- Page 1 Manual AK-USB-DeviceServer ConLine-USB-XXL-B ConLine-USB-XXL-A ComPoint-LAN-USB AK – Nord EDV- Vertriebsges. mbH Stormstrasse 8 XT-PICO-USB AK-DinRail - USB 25524 Itzehoe Germany Phone: +49 (0) 4821 8040350 Fax: +49 (0) 4821 4083024 AK-RailPort - USB EVA-KIT-USB...
-
Page 2: Table Of Contents
Contents 1. Installation ..............................4 Hardware installation file........................4 Software installation file ........................4 Automatic installation start ....................... 4 2. Software ............................... 6 First start of your software ....................... 6 Program user interface ........................7 3. Connecting the USB device ........................8 Establishing a connection ........................ - Page 3 RFID readers, USB sticks, measurement devices, sensors and industrial machines equipped with USB connection, etc. to a network using the AK-NORD-USB–DeviceServer. Then they can be directly addressed and controlled via a PC in the network. A driver is installed on the PC which makes you available these USB devices via a virtual USB interface.
-
Page 4: Installation
1. Installation Hardware installation file Connect the hardware AK-USB-DeviceServer (XT-PICO-USB, ComPoint-USB or ConLine-USB2) to the network and connect the power supply unit. Software installation file If you receive the installation program compressed (ZIP file), decompress it beforehand. Then start the installation program “USB_Server_Setup.exe“ USB_Server_Setup.exe Automatic installation start The installation process starts automatically and does not require any further entries. - Page 5 Installation In order to successfully complete the installation select “Finish“. Then it is necessary to restart the PC. Also select “Finish“ here. Then the PC is restarted and the installation is successfully completed. AK-USB Server Handbuch, Version 1.0...
-
Page 6: Software
2. Software First start of your software After restarting your PC you will find two new icons on your desktop. Start the “Launch USB Server“ by double-clicking on the icon. When first starting the software the confirmation prompt of the Windows firewall below is displayed. -
Page 7: Program User Interface
Software Program user interface Here you can see all available AK-USB-DeviceServers in the network. By clicking on the button “Search” the program “USB Server“ browses your network again. If no AK-USB-DeviceServer is played, connect your AK-USB-DeviceServer to your network and check your cabling or the network settings of your PC. The network default settings of the AK-USB-DeviceServer are: DHCP 192.168.100.100... -
Page 8: Connecting The Usb Device
3. Connecting the USB device Establishing a connection AK-USB-DeviceServer (XT-PICO-USB, ComPoint-USB or ConLine-USB2) recognizes a USB device on the USB connection, it is displayed in the program “USB Server“. All important information such as device, status and information are displayed here. - Page 9 Connecting the USB device In the next step please select your USB device. The selected USB device will be highlighted in green. Then select “Connect Device“ in order to connect the USB device to your PC. AK-USB Server Handbuch, Version 1.0...
- Page 10 Connecting the USB device If your USB device is connected to the PC, the status of the selected device changes to “locally connected “ and a green checkmark is displayed. Then Windows recognizes the USB device as a standard USB device connected to the USB port and you will possibly prompted to install the corresponding driver in order to guarantee the proper function.
