TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
CAREFULLY FOLLOW THESE INSTRUCTIONS
SECTION « A » DESCRIPTION
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shipping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Distances to respect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A3
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance and cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A5
For more information, please contact our office: . . . . . . . . . . . . . . . . . . . . A6
DRP3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRPR3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B2
DRP4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRPR4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B4
DRP4S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRPR4S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B6
DRP3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRPR3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E3
DRP4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRPR4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E7
DRP4S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRPR4S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E11
SECTION « G » ELECTRIC SCHEMATICS
DRP3 - 120V/1PH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . .
All manuals and user guides at all-guides.com
PIZZA WARMER
DRP3 & DRPR3
DRP4 & DRPR4
DRP4S & DRPR4S
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
DANGER

TABLE OF CONTENTS

PAGE
A2
G1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DRP3 and is the answer not in the manual?

Questions and answers

Related Manuals for Doyon DRP3

Summary of Contents for Doyon DRP3

  • Page 1: Table Of Contents

    DRP3 - 120V/1PH ........
  • Page 2 DRP3 - 230V/1PH/50 Hz ........
  • Page 3 All manuals and user guides at all-guides.com SECTION DESCRIPTION...

  • Page 4: Introduction

    A nameplate specifies the model number, serial number, voltage, amperage, frequency and manufacturing date. Drawings, electrical diagram and replacement parts numbers are included in this manual. ATTENTION DOYON is not responsible for damages to the property or the equipment caused by personnel who is not certified by known organisations.

  • Page 5: Shipping

    All manuals and user guides at all-guides.com SHIPPING For your safety, this equipment has been verified by qualified technicians and carefully crated before shipment. The freight company assumes full responsibility concerning the delivery in good condition of the equipment in accepting to transport it. IMPORTANT RECEPTION OF THE MERCHANDISE Take care to verify that the received equipment is not damaged before signing the delivery receipt.

  • Page 6: Distances To Respect

    All manuals and user guides at all-guides.com DISTANCES TO RESPECT You must keep a clearance of one-inch (1") from combustibles material which includes the back, the top and the sides of the warmer. GENERALITIES Take off the packaging material with care. Take off all the material used for packing and accessories.

  • Page 7: Operation

    All manuals and user guides at all-guides.com OPERATION DRP3 & DRP4 Fill the pan with water. Turn the switch "on". Adjust the thermostat at 175° F. DRP3R & DRPR4 Fill the pan with water. Turn the two switches "on". Adjust the thermostat at 175° F.

  • Page 8: Maintenance And Cleaning

    All manuals and user guides at all-guides.com OVEN MAINTENANCE AND CLEANING Step by step Recommendations Clean the inside of the warmer with water We recommend and sell: and soap Durt Buster III : Action foam cleaner. CHEMCO Part number : NEB201 Take out the grills (the grills of the oven could be cleaned with "Easy-Off") After cleaning the inside of the warmer,...

  • Page 9: For More Information, Please Contact Our Office

    All manuals and user guides at all-guides.com FOR MORE INFORMATION, PLEASE CONTACT OUR OFFICE: DOYON EQUIPMENT INC. 1255, rue Principale, C.P. 250 Linière, Qc, Canada G0M 1J0 Tel. : 1 (418) 685-3431 Canada : 1 (800) 463-1636 U.S. : 1 (800) 463-4273 FAX : 1 (418) 685-3948 Internet: http://www.doyon.qc.ca...

  • Page 10: Section « B » Dimensions

    All manuals and user guides at all-guides.com SECTION DIMENSIONS...

  • Page 11: Drp3

    All manuals and user guides at all-guides.com DRP3 DRP3...

  • Page 12: Drpr3

    All manuals and user guides at all-guides.com DRPR3 DRPR3...

  • Page 13: Drp4

    All manuals and user guides at all-guides.com DRP4 DRP4...

  • Page 14: Drpr4

    All manuals and user guides at all-guides.com DRPR4 DRPR4...

  • Page 15: Drp4S

    All manuals and user guides at all-guides.com DRP4S DRP4S...

  • Page 16: Drpr4S

    All manuals and user guides at all-guides.com DRPR4S DRPR4S...

  • Page 17: Section « E » Component Parts

    All manuals and user guides at all-guides.com SECTION COMPONENT PARTS...

