- Page 1 S-Charge System Battery System with Display and Magnetic Charger Technical Manual...
-
Page 2: Table Of Contents
In the Box Features and Benefits 3500S Battery System Compatibility Connector Pack Cable Principle Dimensions and Specifications Connecting the S-Charge System Installation Instructions Important Notes for Fitting Initial Start-up Checking the Battery Level Activating the Prosthesis Power Deactivating the Prosthesis Cable... -
Page 3: In The Box
S-Charge System Features and Benefits The S-Charge System is a user-friendly battery system with • High-capacity 3500mAh batteries. an OLED display and a magnetic charger, that is fitted into • The 3500S battery pack fits easily within the prosthesis. a prosthesis to allow the user to easily activate, deactivate •... -
Page 4: Principle Dimensions And Specifications
Connect to 3500S Battery Pack Display end view Top view The S-Charge System has been developed to employ the latest advances in battery technology. The system is only compatible with the Steeper 7.2V Lithium-ion 3500S Battery Pack provided. Please note: The battery cells must not be separated. -
Page 5: Connecting The S-Charge System
2 - 2.5mm. Cable separately, part no: CBBHA72. 2-pin for Electrodes not included) The S-Charge System is designed to be retrofitted to a pre-made forearm. However, if the residual limb is too long 4-pin for connector... - Page 6 6. Please note, to connect all the components these e) Connect the EQD cable to instructions MUST be carried out in this order: the power cable (if required) a) Firstly, connect the 3500S b) Next, connect the display Battery Pack to the hub. The with the ribbon cable to hub is able to accommodate the hub.
-
Page 7: Important Notes For Fitting
10. Feed the full system through the forearm, and pull Important Notes for Fitting the display through so it exits the forearm through the mounting frame hole. If a bend is required to allow the ribbon cable to run along the forearm, carefully fold it at •... -
Page 8: Initial Start-Up
1. Connect the display to the hub. with excessive force. 2. Connect the 3500S Battery Pack to the hub. • The S-Charge System must only be fitted by a qualified prosthetic technician, and prescribed by a 3. The display will show the battery status bar. -
Page 9: Activating The Prosthesis
Low Battery Level Deactivating the Prosthesis 1. The prosthesis can be deactivated by holding down the 1. When the battery level reaches 10%, the display will flash the below screen, on the press of the button, if the Standby button for 1.5 seconds. The system will then be system is active: in Standby Mode. -
Page 10: Charging The Prosthesis
Charging the Prosthesis 1. Connect the magnetic plug to the magnetic charging 4. When the battery is fully charged, all segments will be solid. port of the display. 5. When the magnetic plug has been disconnected, the display will show the current charge of the battery, and the prosthesis will be activated. -
Page 11: Charging Faults
• The batteries will degrade over time, therefore may mounting frame will break, replacements are provided require a replacement within the kit, and are available from Steeper). Check all • Charger may be faulty - try a different unit cables for sign of damage - if damaged, replacement parts are required. - Page 12 Distorted display Prosthesis non-operational despite full charge and power on Carry out in the following order until working: Carry out in the following order until working: 1. Disconnect all parts and ensure that the areas between the connections are clear of debris. 1.
-
Page 13: Care, Cleaning And Safety
In the event of failure or suspected malfunction, please contact Steeper or your supplier. The batteries must only • Do not expose the S-Charge System to a naked flame or be charged with the appropriate charger and its power any other excessive heat. -
Page 14: Warranty Terms
• The 3500S battery pack will degrade after a number of The designed service life of the S-Charge System is two cycles. To order a replacement, please contact Customer years. We would recommend replacing the 3500S batteries Services - this is not included in the warranty. -
Page 15: Environmental And Operational Conditions
• IEC62133-2:2017 15kV air • UN38.3 If the S-Charge System has been in storage, please leave in an ambient temperature (20°C) for a minimum of 2 hours before Quality Assurance use. Steeper/SteeperUSA operate a quality management system that fully complies with the requirements of BS EN ISO 13485:2016. -
Page 16: Symbols Used On Product & Packaging
Great Britain. Device Regulations. 20, 21, 22, 74 and Annex V) The design and manufacture of Steeper equipment and components are subject to a policy of continuous reappraisal. Single Patient - Multiple use ISO/DIS 15223- The company, therefore, reserves the right to introduce changes... - Page 17 Office 14, 1st Floor, Elite Trading Centre Building 7934 King Abdul Aziz Road, Al VIC, 3168, Australia. Rabi, 13315 Riyadh, Saudi Arabia EMERGO EUROPE Prinsessegracht 20, 2514 AP The Hague, Netherlands STPPR042 Issue 11 June 2021 © 2021 Steeper Group. All rights reserved.
