CSSG20
ON-CAMERA SHOTGUN MIC
USER GUIDE
Thank you for choosing JBL Commercial CSSG20
On-Camera Shotgun Microphone. This guide will
help you set up & operate your microphone. CSSG20
can be connected to both cameras & smartphones
(using the splitter cable). It is perfect while creating
news gathering videos, vlogging, youtube videos,
interviews & many more.
Advertisement
Table of Contents
Related Manuals for JBL CSSG20
Summary of Contents for JBL CSSG20
- Page 1 USER GUIDE Thank you for choosing JBL Commercial CSSG20 On-Camera Shotgun Microphone. This guide will help you set up & operate your microphone. CSSG20 can be connected to both cameras & smartphones (using the splitter cable). It is perfect while creating news gathering videos, vlogging, youtube videos, interviews &...
- Page 2 CSSG20 ON-CAMERA SHOTGUN MIC...
-
Page 3: Box Includes
BOX INCLUDES CSSG20 on-camera shotgun mic with attached cable with 3.5mm connector Windscreen iii. 3.5mm splitter cable PARTS & FUNCTIONS GUIDE Power switch – slide to turn ON & OFF the device. Power LED – glows GREEN when the battery has sufficient power, glows RED when the battery is low. -
Page 4: Inserting Battery
Cold shoe – to attach the microphone to DSLR/Camera/suitable stands. Knob – tighten this to lock the microphone to the cold shoe mount. ¼” socket - use this to mount the microphone on a suitable mounting stand. 10. Windscreen – used to prevent wind & pop noise. INSERTING BATTERY Open the battery compartment &... - Page 5 CONNECTING WITH DSLR/CAMERAS Connect the microphone 3.5mm connector with DSLR/camera. Turn ON the microphone. Adjust the gain & high pass filter according to the recording situation. You may use the output from the camera to monitor the recording. Microphone Camera CONNECTING WITH SMARTPHONES/TABLETS Use the splitter cable provided in the box to connect the microphone with smartphone/tablet.
- Page 6 Splitter Cable Cell Phone FEATURES High sensitivity condenser capsule with super-cardioid pickup pattern Adjustable microphone gain in three steps, -10dB, 0dB & +10dB iii. Built-in high pass filter to cut noise below 200Hz Standard cold shoe mount for convenient installation on camera Integrated shockmount to reduce mechanical &...
-
Page 7: Specifications
SPECIFICATIONS Polar pattern Super-cardioid Transducer 10mm condenser capsule Frequency response 50Hz - 16KHz Sensitivity -25dB ±3dB (0dB=1V/Pa at 1KHz) Gain adjustment -10dB/ 0dB/ +10dB High pass filter 200Hz 12dB/Oct Output impedance 2.2KΩ ± 30% Power supply 1.5V AA battery (approx. 80 hours) Outer dimensions L 157mm x H 48mm Tube dimensions... -
Page 8: Frequency Response
FREQUENCY RESPONSE 0° POLAR PATTERN... - Page 10 s shown are for illustration purpose only and may All product images shown are for illustration purpose only and may presentation of the product. Actual product may not be an exact representation of the product. Actual product may e and finishing. © 2021 HARMAN International vary in colour, size and finishing.
