Artillian 1RMTBXS Installation & Owner's Manual

Rops mounted toolbox, small, 20"x10"x11"

ARTILLIAN ROPS MOUNTED

TOOLBOX, SMALL, 20"X10"X11"

For use on the Artillian ROPS Mounted Tool Bar (P/N: 1RMTB) (sold separately)

The Small Artillian ROPS Mounted Toolbox is a plastic storage container

with an internal tote tray and 10 gauge steel support brackets. The box is

rated for 30 pounds. Integrated Cam Lever Latches securely lock onto the

Artillian ROPS Mounted Tool Bar (sold separately) in seconds without the

use of tools.

Bring the box to where the tools are, fill it up, and carry it back to your

tractor. Drop it onto the Tool Bar, cam over the latches, and you are on

your way!

The quick release latches allow for easy removal of the toolbox for storage

or replacement with one of the many other Artillian ROPS Mounted Tool

Bar Accessories.

Approximate Installation Time

Experienced Dealer Technician – 2 Minutes

Average Dealer Technician – 2 Minutes

Do-It-Yourself – 2 Minutes

CAUTION

The contents of this envelope are the property of the owner. Leave with the owner when installation is complete.

P/N: 1RMTBXS

Approximate Product Specifications

Overall dimensions: 20" L x 10" W x 11" H

Weight: 13.71 lbs. (not including mounting bar)

Capacity: 30 lbs.

Do not exceed the rated capacity for the Toolbox. Doing so may result

in damage to the Toolbox and/or the Tool Bar and will void the warranty.

Rev. A, 04/30/2020

p/n: IM-1RMTBXS

1 of 3

Table of Contents

Need help?

Do you have a question about the 1RMTBXS and is the answer not in the manual?

Page 1 TOOLBOX, SMALL, 20”X10”X11” P/N: 1RMTBXS For use on the Artillian ROPS Mounted Tool Bar (P/N: 1RMTB) (sold separately) The Small Artillian ROPS Mounted Toolbox is a plastic storage container with an internal tote tray and 10 gauge steel support brackets. The box is rated for 30 pounds.
Page 2 2 of 3 FEATURES AND OPERATION ATTACH TO MOUNTING BAR: Figure 1 shows a toolbox installed onto an Artillian ROPS Mounted Tool Bar. 2. To install the toolbox, rotate both cam levers UP, then place onto the Tool Bar. See fig. 2.
Page 3 3 of 3 SERVICE PARTS: TOOLBOX SUPPORT BRACKET, SMALL CAM LEVER LATCH SAFETY WALK ADHESIVE STRIPS P/N: 8SV-WA-00364 (QTY.: 2) P/N: 8SV-110-00071 (QTY.: ONE) P/N: 9SV-9PR62-375 (QTY.: 12) TOOLBOX, DRILLED, 20”X10”X11” P/N: 8SV-9TB-02A OTHER ACCESSORIES: ROPS MOUNTED TOOL RACK ROPS MOUNTED TOOLBOX, LARGE ROPS MOUNTED TOOL BASKET P/N: 1RMTRK P/N: 1RMTBXL...
