- Page 1 ASSEMBLY INSTRUCTIONS Description : COTTAGE 60 INCH TV STAND Item No. : TV-20 ITEM NO. : TV-20 Printed in Vietnam ISSUED MAR 01, 2016 - 1 -...
- Page 2 Protect the surface of the product with cloth if you are using any product with rubber feet or base. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO. : TV-20 Printed in Vietnam ISSUED MAR 01, 2016 - 2 -...
- Page 3 Back panel (L Door (L-R) & R) Vertical Center back panel panel (L) (L-R) Center back Side panel panel (R) Bottom H-Connector panel Center divider ITEM NO. : TV-20 Printed in Vietnam ISSUED MAR 01, 2016 - 3 -...
- Page 4 STEP 1 Attach side panel (E) and center divider (G) to top (A) with bolts (1) and washers (2) and (3) as shown below. Tighten with Allen key (12). ITEM NO. : TV-20 Printed in Vietnam ISSUED MAR 01, 2016...
- Page 5 STEP 3 Attach vertical panels (D) to center panel (B) with bolts (1) and washers (2) and (3) as shown below. Tighten with Allen key (12). ITEM NO. : TV-20 Printed in Vietnam ISSUED MAR 01, 2016 - 5 -...
- Page 6 Slide back panels (J) into grooves of vertical panels (D) and side panels (E). Then attach back panels (J) to bottom panel (F) with screws (6) as shown below. Tighten with a screwdriver. ITEM NO. : TV-20 Printed in Vietnam...
- Page 7 Insert brackets (10) into the unit as shown below. Place shelves (H) and (I) on the brackets and attach with screws (5). Tighten with a screwdriver. Attach magnets (9) to vertical panels (D) with screws (5) as shown below. Tighten with a screwdriver. ITEM NO. : TV-20 Printed in Vietnam ISSUED MAR 01, 2016...
- Page 8 (to secure the product and prevent tipping). Tighten with a screwdriver. Attach knobs (13) to doors (C) with pan head screws (7) as shown below. Tighten with a screwdriver. ITEM NO. : TV-20 Printed in Vietnam ISSUED MAR 01, 2016...
