Instruction Manual
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shipping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Distances to respect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance and cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A5
For more information, please contact our office: . . . . . . . . . . . . . . . . . . . .
DRP3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRPR3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRP4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRPR4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRP4S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRPR4S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B6
DRP3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRPR3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRP4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRPR4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRP4S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRPR4S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E11
SECTION « G » ELECTRIC SCHEMATICS
DRP3 - 120V/1PH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . .
PIZZA WARMER
DRP3 & DRPR3
DRP4 & DRPR4
DRP4S & DRPR4S
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
CAREFULLY FOLLOW THESE INSTRUCTIONS
TABLE OF CONTENTS
DANGER
PAGE
A1
A2
A2
A3
A4
A6
B1
B2
B3
B4
B5
E1
E3
E5
E7
E9
G1
Advertisement
Table of Contents
Related Manuals for Doyon DRP4
Summary of Contents for Doyon DRP4
-
Page 1: Table Of Contents
DRP4 ........ - Page 2 DRP4 - 230V/1PH/50 Hz ........
-
Page 3: Section « A » Description
SECTION DESCRIPTION... -
Page 4: Introduction
A nameplate specifies the model number, serial number, voltage, amperage, frequency and manufacturing date. Drawings, electrical diagram and replacement parts numbers are included in this manual. DOYON is not responsible for damages to the property or the equipment caused by personnel who is not certified by known organisations. INTRODUCTION... -
Page 5: Shipping
SHIPPING For your safety, this equipment has been verified by qualified technicians and carefully crated before shipment. The freight company assumes full responsibility concerning the delivery in good condition of the equipment in accepting to transport it. IMPORTANT RECEPTION OF THE MERCHANDISE Take care to verify that the received equipment is not damaged before signing the delivery receipt. -
Page 6: Distances To Respect
DISTANCES TO RESPECT You must keep a clearance of one-inch (1") from combustibles material which includes the back, the top and the sides of the warmer. GENERALITIES Take off the packaging material with care. Take off all the material used for packing and accessories. -
Page 7: Operation
DRP3 & DRP4 Fill the pan with water. Turn the switch "on". Adjust the thermostat at 175° F. DRP3R & DRPR4 Fill the pan with water. Turn the two switches "on". Adjust the thermostat at 175° F. * To stop the rotation of the rack only, turns the right switch "off". -
Page 8: Maintenance And Cleaning
OVEN MAINTENANCE AND CLEANING Step by step Clean the inside of the warmer with water and soap Take out the grills (the grills of the oven could be cleaned with "Easy-Off") After cleaning the inside of the warmer, apply a silicone base oven protector. avoids food from sticking to the metal. -
Page 9: For More Information, Please Contact Our Office
FOR MORE INFORMATION, PLEASE CONTACT OUR OFFICE: DOYON EQUIPMENT INC. 1255, rue Principale, C.P. 250 Linière, Qc, Canada G0M 1J0 Tel. : 1 (418) 685-3431 Canada : 1 (800) 463-1636 U.S. : 1 (800) 463-4273 FAX : 1 (418) 685-3948 Internet: http://www.doyon.qc.ca... -
Page 10: Section « B » Dimensions
SECTION DIMENSIONS... -
Page 11: Drp3
DRP3 DRP3... -
Page 12: Drpr3
DRPR3 DRPR3... -
Page 13: Drp4
DRP4 DRP4... -
Page 14: Drpr4
DRPR4 DRPR4... -
Page 15: Drp4S
DRP4S DRP4S... -
Page 16: Drpr4S
DRPR4S DRPR4S... -
Page 17: Section « E » Component Parts
SECTION COMPONENT PARTS... -
Page 18: Drp3
DRP3 DRP3... - Page 19 Item Part Number Description 50010823 DRP-3 & DRPR3 HINGE VT1916 TEMPERED GLASS 5 MM ELA325 BULB 40W 120V ELD050 INCANDESCENT LIGHT SOCKET 50010824 DRP-3 & DRPR3 HANDLE VT1815 TEMPERED GLASS 5 MM ELE125 STRAIGHT ELEMENT 120V 1000W ELE124 STRAIGHT ELEMENT 240V 1500W FOR MODEL 220V 50HZ ELF015 120V MALE PLUG &...
-
Page 20: Drpr3
DRPR3 DRPR3... - Page 21 Item Part Number Description 50010823 DRP-3 & DRPR3 HINGE VT1916 TEMPERED GLASS 5 MM ELA325 BULB 40W 120V ELD050 INCANDESCENT LIGHT SOCKET 50010824 DRP-3 & DRPR3 HANDLE VT1815 TEMPERED GLASS 5 MM ELE125 STRAIGHT ELEMENT 120V 1000W ELE124 STRAIGHT ELEMENT 240V 1500W FOR MODEL 220V 50HZ ELF015 120V MALE PLUG &...
-
Page 22: Drp4
DRP4 DRP4... - Page 23 THERMOSTAT 250F & ELT622 THERMOSTAT BEZEL & ELT615 THERMOSTAT KNOB 250F ELL650 RED PILOT LIGHT RFTH06 THERMOMETER 40-240°F ELI635 SWITCH 20A/130V - 15A/240 V P. LIGHT PAP700 ADJUSTABLE CHROMED LEG ELM759 COOLING FAN Model : DRP4 View : BACK Quantity...
-
Page 24: Drpr4
DRPR4 DRPR4... - Page 25 Item Part Number Description 50010821 DRP-4 & DRPR4 HINGE VT2121 TEMPERED GLASS 5 mm 50010822 DRP-4 & DRPR4 HANDLE ELD050 INCANDESCENT LIGHT SOCKET ELA275 BULB 60W 130V VT2020 TEMPERED GLASS 5 mm ELE127 HEATING ELEMENT 1250 WATTS 120 VOLTS ELE124 STRAIGHT ELEMENT 240V 1500W FOR MODEL 220V 50HZ ELF015 120V MALE PLUG &...
-
Page 26: Drp4S
DRP4S DRP4S... - Page 27 Item Part Number Description 50010821 DRP-4 & DRPR4 HINGE VT2121 TEMPERED GLASS 5 mm 50010822 DRP-4 & DRPR4 HANDLE ELD050 INCANDESCENT LIGHT SOCKET ELA275 BULB 60W 130V VT2020 TEMPERED GLASS 5 mm ELE127 HEATING ELEMENT 1250 WATTS 120 VOLTS ELE124 STRAIGHT ELEMENT 240V 1500W FOR MODEL 220V 50HZ ELF015 120V MALE PLUG &...
-
Page 28: Drpr4S
E-11 DRPR4S DRPR4S... - Page 29 Item Part Number Description 50010821 DRP-4 & DRPR4 HINGE VT2121 TEMPERED GLASS 5 mm 50010822 DRP-4 & DRPR4 HANDLE ELD050 INCANDESCENT LIGHT SOCKET ELA275 BULB 60W 130V VT2020 TEMPERED GLASS 5 mm ELE127 HEATING ELEMENT 1250 WATTS 120 VOLTS ELE124 STRAIGHT ELEMENT 240V 1500W FOR MODEL 220V 50HZ ELF015 120V MALE PLUG &...
-
Page 30: Electric Schematic
SECTION ELECTRIC SCHEMATIC... - Page 38 DOOR SWITCH...
- Page 40 G-10...
-
Page 41: Limited Warranty
LIMITED WARRANTY (Continental United States Of America And Canada Only) Doyon Equipment Inc. guarantees to the original purchaser only that its product are free of defects in material and workmanship, under normal use. This warranty does not cover any light bulbs, thermostat calibration or defects due to or resulting...
