Summary of Contents for Magigoo Coater
- Page 1 User Manual Starter Kit Expansion Kit Coater...
- Page 2 Please carefully read and understand the contents of this user manual. Failure to follow instructions set out in the manual may lead to personal injury, poor results or damage to the Magigoo Coater, 3D Printer or its peripherals. To make the most out of the Magigoo Coater, study the manual carefully and make sure that anyone using the Magigoo Coater understands the instructions laid out in this user manual.
-
Page 3: Table Of Contents
Attaching the pump 2.1.3 Preparing for first use Recommendations for use 2.2.1 Before Coating 2.2.2 Coating 2.2.3 Cleaning the manifold 2.2.4 Cleaning Build Plate from Magigoo Adhesive compatibility Maintenance Warranty General Exclusions Conditions & Limitations Lodging Claims Applicable law and competent court... - Page 4 Magigoo Coater User Manual...
-
Page 5: Safety
1.2 Intended Use The Magigoo Coater is designed and built for use in FDM/ FFF 3D printing to cover the build plate of a 3D printer with a thin layer of Magigoo or Magigoo Pro bed adhesives to increase the reliability of the 3D print, reduce warping and provide easy release. -
Page 6: Health And Safety
Use only on a 3D printer that is in idle mode. Use only on build plate that is at room temperature. Store Magigoo Coater away so it will not fall, or risk to injure someone. Magigoo... -
Page 7: Instructions For Use
Instructions for Use... - Page 8 Introduction...
-
Page 9: Unboxing And Assembly
Unboxing and Assembly 2.1.1 Unboxing Open the case and inspect that all components are included and are in good condition. For reference see table below and point 2.1. Starter Expansion Item Case Bottle with adhesive Bottle for cleaning Cleaning Cloth Spray Head (nozzle with cap) Pump Head... -
Page 10: Attaching The Pump
Screw on the manifold until it is slightly tightened and the manifold is perpendicular to the trigger. Do not over tighten to prevent rupture of the manifold. Attach the short straw to the pump. Orientation of the straw should be in the direction of applicator. Magigoo Coater User Manual... - Page 11 Screw on the assembled system to the Magigoo bottle.
-
Page 12: Preparing For First Use
Preparing for first use Find a surface that can be easily cleaned. For the first time use, the Coater system needs to be primed by pumping several times until the adhesive starts coming out of the valves consistently. After priming wipe the silicone roller with a slightly damp cloth. -
Page 13: Coating
Check that the Coater valves and the applicator are clean and dry. If necessary, wipe the applicator and valves with a damp cloth and/or wipe dry prior to using the Coater. If the valves are still clogged, clean the manifold channels. See section 3.2.3 for Manifold cleaning instructions. - Page 14 Wipe clean the valves and applicator with a damp cloth immediately. NB! If changing adhesive type in between the use of the Coater, the manifold channels have to be properly cleaned. See how to clean in point 3.2.3 Cleaning the Manifold.
-
Page 15: Cleaning The Manifold
2.2.3 Cleaning the manifold When storing the Coater away or when changing the type of adhesive , the internal channels of manifold need to be cleaned thoroughly. Clean the manifold in a safe place away from other people, ideally inside a sink or secondary container. -
Page 16: Adhesive Compatibility
2.3 Adhesive compatibility The Magigoo Coater should be used only with adhesives produced by Thought3D under the brand Magigoo or other Thought3D approved adhesives. The Magigoo Coater has been designed to work with Magigoo and Magigoo Pro 3D printing build plate adhesives. -
Page 17: Maintenance
Maintenance... - Page 18 Maintenance The Coater is designed to be used on a daily basis. The components like applicator, valves and pump may lose original functionality with normal wear and tear. If applied coating is inconsistent, check if valves need to be cleaned or replaced. The Coater should still function well, with 1-2 valves not working properly.
-
Page 19: Warranty
Warranty... -
Page 20: General
4.1 General Thought3D Ltd (the “Manufacturer”) grants a standard commercial warranty on the Magigoo Coater product (the “Product”), including all accessories supplied with it except for items which are consumables. The warranty is additional to any contractual rights that the... -
Page 21: Exclusions
Under this warranty, the Manufacturer shall not be responsible for any costs incurred by way of shipping, whether such shipping is required to return defective products to the Manufacturer for inspection or repair, or to return replacement or repaired Product(s) back to claimant. -
Page 22: Conditions & Limitations
Product(s); and the Product(s) must be returned in the original packaging. Magigoo Coater User Manual... -
Page 23: Lodging Claims
Since warranty claims are conditional on the submission of the original purchase invoice and packaging, the Manufacturer advises purchasers to store the invoice and official packaging in a safe place. If the original packaging is not available anymore, the purchaser can purchase replacement packaging from the Manufacturer.
