HITROL HCC-96RF-C Series Instruction Manual

Capacitance type level switch
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HCC-96RF-C(S) Series
HITROL CO., LTD.
HEAD OFFICE.FACTORY.R&D INSTITUDE
HITROL CO., LTD 141, Palhakgol-gil, Jori-eup
Paju-si, Gyeonggi-do, Korea
TEL.: (00)-82-31-950-9700
FAX: (00)-82-31-943-5600
www.hitrol.com
INSTRUCTION MANUAL
CAPACITANCE TYPE LEVEL SWITCH
HCC-96RF-C(S) Series
Doc. no. : HCC96RFC(S)_IM_Eng_Rev.1
Issue date: 2021. 01
HITROL CO.,LTD.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HCC-96RF-C Series and is the answer not in the manual?

Questions and answers

Related Manuals for HITROL HCC-96RF-C Series

Summary of Contents for HITROL HCC-96RF-C Series

  • Page 1 HCC-96RF-C(S) Series HITROL CO., LTD. HEAD OFFICE.FACTORY.R&D INSTITUDE HITROL CO., LTD 141, Palhakgol-gil, Jori-eup Paju-si, Gyeonggi-do, Korea TEL.: (00)-82-31-950-9700 FAX: (00)-82-31-943-5600 www.hitrol.com INSTRUCTION MANUAL CAPACITANCE TYPE LEVEL SWITCH HCC-96RF-C(S) Series Doc. no. : HCC96RFC(S)_IM_Eng_Rev.1 Issue date: 2021. 01 HITROL CO.,LTD.

  • Page 2: Table Of Contents

    Marking · · · · · · · · · · · · · · · · · · · · · · · · · · · · 9 marked to carry out the work. Warranty and Contact · · · · · · · · · · · · · · · · · · · · · 9 HITROL CO.,LTD.

  • Page 3: Overview

    ■ Easy installation and calibration ■ Operating can be checked at the site. Operating For HCC-96RF-C Series, if the level of the medium increases and the main probe comes Principle into contact with the medium, the impedance changes depending on the capacitance value.

  • Page 4: Specifications

    0.5Sec. @ Min. / 1 ~ 10Sec. @ 0.1Sec. Resolution (Adjustment) Relay Contact Out Control Normal Close @ Default. Status Indicator Bi-Color LED [Green / Red / Orange] Detection Indicator Red LED Green LED Relay Control Indicator UART Monitoring Ambient Temperature -20˚C ~ +80˚C HITROL CO.,LTD.

  • Page 5: Product Composition

    Rod Type (Fully insulated Teflon) For HCC-96RF-C(H) For HCC-96RF-S (Only Solid) * Flat Type can be used in liquids, but further verification is required at the head office as a sample. Actual product may have a tolerance slightly. HITROL CO.,LTD.

  • Page 6: Installation

    - For outdoor installation, it is recommended to install the sun cover to avoid the effects of temperature increases. - In case of tank with stirrer, the probe shall be installed at a safe distance from the stirrer. HITROL CO.,LTD.

  • Page 7: Precautions For Attachment

    3.1㎟ (3.1mmSQ). If the power line is larger than 3.1㎟, connect the ground wire without terminal lug. Make sure to insert a washer if the terminal lug is removed from ground terminal and then re- connected. (Loosening prevention) HITROL CO.,LTD.

  • Page 8: Maintenance

    - Make sure to separate the amplifier and main unit from housing before disposing the products. Also, the amplifier shall be detached and discard the metal and non- metallic materials. No part (ex. Mercury switch) has influence on the environment, so no special attention is required. HITROL CO.,LTD.