-
Page 11: Disconnecting The Virtual Connection
Connecting the USB device Disconnecting the virtual connection It is possible to disconnect the virtual connection to the USB device at any time. Select “Disconnect device“. Note: We recommend you to always log out the USB memory devices (USB sticks, external drives, etc.) using the function of the operating system “Safely remove hardware”... -
Page 12: Error Messages
4. Error messages In use Icon: The device is used by another user and you cannot establish any connection to this device at present. AK-USB Server Handbuch, Version 1.0... -
Page 13: Other Segment
Error messages Other segment Icon: The question mark shows that the IP address of the AK-USB-DeviceServer is in another network segment. Check your network settings in the “Server configuration“. AK-USB Server Handbuch, Version 1.0... -
Page 14: Not Supported Device
Error messages Not supported device Icon: Devices with this icon are not supported. It is not possible to connect these devices. Inaccessible IP address Your IP address is inaccessible or your AK-USB-DeviceServer is not connected. Check the connecting cables to your AK-USB-DeviceServer or check your network settings. AK-USB Server Handbuch, Version 1.0... -
Page 15: Ak-Usb-Deviceserver Configuration
5. AK-USB-DeviceServer configuration Settings Using the program “USB Server“ you can perform settings on the AK-USB-DeviceServer. To do so, click with the right mouse button on the selected USB device. A submenu opens up. Click on “Server Configurations“. Then you are prompted to enter the preset password. The default password is “XT“. -
Page 16: Ip Addressing
Server configuration 5.1.1 IP addressing Upon successful authentification you enter the setup menu. It is possible to modify the “Server name“ in any way. In order to be able to modify the input fields “IP address“ and “Subnet“ you have to deactivate “Use DHCP “. Click on “Set”... -
Page 17: Backup Firmware
Server configuration 5.1.2 Backup firmware Do you want to save your firmware click on “Backup firmware“. A window opens up. Select the memory location for the firmware and click on “Save “. AK-USB Server Handbuch, Version 1.0... -
Page 18: Update Firmware
Server configuration 5.1.3 Update firmware If you want to update your product with the new firmware, click on “Update firmware“. A new window opens up. Select the new firmware and click on “Open“. Server- AK-USB Server Handbuch, Version 1.0... -
Page 19: Changing The Password
Server configuration 5.1.4 Changing the password Click on “Change Password“ if you want to change the password. A window “Change Password “. You can enter any password in the input field „New Password“. Repeat your entry in the field “Confirm New Password“ in order to confirm it. By clicking on the button “Submit“... -
Page 20: Web Interface
Server configuration Web interface Click on the button “Open Web Page“ after selecting the server in order to call the web interface of your AK-USB-DeviceServer. The browser opens up. AK-USB Server Handbuch, Version 1.0... -
Page 21: Status
Server configuration Status 5.2.2 You see the Status of the AK-USB-DeviceServers in the browser. The information of the current AK-USB-DeviceServer are displayed under “Server information”. The information of the connected USB device are displayed under “Device information“. AK-USB Server Handbuch, Version 1.0... -
Page 22: Network
Server configuration 5.2.3 Network You see the currently applicable settings for: IP address Subnet mask. Mac address. in the “Network information“ You can perform changes under “Network setting“ Enter the password and transfer the settings by clicking on the button “Submit“ in order to change the parameters. -
Page 23: Reset Device
Server configuration Reset Device 5.2.4 Click on “Reset Device“ in order to perform a restart of the AK USB DeviceServer. After entering the password click on “Submit“. The AK-USB-Server performs a restart. AK-USB Server Handbuch, Version 1.0... -
Page 24: Factory Default
Server configuration 5.2.5 Factory Default Click on “Factory Default“ in order to reset the AK-USB-DeviceServer in the delivery status. Click on “Submit“ after having entered the password. The AK-USB-server loads the standard settings and performs a restart. AK-USB Server Handbuch, Version 1.0... -
Page 25: Firmware Update
Server configuration 5.2.6 Firmware Update Under “Firmware Update“ you can update the AK-USB-DeviceServer with the latest version. Select the update file by clicking on the button “Browse”. Enter the password and transfer the settings by clicking on the button “Submit“. AK-USB Server Handbuch, Version 1.0... -
Page 26: Password Change
Server configuration 5.2.7 Password Change The access password can be changed. Enter your current password in the field “Current Password“. Enter any new password in the input field “New Password“. It must be repeated in the input field “Confirm New Password“... -
Page 27: Usb Server Menu
6. USB Server menu 6.1 File(F) By clicking on “Quit“ the program “USB Server“ is closed. When quitting the software all connections are disconnected. AK-USB Server Handbuch, Version 1.0... -
Page 28: Options(O)
USB Server menu 6.2 Options(O) Language. Automatic connection at program start. Server settings. Open website. Connect device. Disconnect device. Prompt to disconnect the device. Device features Automatically disconnect storage medium in case of inactivity. Automatically disconnect printer in case of inactivity. AK-USB Server Handbuch, Version 1.0... -
Page 29: View(V)
USB Server menu 6.3 View(V) Click on the button “Show Devices Only “, if you would like to see only the USB devices on the list. AK-USB Server Handbuch, Version 1.0... -
Page 30: Help(H)
USB Server menu 6.4 Help(H) Click on “About“ in order to see the USB server software information. Activate the “Log file“ in order to protocol all messages. The log file has the name “log.txt“ and is located in the installation folder of the AK-USB-DeviceServer program. AK-USB Server Handbuch, Version 1.0... -
Page 31: Hardware
7. Hardware ConLine-USB-XXL USB Plug TYPE B NETWORK LED’s POWER SUPPLY USB Jack TYPE A NETWORK LED’s POWER SUPPLY 1: Network link 2: Network activity AK-USB Server Handbuch, Version 1.0... - Page 32 ConLine-USB-XXL Description Technical description Voltage: Power supply 5 Volts / 1A Network connections: Ethernet 10/100MBit (M-DIX) RJ45 Network speeds: 10/100 MBit Full/Half Duplex Network protocols: IP, TCP, UDP, ICMP, ARP, LPR, DHCP, BOOTP, HTML, HTTP Interface functions: USB1.1/USB2.0 (high speed) Temperature range: from -10°...
