (1) este dispositivo no puede ocasionar interferencias perjudiciales.
Page 87
PROFILER STAGE PRISE EN MAIN EN FRANÇAIS...
Page 88
Remote™, PROFILER Stage™, KEMPER Kone™, KEMPER Kabinet™, KEMPER Power Kabinet™, KEMPER Rig Exchange™, KEMPER Rig Manager™, PURE CABINET™ et CabDriver™ sont des marques commerciales de Kemper GmbH. Toutes les fonctions et caractéristiques techniques sont susceptibles d’être modifiées sans préavis. (Rév. Février 2021).
Page 89
PROFILER STAGE – PRISE EN MAIN SOMMAIRE Bon, qu’est-ce que je viens d’acheter? ........................91 Prise en main ..................................91 Connexions ..................................92 Changer de Rig ................................93 Editer et sauvegarder des Rigs..........................94 Noise Gate ..................................95 Ajouter des effets ................................96 Activer/couper des effets avec les commutateurs d’effet ................97 Accordeur ...................................98...
BON, QU’EST-CE QUE JE VIENS D’ACHETER? Avant tout, merci d’avoir choisi le KEMPER PROFILER Stage™. Nous sommes certains qu’une fois que vous aurez réalisé tout ce qu’il peut faire, vous partagerez notre enthousiasme. Notre objectif ultime est de fournir une solution intégrale répondant à...
MAIN OUTPUT (XLR ou TS) aux entrées du dispositif récepteur. N’oubliez pas de brancher le câble d’alimentation à une prise secteur. Le PROFILER Stage est conçu pour des tensions comprises entre 100V et 230V! Mettez l’appareil sous tension en appuyant sur l’interrupteur situé...
PROFILER STAGE – PRISE EN MAIN CHANGER DE RIG Le PROFILER propose de nombreuses configurations d’ampli et d’effets de guitare. Elles sont appelées “Rigs” et la bibliothèque des Rigs sauvegardés dans le PROFILER est appelée “Rig Pool”. La commande BROWSE au centre de la façade permet de naviguer au sein du Rig Pool.
94 PROFILER STAGE – PRISE EN MAIN EDITER ET SAUVEGARDER DES RIGS Vous pouvez modifier le Rig sélectionné et sauvegarder vos changements. Si, par exemple, vous souhaitez accentuer l’aigu, All Rigs Sorted by Name Store Snapshot Nitro 2015 A LOOP...
PROFILER STAGE – PRISE EN MAIN NOISE GATE Pour régler l’intensité du Noise Gate, appuyez sur le bouton INPUT et réglez la commande correspondante, située sous l’écran. INPUT Section [Page 1/2] Réglez le volume de la guitare à fond et placez la paume de la main 0.0dB...
96 PROFILER STAGE – PRISE EN MAIN AJOUTER DES EFFETS Le PROFILER dispose de huit modules d’effets. Quatre sont situés avant le module d’amplificateur (pre) et quatre après (post). Les modules A, B, C et D sont avant l’ampli et les modules X, MOD, DLY et REV après l’ampli.
PROFILER STAGE – PRISE EN MAIN ACTIVER/COUPER DES EFFETS AVEC LES COMMUTATEURS D’EFFET Le PROFILER Stage propose quatre commutateurs d’effet dédiés (I~IIII) pour activer/couper les modules d’effet. Chacun d’entre eux peut commuter un module ou une combinaison de modules. Pour assigner un des modules d’effet à un commutateur d’effet: »...
98 PROFILER STAGE – PRISE EN MAIN ACCORDEUR Vous pouvez vérifier l’accord de la guitare à tout instant en regardant les trois LED TUNER près du commutateur au pied TUNER. Appuyez sur le commutateur TUNER pour passer en mode d’accordage.
Pour piloter les fonctions avec pédale, utilisez des pédales dites d’“expression” optimisées pour des dispositifs numériques comme le PROFILER. Branchez la pédale d’expression à l’entrée PEDAL1 en face arrière du PROFILER Stage. Vous pouvez régler le volume directement. La fonction de la pédale d’expression peut varier selon le Rig choisi (et être placée avant ou après l’ampli, par exemple).
100 PROFILER STAGE – PRISE EN MAIN PÉDALE MORPH Le Morphing vous permet de changer simultanément plusieurs paramètres continus comme le gain, le mix du delay ou le feedback du delay – le tout avec une seule pédale d’expression. Actionner la pédale revient à tourner toutes ces commandes simultanément pour passer d’un son à...
