Replacing fans on an AudiaFLEX
This article explains how to replace the fans in an AudiaFLEX. The AudiaFLEX has either one or two fans, depending
on its configuration. The AudiaFLEX NC (No CobraNet) has a single fan, located on the right side of the chassis (when
viewed from the front). The AudiaFLEX CM (with CobraNet Module) has two fans: a chassis fan (same as the NC), as
well as a CobraNet fan that is internal to the unit.
The fans should be replaced if it makes excessive noise (especially grinding or groaning noises) or if it doesn't spin at all
when the unit is powered on. Note that AudiaFLEX fans are variable-speed and therefore they may not spin at all if the
temperature is low enough. However, they should always spin briefly right after the unit is powered on.
Replacement fans can be obtained from Biamp Systems, either as a warranty item or a spare part order. However, there
are several different fans available, depending on when the AudiaFLEX was manufactured. Please take note of the
serial number of the AudiaFLEX and call Biamp's Service department to ensure you receive the correct fan for
your AudiaFLEX.
Required Tools
The following items are required to replace a Audia fan:
• #1 Phillips screwdriver
• #2 Phillips screwdriver
• Replacement Fan(s) (call Biamp Service department for correct part number)
• Two 6-32x3/4 screws with nylon locking nuts:
◦ 6-32x3/4 screw part number is 525.0016.900
◦ Nylon locking nut part number is 535.8003.900
Step by step
Follow the steps below to replace the fan(s). Click on any of the images to see a full-size version of the photo.
Removing the cover
1. Unplug power to the AudiaFLEX.
2. Remove the AudiaFLEX from its rack or enclosure, if necessary.
3. Remove the three screws from top of the chassis.
Copyright 2013-2020 Biamp Systems
http://support.biamp.com/
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Biamp AudiaFLEX
Summary of Contents for Biamp AudiaFLEX
- Page 1 The fans should be replaced if it makes excessive noise (especially grinding or groaning noises) or if it doesn't spin at all when the unit is powered on. Note that AudiaFLEX fans are variable-speed and therefore they may not spin at all if the temperature is low enough.
- Page 2 The correct orientation might be different than the photo below. Disconnect the fan from its connector on the board. 2. Remove the old fan by removing the four screws holding the fan in place. Note the orientation of the fan before Copyright 2013-2020 Biamp Systems http://support.biamp.com/...
- Page 3 Confirm that the fan spins normally and doesn't make excessive noise. If it makes excessive noise, you may need to re-open the chassis and loosen the screws that hold the fan to the chassis. In general, AudiaFLEX fans are designed to exhaust air from the unit, so if the fan is sucking air into the unit, then the fan may be installed backwards.
- Page 4 Disconnect the fan from its connector on the board. You may need to temporarily remove some of the I/O cards and/or use long needle-nose pliers to reach the connector underneath the power supply. 6. Install the new fan using the included 6-32x3/4 screws and nylon locking nuts. Please remember that only minimal Copyright 2013-2020 Biamp Systems http://support.biamp.com/...
- Page 5 9. Replace the two screws that hold the power/fan module to the side of the chassis. 10. Replace the top cover and replace all of the screws in the reverse order of how they were removed. Re-install the AudiaFLEX into its rack or enclosure, if necessary, and re-apply power to it. Copyright 2013-2020 Biamp Systems...