-
Page 33: Ak-Dinrail-Usb
AK-DinRail-USB AK-DinRail-USB Technical description Dimensions: 22.5 x 120 mm(WxH) Voltage: 7-32 volts / 2,7 watt Network connections: Ethernet 10/100MBit (M-DIX) RJ45 Network speeds: 10/100 MBit Full/Half Duplex Network protocols: IP, TCP, UDP, ICMP, ARP, LPR, DHCP, BOOTP, HTML, HTTP Interface functions: USB1.1/USB2.0 (Hi-speed) Special features: up to 4 USB devices... - Page 34 AK-DinRail-USB Description and connection assignment USB – Jack TYPE A USB4 USB3 USB - Connectors USB2 USB1 Network Power supply Shield + 7-32 2,7 watt - 7-32 2,7 watt Power supply Power LED Network link Reset - Button Network activities Status LED USB1 connected USB2 connected...
-
Page 35: Ak-Railport-Usb
AK-RailPort-USB AK-RailPort-USB Technical description Dimensions: 87 x 62 mm(WxH) Voltage: 7-32 volts / 2,7 watt Network connections: Ethernet 10/100MBit (M-DIX) RJ45 Network speeds: 10/100 MBit Full/Half Duplex Network protocols: IP, TCP, UDP, ICMP, ARP, LPR, DHCP, BOOTP, HTML, HTTP Interface functions: USB1.1/USB2.0 (Hi-speed) Special features: up to 4 USB devices... - Page 36 AK-RailPort-USB Description and connection assignment USB – Jack TYPE A USB4 USB3 USB2 USB - Connectors USB1 Power supply Shield + 7-32 2,7 watts - 7-32 2,7 watts Network Power LED Network link Network activities Status LED USB1 connected USB2 connected USB3 connected USB4 connected Reset - Button...
-
Page 37: Compoint-Lan-Usb
ComPoint-LAN-USB ComPoint-LAN-USB Technical description Dimensions: 100 x 28 x 110 mm (W x H x L) Voltage: Power supply 5 volts / 2A Optional: via PowerOverEthernet IEEE802.3af via switching regulator 34 volts Network connections: Ethernet 10/100MBit (MDIX) RJ45 Network speeds: 10/100 MBit Full/Half Duplex Network protocols: IP, TCP, UDP, ICMP, ARP, LPR, DHCP, BOOTP, HTML, HTTP... - Page 38 ComPoint-LAN-USB Description USB socket TYPE A NETWORK LED’s POWER SUPPLY LED’s (front view) 1: Status LED 2: Network link 3: Network activity 4: Power LED AK-USB Server Handbuch, Version 1.0...
-
Page 39: Xt-Pico-Usb
XT-PICO-USB XT-PICO-USB Ethernet RJ45 / POE USB connection Technical description Dimensions: 32 x 22 mm Voltage / Power consumption: 1.8 volts / about 120 mA 3.3 volts / about 110 mA Network connections: Ethernet 10/100MBit (MDIX) RJ45 (PoE pins are executed ) Network speeds: 10/100 MBit Full/Half Duplex Network protocols:... - Page 40 XT-PICO-USB Description Bottom View AK-NORD XT-PICO-USB PIN9 PIN9 PIN9 PIN9 XT-PICO-USB PIN1 PIN1 PIN1 PIN1 AK-USB Server Handbuch, Version 1.0...
- Page 41 XT-PICO-USB Everything you need is a RJ45 female connector and two LED’s. It is possible to directly use the LED connections. The series resistors are already available on the XT-PICO-USB. Also the RJ45 connections can be directly connected on the RJ45 female connector. The necessary transmitter is also available on the XT-PICO- USB.