PROFILER STAGE – PRISE EN MAIN JOUER AVEC LES PÉDALES Voici quelques astuces concernant les liens et la vérification des pédales: Appuyez sur le bouton PEDALS pour accéder à plusieurs pages de réglages globaux. Ces réglages ne dépendent pas des Rigs. Utilisez les boutons <PAGE>...
102 PROFILER STAGE – PRISE EN MAIN FONCTION LOCK Certains aspects d’un Rig peuvent être verrouillés (“locked”) pour éviter qu’ils ne changent lorsque vous chargez un autre Rig. Sélectionnez un Rig contenant un effet wah puis sélectionnez le wah tout en maintenant le bouton LOCK enfoncé. Chargez ensuite un Rig différent.
100V et 240V! Réglez la commande VOLUME du Power Kabinet au minimum. Utilisez un câble d’instrument pour brancher l’entrée du KEMPER Power Kabinet à une des prises MONITOR OUTPUTS à l’arrière du Stage. Instrument Cable Mettez le Kabinet sous tension et augmentez doucement le réglage VOLUME sur le Power...
Page 104
Monitor Volume Imprint Select Directivity Pour en savoir plus sur les options et réglages du KEMPER Kone, voyez le manuel principal. Si vous êtes sur scène ou au studio, vous n’aurez pas besoin de micro pour capter le son. Branchez donc les sorties XLR MAIN OUTPUT à...
MAINTENIR LE PROFILER À JOUR AVEC ‘RIG MANAGER’ “KEMPER Rig Manager™” est un logiciel gratuit pour le PROFILER. Cette application permet d’effectuer ce qui suit: » Accéder à plus de 17.000 Rigs gratuits et à des dizaines de Rigs Packs supplémentaires d’excellente qualité.
Page 106
106 PROFILER STAGE – PRISE EN MAIN » Cliquez sur “Not a member yet? Sign Up” et remplissez le formulaire. » N’oubliez pas d’enregistrer votre PROFILER par la même occasion pour accéder aux mises à jour etc. Pour l’enregistrement, vous avez besoin du numéro de série qui se trouve sur un autocollant sous le produit.
Page 107
Confirmez l’opération avec “Yes” et suivez les instructions affichées. Sachez que ce formatage supprime toutes les données de la clé! » Rendez-vous à la page www.kemper-amps.com/start, choisissez “Updates” puis passez à la section de téléchargement et sélectionnez la catégorie “Operating System Updates”. Téléchargez la mise à jour et ouvrez l’archive.
108 PROFILER STAGE – PRISE EN MAIN Pour toute utilisation critique, nous vous conseillons d’utiliser la version la plus récente du système. Le manuel principal vous en apprendra plus sur les avantages et les inconvénients des versions bêta des logiciels.
PROFILER STAGE – PRISE EN MAIN ASSISTANCE ET FORUM D’UTILISATEURS Bien que nous fassions de notre mieux pour vous proposer une documentation aussi complète que possible, n’hésitez pas à contacter notre service d’assistance en utilisant le formulaire de contact sur notre site web: www.kemper-amps.com/contact...
110 PROFILER STAGE – PRISE EN MAIN CONSIGNES IMPORTANTES DE SÉCURITÉ Lisez ces consignes. Conservez ces consignes. Tenez compte de tous les avertissements. Suivez toutes les instructions. » N’utilisez pas le produit à proximité d’eau. Nettoyez-le avec un chiffon sec uniquement.
PROFILER STAGE – PRISE EN MAIN » Cet appareil n’est pas conçu pour un usage à l’extérieur. » Ce dispositif ne peut être utilisé que sur le sol ou sur une table. » Ne l’utilisez pas à des températures inférieures à 5°C ou supérieures à 45°C. Evitez d’utiliser le dispositif en plein soleil.
112 PROFILER STAGE – PRISE EN MAIN DÉCLARATION DE CONFORMITÉ KEMPER PROFILER Stage est conforme aux normes suivantes régissant les interférences et la CEM: Procédure de vérification FCC - 47CFR §15.107 + 109 et contient l’ID FCC: 2AC7Z-ESPWROOM02. Cet appareil contient un module radio approuvé par SRRC CMIIT ID 6DP3252 Autres appareils et périphériques numériques de classe B: EN 55032 + EN55035...
Page 113
DÉCLARATION DE CONFORMITÉ Nous, Kemper GmbH, Königswall 16-18, 45657 Recklinghausen Allemagne, Tél: +49 (0) 2361 970970, déclarons sous notre seule responsabilité que le produit PROFILER Stage est conforme à la partie 15 des règles FCC. L’étape Profiler contient l’ID FCC: 2AC7Z-ESPWROOM02.