  • Page 18: Drp3

    All manuals and user guides at all-guides.com DRP3 DRP3...
  • Page 19 ELT610 THERMOSTAT 250F & ELT622 THERMOSTAT BEZEL & ELT615 THERMOSTAT KNOB 250F ELL650 RED PILOT LIGHT RFTH06 THERMOMETER 40-240°F ELI635 SWITCH 20A/130V - 15A/240 V P. LIGHT PAP700 ADJUSTABLE CHROMED LEG ELM759 COOLING FAN Model : DRP3 View : BACK...

  • Page 20: Drpr3

    All manuals and user guides at all-guides.com DRPR3 DRPR3...
  • Page 21 THERMOMETER 40-240°F ELI635 SWITCH 20A/130V - 15A/240 V P. LIGHT ELM759 COOLING FAN ELM938 GEARMOTOR DAYTON 7 RPM 120 V ELM937 GEARMOTOR DAYTON5,87 RPM 220V 50HZ QURB013 THRUST BEARING PAP700 ADJUSTABLE CHROMED LEG Model : DRP3 ROTATIF View : BACK...

  • Page 22: Drp4

    All manuals and user guides at all-guides.com DRP4 DRP4...
  • Page 23 All manuals and user guides at all-guides.com Item Part Number Description Quantity 50010821 DRP-4 & DRPR4 HINGE VT2121 TEMPERED GLASS 5 mm 50010822 DRP-4 & DRPR4 HANDLE ELD050 INCANDESCENT LIGHT SOCKET ELA275 BULB 60W 130V VT2020 TEMPERED GLASS 5 mm ELE127 HEATING ELEMENT 1250 WATTS 120 VOLTS ELE124...

  • Page 24: Drpr4

    All manuals and user guides at all-guides.com DRPR4 DRPR4...
  • Page 25 All manuals and user guides at all-guides.com Item Part Number Description Quantity 50010821 DRP-4 & DRPR4 HINGE VT2121 TEMPERED GLASS 5 mm 50010822 DRP-4 & DRPR4 HANDLE ELD050 INCANDESCENT LIGHT SOCKET ELA275 BULB 60W 130V VT2020 TEMPERED GLASS 5 mm ELE127 HEATING ELEMENT 1250 WATTS 120 VOLTS ELE124...

  • Page 26: Drp4S

    All manuals and user guides at all-guides.com DRP4S DRP4S...
  • Page 27 All manuals and user guides at all-guides.com E-10 Item Part Number Description Quantity 50010821 DRP-4 & DRPR4 HINGE VT2121 TEMPERED GLASS 5 mm 50010822 DRP-4 & DRPR4 HANDLE ELD050 INCANDESCENT LIGHT SOCKET ELA275 BULB 60W 130V VT2020 TEMPERED GLASS 5 mm ELE127 HEATING ELEMENT 1250 WATTS 120 VOLTS ELE124...

  • Page 28: Drpr4S

    All manuals and user guides at all-guides.com E-11 DRPR4S DRPR4S...
  • Page 29 All manuals and user guides at all-guides.com E-12 Item Part Number Description Quantity 50010821 DRP-4 & DRPR4 HINGE VT2121 TEMPERED GLASS 5 mm 50010822 DRP-4 & DRPR4 HANDLE ELD050 INCANDESCENT LIGHT SOCKET ELA275 BULB 60W 130V VT2020 TEMPERED GLASS 5 mm ELE127 HEATING ELEMENT 1250 WATTS 120 VOLTS ELE124...
  • Page 30 All manuals and user guides at all-guides.com SECTION ELECTRIC SCHEMATIC...
  • Page 31 All manuals and user guides at all-guides.com...
  • Page 32 All manuals and user guides at all-guides.com...
  • Page 33 All manuals and user guides at all-guides.com...
  • Page 34 All manuals and user guides at all-guides.com...
  • Page 35 All manuals and user guides at all-guides.com...
  • Page 36 All manuals and user guides at all-guides.com...
  • Page 37 All manuals and user guides at all-guides.com...
  • Page 38 All manuals and user guides at all-guides.com DOOR SWITCH...
  • Page 39 All manuals and user guides at all-guides.com...
  • Page 40 All manuals and user guides at all-guides.com G-10...
  • Page 41 LIMITED WARRANTY (Continental United States Of America And Canada Only) Doyon Equipment Inc. guarantees to the original purchaser only that its product are free of defects in material and workmanship, under normal use. This warranty does not cover any light bulbs, thermostat calibration or defects due to or resulting...

This manual is also suitable for:

Drpr3Drp4sDrp4Drpr4sDrpr4

Table of Contents
