PLOT TRAILS - Trails Shown
The current plot trail shows on the plotter by default. To
place a previously saved trail onto the plotter, choose
"TRAILS SHOWN" from the Trail Options menu. The
screen shown at right appears. Highlight the desired
trail on this screen, then press the right arrow key to
select it. Press the EXIT key to erase this menu. The
selected plot trail shows on the plotter.

ICONS

The plotter has 28 symbols or "icons" available that can be placed any-
where on the screen. They can be used to mark fishing or hunting loca-
tions, landmarks, boat ramps, and virtually any point of interest. An icon
can be placed at your present position or at the cursor's location.

Place Icon - Present Position

To place an icon at your present position, simply press
the ENT key while the mapping screen is on. The screen
shown at right appears. Use the arrow keys to high-
light the desired icon. Now press the ENT key again.
The mapping screen reappears with the icon showing
at the position you were at when the ENT key was
pressed.
MAP-1 SCREEN SELECT ICON ICON PLACED
PRESS ENT KEY PRESS ENT KEY AT POSITION.
19
