ssembly Instructions for PROSCOPE
D
.
ttach "Y" tubing to each set of the binaurals (660-05) as shown in the illustration.
B.
ttach free end of each "Y" tubing to the double pair end of the "Y" connector (#611-20).
C. Connect one end of the straight tubing (#671-05TBK) to single end of the "Y" connector.
D. Connect remaining end of the straight tubing to stem of chestpiece (#660-01 or #670-01).
(Models #671 and #661)
B
C
B
TO
SSEMBLE
Make sure all tubing connections are firm.
