Specification
Power supply
230Vac ±10% @ 50/60Hz
Power consumption
3VA
Radio disturbance
VDE0875/0871
Vibration test
with 2g (DIN 40046)
Relay output
SPDT, 250V @ 5 (1) A
Housing dimensions
115 x 53 x 70mm
Housing materials:
Cover
ABS
Base
Nylon
Housing protection
IP30
Sensor dimensions
77 x 77 x 44
Sensor material
Nylon
Sensor protection
IP44
Ambient:
Storage temp. -25 to + 60°C
Operating temp.0 to 45°C
RH
Class F Din 40040
Country of origin
Italy
UK Sales Tel: 0845 345 7253
1-Channel Gas Leak Alarm System
Features
•
•
•
Product Codes
GL-CO-RFG361
GL-CO-RFG-FMK3
GL-CO-SRS150
GL-CO-SRS250
GL-CO-SRS350
Page 1 of 4
Date Of Issue: 28/10/2008
© 2008 Sontay Limited. All rights reserved.
Remote sensor for Natural Gas, LPG or CO
Audio & visual alarms
DIN rail or panel mounting
1 Channel gas leak alarm system (DIN rail mount)
Panel door mounting kit
Natural gas sensor
LPG, Propane sensor
Carbon Monoxide sensor
International Tel: +44 1732 861225
GL-CO-RFG361
Issue: 5.5
Advertisement
Related Manuals for Sontay GL-CO-RFG361
Summary of Contents for Sontay GL-CO-RFG361
- Page 1 GL-CO-RFG361 Issue: 5.5 Date Of Issue: 28/10/2008 © 2008 Sontay Limited. All rights reserved. 1-Channel Gas Leak Alarm System Features • Remote sensor for Natural Gas, LPG or CO • Audio & visual alarms • DIN rail or panel mounting...
- Page 2 F3 - F4 linked: Alarm ceases when the gas concentration falls below the 1. The GL-CO-RFG361 should only be installed by a compe- threshold level and the ALARM LED blinks slowly. Press the tent, suitably trained technician, experienced in installa- RESET button to clear the LED status.
- Page 3 GL-CO-RFG361 Issue: 5.5 Date Of Issue: 28/10/2008 © 2008 Sontay Limited. All rights reserved. Alarm Levels (continued) Self Diagnostics The alarm threshold for Natural Gas is about 16% of the In the event of a fault or incorrect connection of the sensor LEL.
- Page 4 For the latest information and product updates, register at www.sontay.com Whilst every effort has been made to ensure the accuracy of this specification, Sontay cannot accept responsibility for damage, injury, loss or expense resulting from errors or omissions. In the interest of technical improvement, this specification may be altered without notice.