Page 115
PROFILER STAGE GUIDA VELOCE IN ITALIANO...
Page 116
è soggetto a modifiche senza preavviso e non deve essere considerato vincolante per Kemper GmbH. Kemper GmbH non si assume nessuna responsabilità per la presenza di eventuali errori o imprecisioni in questo manuale. Ad eccezione di quanto consentito da tale licenza, nessuna parte di questa pubblicazione può essere...
Page 117
PROFILER STAGE – GUIDA VELOCE SOMMARIO Okay, ma cosa ho appena comperato? ........................ 119 Per Iniziare ..................................119 I Collegamenti ................................. 120 Cambiare i Rig ..................................121 Modificare e Memorizzare i Rig ..........................122 Noise Gate ..................................123 Aggiungere Effetti ................................ 124 Attivare/Disattivare gli Effetti con i pedali degli Effetti ................125...
è il motivo per cui non vi limitiamo alla scelta di una serie predefinita di modelli digitali di amplificatori. Ed il risultato è che KEMPER™ ha creato il primo ampli digitale per chitarra che vi permette di creare un PROFILE™...
MAIN OUTPUT (o XLR o TS). Non dimenticate di collegare il cavo di alimentazione ad una presa elettrica. Il PROFILER Stage è progettato per essere alimentato da tensioni comprese tra 100V e 230V! Accendete lo strumento premendo il Pulsante di Accensione che si trova in alto a sinistra sul pannello frontale.
PROFILER STAGE – GUIDA VELOCE CAMBIARE I RIG Il PROFILER dispone di numerosi setup di ampli per chitarra, completi di effetti. Vengono denominati “Rigs” e la libreria di Rig memorizzata nel vostro PROFILER viene chiamata “Rig Pool”. La manopola BROWSE in alto al centro dello strumento serve per navigare nel Rig pool.
122 PROFILER STAGE – GUIDA VELOCE MODIFICARE E MEMORIZZARE I RIG Potete modificare il Rig attuale e memorizzare ciò che volete conservare. Per esempio, se volete aumentare il Treble, ruotate il All Rigs Sorted by Name Store Snapshot Nitro 2015 A...
PROFILER STAGE – GUIDA VELOCE NOISE GATE Per regolare l’intervento del Noise Gate, premete il pulsante INPUT e regolate il controllo software corrispondente che trovate sotto allo schermo. INPUT Section [Page 1/2] 0.0dB 0.0dB Front Input Noise Gate Clean Sense...
124 PROFILER STAGE – GUIDA VELOCE AGGIUNGERE EFFETTI Il PROFILER dispone di otto moduli di effetti. Quattro sono posizionati prima del modulo dell’amplificatore (pre) e quattro dopo (post). I moduli A, B, C e D sono pre amplificatore e X, MOD, DLY e REV sono post amplificatore.
PROFILER STAGE – GUIDA VELOCE ATTIVARE/DISATTIVARE GLI EFFETTI CON I PEDALI DEGLI EFFETTI Il PROFILER Stage dispone di quattro pedali Effetti ((I~IIII)) dedicati, che servono per attivare i moduli degli effetti. Ognuno può commutare un singolo modulo o una combinazione di moduli.
126 PROFILER STAGE – GUIDA VELOCE ACCORDATORE Potete controllare l’accordatura della vostra chitarra in qualsiasi momento guardando i tre LED TUNER che si trovano vicino al pedale TUNER. Premete l’interruttore a pedale TUNER per attivare la Modalità Tuner (Accordatore). Se preferite che la chitarra venga silenziata quando entrate in...
Per tutte le funzioni dei pedali dovreste utilizzare i cosiddetti “pedali di espressione”, che sono ottimizzati per dispositivi digitali come il PROFILER. Collegate il vostro pedale di espressione al connettore PEDAL1 che si trova nel retro del PROFILER Stage. Potete controllare il volume già da subito.
128 PROFILER STAGE – GUIDA VELOCE PEDALE MORPH Il Morphing vi permette di cambiare simultaneamente tutti i parametri continui che volete, come livello del Gain, Delay Mix o Delay Feedback – tutti con un solo pedale di espressione. Muovere il pedale equivale a ruotare tutti i controlli insieme, per passare da un suono ad un altro.
PROFILER STAGE – GUIDA VELOCE DIVERTIRSI CON I PEDALI Ecco alcuni consigli per collegare e verificare i controlli dei pedali: Premete il pulsante PEDALS per accedere a svariate pagine delle global setting (impostazioni generali). Queste sono impostazioni comuni per tutti i Rig. Usate i pulsanti <PAGE> per scorrere tra WahPedal >...
