- Page 1 AK-Nord GmbH Werner-von-Siemens-Straße 14 49584 Fürstenau Gemany Tel: +49 (0) 5901/93 890-10 Fax: +49 (0) 5901/93 890-24 Internet www.ak-nord.com E-Mail: info@ak-nord.com LXL Serie: Manual USB-Server...
-
Page 2: Table Of Contents
12.06.2020 Content Setup ............................3 Access via Network ......................3 Telnet-Configuration ....................... 4 MAIN MENU: ........................5 ADMIN MENU: ........................ 6 GENERAL MENU: ......................7 NETWORK MENU: ......................8 IP MENU: .......................... 9 DNS MENU: ........................10 NTP MENU: ........................11 INTERFACE MENU: ...................... -
Page 3: Setup
Setup Access via Network The devices from AK-Nord are delivered from the factory with the DHCP setting activated. I.e. you need a started DHCP server in your network, so that a LXL device gets a valid IP from this server. -
Page 4: Telnet-Configuration
12.06.2020 Once you know the assigned IP address of the device, you can configure it via Telnet menu (port 23). For this purpose please use the Telnet window in our XTAdminXXL tool or one of the other Telnet programs like e.g. PuTTY. Telnet-Configuration The first thing you will see is the password window. -
Page 5: Main Menu
12.06.2020 Enter "a" to call up the ADMIN MENU. Press "q" to close the current menu and return to the previous menu. Entering "q" in the MAIN MENU terminates the Telnet connection to the device. To change a configuration value, you must enter the <menu item ID>=<new value>. For the host name, for example, it would look like this: 1=usbserver_webcam MAIN MENU:... -
Page 6: Admin Menu
Here you can define the TCP/IP or UDP port that is allowed for the USB interface. Data can be received from or sent to USB via this port. a : Apps Here you can start or stop the AK-Nord programs. b : Apps autostart Configuration of Autostart when booting the AK-Nord programs. -
Page 7: General Menu
12.06.2020 GENERAL MENU: s : SYSTEM INFO Here you can view the system information like Linux version, runtime etc.. m : MEMORY INFO Here information about the consumption of the working memory is displayed. -
Page 8: Network Menu
12.06.2020 NETWORK MENU:... -
Page 9: Ip Menu
12.06.2020 IP MENU: d : DHCP(Y/N) Here you can configure whether the IP address should be obtained dynamically from a DHCP server or not. 1 : IPv4 address If DHCP is active, the current IPv4 address of the device is displayed here. If DHCP is switched off, the fixed IP address for the device can be assigned here. -
Page 10: Dns Menu
12.06.2020 DNS MENU: 1 : Hostname Here you can configure the host name of the device. The following characters are allowed: 0-9, A-z, minus sign and dot. 2 : Nameserver1 Here you can enter IP address of your 1st name server manually. 3 : Nameserver2 Here you can enter IP address of your 2nd name server manually. -
Page 11: Ntp Menu
12.06.2020 NTP MENU: 1 : NTP Server Here you can enter the IP address or the hostname for the NTP server for time synchronization. Current displays the current time on the device. -
Page 12: Interface Menu
12.06.2020 INTERFACE MENU: If you use VirtualHere, all settings made here are ignored. - Page 13 12.06.2020 USB1 MENU:...
-
Page 14: Usb1 Info
12.06.2020 USB1 INFO: Here you can find different device information like manufacturer ID(VID) or product ID(PID) for the connected USB device. -
Page 15: Config Menu
12.06.2020 CONFIG MENU 1 : Emulation Here you can enter the desired operating mode for the respective interface. The following values are allowed: TCPSERVER, UDPSERVER, TCPCLIENT, UDPCLIENT and VIRTUAL. If you want to use VirtualHere you have to enter VIRTUAL here. 2 : Selection(MULTI/SINGLE) With emulation TCPCLIENT you can select the client mode here. -
Page 16: Destinations
12.06.2020 DESTINATIONS Here you can enter the destinations(IP:Port) for the emulations TCPCLIENT or UDPCLIENT. Depending on the SELECTION one or more network connections are then established. -
Page 17: Virtualhere
12.06.2020 VirtualHere The VirtualHere service is pre-installed on the device. Please select the emulation "VIRTUAL" at the USB-Config-Menu. To use the virtual USB devices you still need the VirtualHere client. You can download it from the VirtualHere website: https://www.virtualhere.com/usb_client_software After installing the client, the USB-Server-LXL is displayed in the list of USB hubs and you can connect the connected USB device in the client to the PC via the right mouse button. -
Page 18: Rescue-Modus
PC to e.g. 192.168.100.50 for a short time and then call the following address in the WEB browser: https://192.168.100.100:8080 Here you can then import a new firmware, which you can get from AK- Nord. To get a firmware please contact: service@ak-nord.de... -
Page 19: Factory Settings
12.06.2020 Factory Settings: To perform factory reset, you must hold the factory reset button for 5 seconds during operation and then release it. The factory settings are applied and the device restarts once. Now DHCP is active again and network access is switched on.
