  • Page 1 SyncroDAC Operating Manual www.syncronorm.com #liquidinspiration info@syncronorm.com...
  • Page 2 & hardware solutions fitting to your dedicated project. From show-design, training-programs, instant support & consulting to continuously soft- & hardware development, the team at Syncronorm is eager to realize your visions. Syncronorm provide the most established & renowned products for the entertainment- &...
  • Page 3 4 Channel DMX to Analog Decoder SYNCRODAC The SyncroDAC is a Universal Network Decoder to drive electronic control components in a multi- media show environment. The Decoder supports all Major Protocols: Analog (0...10V) or Digital (DSI or DALI). SyncroDAC is the perfect tool to integrate analog VFD´s into a Syncronorm Depence Network as well as to control any 0...10V, 1...10V, DSI, DALI or PWM Output.
  • Page 4 Preface This document is a guideline for controlling the hardware of Syncronorm‘s fountain control systems. The information contained in this manual will give you a sufficient understanding of this product, helping you to use the unit correctly and effectively. Adhere to all instructions contained in this manual, when installing and operating this unit.
  • Page 5: Safety Instructions

    This unit requires the SyncroTools DMX address board (SN-STADRB) (not included). Intended Use The SyncroDAC, in the following referred to as „unit“, may only be used as specified as follows: Converting ArtNet signal to DMX-RDM signal Safety Information Danger to persons and assets may emanate from this unit, if it is used in an improper manner or not in accordance with its intended use, or if the safety instructions are ignored.
  • Page 6: Save Operation

    Syncronorm GmbH or personnel with suitable training. Dangers resulting from non-adherence to the Safety Information Please note that Syncronorm GmbH assumes no liability for damage, downtimes or malfunctions resul- ting from non-adherence to this installation and operating manual. By ignoring or not adhering to all of the safety information contained in this manual, you could endanger people, the environment and the system of this unit.
  • Page 7 Syncronorm GmbH have neither been tested nor approved by Syncronorm GmbH. For this reason, the installation and/or use of such products can, under certain circumstances, negatively affect the specifications for the device. This could also lead to restrictions of the active and/or passive safety of the device.
  • Page 8 Ballasts must be connected to the output terminals of the DAC Decoder 4x. Multiple bal- lasts may be connected in parallel if required – see technical data. Digital SYNCRONORM PCA electronic ballasts are insensitive to polarization. If using other ballasts, please check before wiring. The signal out- put of the DAC Decoder 4x is positive (+).
  • Page 9 509) must be programmed. The start address switch board 3000P or 3003P is required to set start ad- dress and mode of operation. This is a standard device, which can be used for all Syncronorm decoders. (C) 2021 Syncronorm GmbH...
  • Page 10: Settings & Setup

    OFF= all outputs are driven to 0% (e.g. stage lighting) ON = all outputs are driven to 100% (e.g. architectural lighting) DIP-SWITCH 3/4: OPERATING MODE OFF/OFF= Analog output 0..10V / 1-10V ON /OFF= DSI OFF/ON = DALI ON /ON = PWM (C) 2021 Syncronorm GmbH...
  • Page 11 This is a ballast property. Minimum ballast intensity is 1% (typically). Again, this is a ballast property: minimum levels of 3%, even 5% (or higher) are commonly available (The decoder will nevertheless go down to 0V). Please check the data of your ballasts. SYNCRONORM recommends use of OSRAM ballasts for optimum performance.
  • Page 12: Drive Characteristics

    The electronic ballasts are connected to connector CN4. Each output has two terminals, orange (output drive signal, +) and blue (ground, -). SYNCRONORM PCA electronic ballasts are insensitive to polariza- tion of the drive signal, thus terminal connections may be interchanged. When using other brands, make sure to obey correct polarization of the drive signal.
  • Page 13 • Connect the equipment to an outlet other than the receiver ‘s • Consult a dealer or an experienced radio/TV technician for assistance FCC Caution: Any change or modification to the product not expressly approved by SLH could void the user’s authority to operate the device. (C) 2021 Syncronorm GmbH...
  • Page 14: Guarantee Conditions