130 PROFILER STAGE – GUIDA VELOCE FUNZIONE LOCK Certi aspetti di un Rig possono essere bloccati per evitare che cambino quando caricate un altro Rig. Trovate un Rig che contenga un effetto wah, poi selezionate il wah mentre tenete premuto il pulsante LOCK. Ora, caricate un Rig diverso. Come potete vedere, il wah rimane nella stessa esatta posizione.
PROFILER STAGE – GUIDA VELOCE IMPOSTAZIONI KEMPER POWER KABINET Con il cavo di alimentazione fornito collegate il KEMPER Power Kabinet™ ad una presa di corrente. Il Power Kabinet è progettato per essere alimentato con tensioni comprese tra 100V e 240V! Abbassate completamente il VOLUME del Power Kabinet.
Page 132
132 PROFILER STAGE – GUIDA VELOCE Premete il pulsante OUTPUT sul vostro PROFILER Stage. Con i pulsanti <PAGE> andate alla pagina “Kemper Kone” e poi attivate “Kemper Kone” con il pulsante software corrispondente Kemper Kone Monitor Stereo Monitor Cab O Bass Boost che trovate sopra lo schermo.
TENERE AGGIORNATO IL VOSTRO PROFILER CON RIG MANAGER KEMPER Rig Manager™ è un software gratuito, partner del vostro PROFILER. L’applicazione vi aiuta a: » Accedere a più di 17.000 Rig gratuiti e dozzine di ulteriori Rig Pack di alta qualità.
Page 134
134 PROFILER STAGE – GUIDA VELOCE » Intanto assicuratevi di registrare il vostro PROFILER, così potrete avere accesso agli aggiornamenti del software e ad altro ancora. Per registrarlo avete bisogno del numero seriale, che potete trovare su un adesivo sotto al prodotto.
Page 135
USB stick needs to be formatted”. Confermate il dialogo premendo “Yes” e seguite le istruzioni sullo schermo. Ricordate che formattando cancellerete tutti i dati dalla chiavetta di memoria! » Con il vostro browser internet accedete al sito: www.kemper-amps.com/start, scegliete “Updates”, andate alla sezione dei download e scegliete la categoria “Operating System Updates”. Scaricate l’aggiornamento e decomprimete il file.
136 PROFILER STAGE – GUIDA VELOCE » Inserite la chiavetta USB nel vostro PROFILER e subito dopo apparirà un dialogo di aggiornamento. Confermate l’aggiornamento e seguite le istruzioni sullo schermo. Per qualsiasi situazione critica vi consigliamo di usare l’ultima versione ufficiale del software. Il Manuale Principale contiene informazioni più...
PROFILER STAGE – GUIDA VELOCE SUPPORTO E FORUM DEGLI UTENTI Anche se facciamo del nostro meglio per spiegare in questi manuali e nei video tutto ciò che dovete sapere, vi invitiamo a contattare in qualsiasi momento il nostro personale di supporto tramite il modulo di contatto che trovate sul nostro sito web: www.kemper-amps.com/contact...
138 PROFILER STAGE – GUIDA VELOCE ISTRUZIONI IMPORTANTI PER LA SICUREZZA Leggete queste istruzioni. Conservate queste istruzioni. Prestate attenzione a tutti gli avvertimenti. Seguite tutte le istruzioni. » Non utilizzate questo strumento vicino all’acqua. Pulitelo solo con un panno asciutto.
PROFILER STAGE – GUIDA VELOCE » L’apparecchio non è adatto ad un utilizzo all’esterno. » Questo apparecchio deve essere utilizzato solo sul pavimento o su di un tavolo. » Non utilizzate l’apparecchio a temperature inferiori a 5°C o superiori a 45°C. Evitate di esporre l’apparecchio alla luce solare diretta.
140 PROFILER STAGE – GUIDA VELOCE DICHIARAZIONE DI CONFORMITÀ KEMPER PROFILER Stage è conforme ai seguenti standard che regolano le interferenze e EMC: Procedura di verifica FCC - 47CFR §15.107 + 109 e contiene ID FCC: 2AC7Z-ESPWROOM02. Questo dispositivo contiene il modulo radio approvato da SRRC CMIIT ID 6DP3252...
Page 141
Noi, Kemper GmbH, Königswall 16-18, 45657 Recklinghausen Germania, Tel: +49 (0) 2361 970970, dichiariamo sotto la nostra esclusiva responsabilità che il prodotto PROFILER Stage è conforme alla Parte 15 delle norme FCC. Lo stage del profiler contiene l’ID FCC: 2AC7Z-ESPWROOM02.
