Bay-Tek SMOKIN TOKEN Troubleshooting Manual

Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
IMPORTANT NOTICE:
THERE ARE 2 DIFFERENT VERSIONS OF THIS GAME
1.) BAYTEK VERSION: MAIN BOARD IN FRONT OF CABINET
2.) SEIDEL VERSION: MAIN BOARD IN BACK OF CABINET
PLEASE MAKE SURE THAT YOU ARE USING THE CORRECT VERSION
FOR YOUR TROUBLESHOOTING

Advertisement

loading
Need help?

Need help?

Do you have a question about the SMOKIN TOKEN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bay-Tek SMOKIN TOKEN

Summary of Contents for Bay-Tek SMOKIN TOKEN

  • Page 1 IMPORTANT NOTICE: THERE ARE 2 DIFFERENT VERSIONS OF THIS GAME 1.) BAYTEK VERSION: MAIN BOARD IN FRONT OF CABINET 2.) SEIDEL VERSION: MAIN BOARD IN BACK OF CABINET PLEASE MAKE SURE THAT YOU ARE USING THE CORRECT VERSION FOR YOUR TROUBLESHOOTING...

  • Page 2: Troubleshooting Strategy

    Gen 5 board, and/or sound and software chips, from another Gen 5 game to see if the problem persists. Insure that the software chip is from an identical game or additional problems may result. See the Service and Repair Section. Troubleshooting Chart – Bay-Tek Version Problem Probable Cause Remedy No power to the game.
  • Page 3 Troubleshooting Chart – Bay-Tek Version Problem Probable Cause Remedy Upper backlighting not a. Cable problem. a. Check for proper connection to functioning properly. main board. Check continuity. Replace grey cable. b. Lamp(s) out. b. Replace burned out lamps. c. Lamp circuit board faulty.
  • Page 4 Faulty sensor board. c. Replace chip – ULN2803 Replace board – AABD9616. Diagnose Code Wheel – Bay-Tek Version The Code Wheel, attached to the back side of the wheel, must work properly to identify slot location and ticket payout.
  • Page 5 SEIDEL VERSION –ST TROUBLESHOOTING & DIAGNOSTICS SECTION Troubleshooting Strategy Use common sense and a systematic method of troubleshooting to determine the exact problem, probable cause and remedy. Use the process of elimination to find the faulty component. Always check for the simple and obvious causes first such as unplugged, loose or broken wires and bad sensors, bent, pinched, stuck or jammed components.
  • Page 6 Troubleshooting Chart – Seidel Version Problem Probable Cause Remedy Upper displays not a. Cable problem. a. Check for proper functioning properly. connection to main board. Check continuity. b. 4 Wire jumper from b. Check jumper for main board continuity. Ensure wires unplugged.
  • Page 7 Troubleshooting Chart – Seidel Version Problem Probable Cause Remedy Tickets a. Disconnected, loose or a. Check connectors. Check Tickets do Owed broken wires. for continuity. not dispense Display is b. Opto Sensor on ticket b. Blow dust from sensor and or Wrong adding up dispenser dirty.

  • Page 8: Error Codes

    Troubleshooting Chart – Seidel Version Problem Probable Cause Remedy Error Codes Err. 2 Game is a. Silver dots not reflecting. a. Clean and shine up silver seeing some, but not dots. all wheel positions. b. Wheel Position Sensor b. Clean/Replace Wheel Position board not reading all Sensor –...
  • Page 9 Diagnose Power Supply Use the following procedure to check the power supply for Gen 5 games. 12 V OUT Check the small green LED light on the power supply circuit board. If the light is out there is a short somewhere. If the light dims, there is an overload in one of the circuits such as a bad motor.
