HomeAware HA360US Installation And Setup Manual

INSTALLATION AND SET UP FOR HA360US – Universal Signaler
The HomeAware™ HA360US is designed to alert you
to many sounds. This signaler alerts you through the
HomeAware™ Main unit and remote receivers located
in other rooms.
Battery Backup Installation
Install a new 9 volt alkaline battery into the battery
compartment located on the back of the unit. See
diagram for battery door location. Battery backup will
provide power when a power outage has occurred.
Power will be provided for a continuous outage lasting
7 days, or for short outages up to two years.
Link Button Set Up
This procedure will link the HA360US – Universal
Signaler to your Main unit. The Main unit will also
provide an alert to all HomeAware™ remote receivers.
When using the Bridge unit HA360BU all original Sonic
Alert receivers (SA101, SA201, BL300, and SB1000)
will also alert you.
It is best to do the link procedure in the same room with
the HomeAware™ Main unit, make sure the unit is
plugged in.
To link the signaler to your HomeAware™ Main
unit:
1. Press set up button and the word LINK will be
shown on the display, press Enter. LINK will begin
blinking. (If LINK mode is entered by accident,
simply press the BACK button to exit and return to
the clock.)
2. Press and hold down the Link button on the back of
your transmitter for about 1 second. The red LED
on the signaler will light up. Release the button.
3. Pick Device will scroll across the display, hit the
TONE button to pick which device you want to be
alerted to (see list of devices below). Once you see
the device hit the ENTER button.
4. Upon successful connection, the red LED on the
transmitter will flash 2 times, then turn off. The
HomeAware™ main unit will briefly show DONE,
and return to the time display. Your signaler is now
connected and ready to test and use.
List of Devices in order:
INTCOM (INTERCOM), KITCH (KITCHEN), GARAG
(GARAGE), DRVWY (DRIVEWAY), MDALRT (MEDICAL
ALERT), OXYGEN, FLOOD, PET
Sensitivity Switch
You can adjust the sensitivity of the detector. There are
three levels to choose from: The HI setting is the most
sensitive setting and will alert you to more sounds.
Moving this switch to MED makes it less sensitive and
will alert you to less sound. The LO setting is the least
sensitive. If you are not picking up the sound you need
to be alerted to, simply move the sensitivity switch to a
higher setting. If you have set this setting to HI and you
are still not picking up the sound try moving the
transmitter closer to the sound.
When a sound is detected it will send a signal to the
HomeAware™ base unit and all HomeAware™ remote
receivers, also the red LED light will flash on the front
of the unit.
Low Voltage Input
HomeAware™ transmitters have a low 120 volt AC
power supply that powers the HA360ss. Simply plug
the unit into any 120 volt AC power outlet. Next plug
the other end into the Low Voltage Input located on the
side, see diagram.
