Screen Protector
2
Waterproof Seal
3
Charging Port (Water resistant seal when charging)
4
Ambient Light Sensor Opening
5
VESA 100 Port
6
Volume Button
7
Power Button
Camera & Flash Opening
8
Speaker Channel
9
MagConnect Port (1/4"-20)
10
Optional Shoulder Strap Support
11
Optional Hand Strap Support
12
Installation Guide
4
7
6
8
12
10
pro M
ご利用ガイド
9
5
11
4
1
2
3
Advertisement
Related Manuals for aXtion Pro M
Summary of Contents for aXtion Pro M
- Page 1 M Installation Guide ご利用ガイド Screen Protector Waterproof Seal Charging Port (Water resistant seal when charging) Ambient Light Sensor Opening VESA 100 Port Volume Button Power Button Camera & Flash Opening Speaker Channel MagConnect Port (1/4"-20) Optional Shoulder Strap Support...
- Page 2 M Installation Guide ご利用ガイド Open charging cover Lift the back of the case from the camera end Align and adjoin the bottom Place water test paper inside, face sections of the case at a 25º down to the front of case/ screen side.
- Page 3 M Installation Guide ご利用ガイド Dry the outer case prior to opening and ensure the water Test under 12" of water for 10 minutes test pad is dry. 12 in 12 in 10 min 30 cm 30cm 2 lb. VESA Installation...
- Page 4 M Installation Guide ご利用ガイド Water Stopper Charging @IP65 Replacing Water- resistant* Gray Blue Installation Call us to get the Gray Water Stopper. If water-resistant (IP65) is required while charging, replace the blue water stopper with the gray one by following directions below. Call us to get the Gray Water Stopper.
- Page 5 Pro Cases are certified as “dust tight” (that is, no dust will be allowed ™ inside the case when it is properly used and the device will be completely protected from contact with dust when the case is so used). All aXtion Pro Cases ™...