  • Page 9: Marking

    You can request A/S at our website or by contacting our headquarters. ■ Headquarters ․ Factory ․ Laboratory Contact Number ADDRESS: HITROL CO., LTD 141, Palhakgol-gil, Jori-eup, Paju-si, Gyeonggi-do, Korea T E L : 031-950-9700 (Headquarters & A/S) F A X : 031-943-5600 (Headquarters & A/S)
  • Page 10 APPENDIX Q HCC-96RF-C Setting Guide RF Admittance Type Level Switch Doc. no. : Rev0.0 Issued Date : 2020.11.18...
  • Page 11 1. M-96RFC Configuration and Function Configuration Function ■ Tuning Capacitance in the tank TUN. ■ Sensitivity Adjustment ■ Relay Delay Time Adjustment ○ Time Range: 0.5s, 1s ~ 10s @ Adjustment 0.1s ■ Relay Return Time Adjustment ○ Time Range: 0.5s, 1s ~ 10s @ Adjustment 0.1s ■...
  • Page 12 2. M-96RFC Setting and Adjustment ■ Initialization Setting Method □ After installing it on the tank, set it to the initial state for quick response. ■ Tuning Setting 1 □ When the capacitance value in the tank is lower than the reference value, TUN.
  • Page 13 ■ Tuning Setting 2 □ When the capacitance value in the tank is higher than the reference value, TUN. TUN. [After Adjusting [Before Adjusting Function Method DET. TUN. ■ To set the reference value while the LED is on, adjust the DET.
  • Page 14 ■ Relay Time Adjustment Method □ You can adjust the relay operation time after detecting the measurement. [Operating Status According to Relay Delay Time] Function Method ■ Relay Delay Time : 0.5s, 1s ~ 10s @ Adjustment 0.1s ■ Time Adjustment Range □...
  • Page 15 ■ Fail Safe Mode Adjustment Method □ You can adjust the contact status to Relay Contact N.C. [Operating Status According to Relay Contact [N.C]] Function Method ■ Relay Contact Out Default Status ■ After detecting the measurement, the contact point changes from N.C to N.O. ■...
  • Page 16 3. M-96RFC UART Monitoring ■ Monitoring Method □ You can only check the state of the adjusted setting values using PC or Smartphone. □ The execution method is the same using PC or Smartphone. (Password: 1975) □ Run Screen Component: You can check the sensor measurement status, sensitivity setting value, relay setting, etc.
  • Page 17 ■ Monitoring Method Using Smartphone □ Component: Smartphone(Android OS), OTG, USB Cable(typical USB to Micro USB B), UART Adaptor.. □ App: Refer to “Serial USB Terminal Install Guide”. [USB Cable] [M-96RFC Smartphone UART Component] [Enter PW and Fly command] [Home Screen] [Select UART Connection] [Run Screen] [Open App]...
  • Page 18 APPENDIX S HCC-96RF-S Setting Guide RF Admittance Type Level Switch Doc. no. : Rev0.0 Issued Date : 2020.11.18...
  • Page 19 1. M-96RFS Configuration and Function Configuration Function TUN. ■ Tuning Capacitance in the tank SEN. ■ Sensitivity Adjustment ■ Relay Delay Time Adjustment ○ Time Range: 0.5s, 1s ~ 10s @ Adjustment 0.1s ■ Relay Return Time Adjustment ○ Time Range: 0.5s, 1s ~ 10s @ Adjustment 0.1s ■...
  • Page 20 2. M-96RFS Setting and Adjustment ■ Initialization Setting Method □ After installing it on the tank, set it to the initial state for quick response. Relay Delay Time: 0.5s SEN. : 0 Relay Return Time: 0.5s Fail Safe Mode (NC) ■...
  • Page 21 ■ Sensitivity Adjustment Method □ You can adjust measurement sensitivity for each environment. SEN. SEN. [After Adjusting VR (Insensitive)] [Before Adjusting Function Method SEN. ■ The VR state according to the “Tuning Setting” is the most sensitive state. Tuning Setting Status ■...
  • Page 22 □ You can adjust the relay return time after undetecting the measurement. [Operating Status According to Relay Return Time] Function Method ■ Relay Return Time : 0.5s, 1s ~ 10s @ Adjustment 0.1s ■ Time Adjustment Range ■ Fail Safe Mode Adjustment Method □...
  • Page 23 □ You can adjust the contact status to Relay Contact N.O. [Operating Status According to Relay Contact [N.O]] Function Method ■ Relay Contact Out Opposite Status. ■ After detecting the measurement, the contact point changes from N.O to N.C. ■ LED Status...
  • Page 24 3. M-96RFS UART Monitoring ■ Monitoring Method □ You can only check the state of the adjusted setting values using PC or Smartphone. □ The execution method is the same using PC or Smartphone. (Password: 1975) □ Run Screen Component: You can check the sensor measurement status, sensitivity setting value, relay setting, etc.
  • Page 25 ■ Monitoring Method Using Smartphone □ Component: Smartphone(Android OS), OTG, USB Cable(typical USB to Micro USB B), UART Adaptor. □ App: Refer to “Serial USB Terminal Install Guide”. [USB Cable] [M-96RFS Smartphone UART Component] [Enter PW and Fly command] [Home Screen] [Select UART Connection] [Run Screen] [Open App]...
  • Page 26 APPENDIX H Serial USB Terminal Serial USB Terminal Install & Setting Guide Application : Level Switch / Level Transmitter Doc. no. : Rev0.0 Issued Date : 2020.04.29...
  • Page 27 ■ Installing Serial USB Terminal App □ Search and Install a App that "Serial USB terminal" in the App Store. ■ Serial USB Terminal Setting □ Run The Serial USB Terminal Icon □ Four types of environments must be set up for normal operation of Serial USB Terminal. ▶...
  • Page 28 ■ Serial – Baud rate Setting □ Baud rate : 19200 -> 9600 [Complete] [Select Baud rate] [Setting] [Default] ■ Terminal - Show connection message / Show timestamps Setting □ Show connection message : ON -> OFF □ Show timestamps : ON -> OFF □...
  • Page 29 ■ Receive – Newline Setting □ Newline : CR+LF (Carriage Return + Line Feed) Check [Default] ■ Send - Newline Setting □ Newline : Auto(same as Receive) -> CR [Select Newline] [Default] [Setting] [Complete] Doc. no. : Rev0.0 Issued Date : 2020.04.29...
  • Page 30 ■ Send - Character delay Setting □ Character delay : 0ms -> 5ms [Complete] [Setting] [Default] [Select Character delay] ■ Send – Local echo / Clear input on send Setting □ Local echo : ON -> OFF □ Clear input on send : OFF -> ON [Complete] [Complete] [Select Local echo]...
