- Page 1 Installing and Using Water Meter DOYON DAF001V3 Release V2.0 March 2005...
- Page 2 1 Installation (DAF001V3) 24 Vac/dc, 50/60 24Vac - 50/60Hz 3/8 Female 1/2 Male The set is supplied together with the water meter. You must always use the filter or small particles will damage the meter and your dough will be dirty and unusable.
- Page 3 2 Using the water meter Description of the electronic controls 1 – Dosing “ON” (valve open) 2 – Start / stop dosing March 2005...
- Page 4 3 – Water quantity preset 4 – Increase water quantity preset 5 – Decrease water quantity preset 6 – Power on / off 7 – Water temperature (ºC or ºF) 8 – Quantity since last reset 9 – Water quantity reset March 2005...
- Page 5 . No need to press key and set the new value with keys , while the water meter is powered off (but several times while the water . If you need to...
- Page 6 3 Technical data Electrical data Power Supply o 24 Vac/dc 50/60Hz Power consumption: 17VA Protection: fuse T800mA, 20 x 5 mm Working temperature: 0º to 60ºC Relative humidity: 0% to 80% without condensing. Hydraulic data Min. pressure: 0,25bar (3,6psi) Max. pressure: 8 bar (116psi) Bursting pressure: 200bar (2900psi) Water temperature reading range from 0,0ºC to 99,5ºC Water metering from 0,1 to 99,9 litres/...
- Page 7 FOR MORE INFORMATION, PLEASE CONTACT OUR OFFICE: DOYON EQUIPMENT INC. 1255, rue Principale Linière, Qc, Canada G0M 1J0 Tel. : 1 (418) 685-3431 Canada : 1 (800) 463-1636 U.S. : 1 (800) 463-4273 FAX : 1 (418) 685-3948 Internet: http://www.doyon.qc.ca E-Mail : doyon@doyon.qc.ca...
- Page 8 Doyon Equipment Inc. does hereby exclude and shall not be liable to purchaser for any consequential or incidental damages including, but not limited to, damages to property, damages for loss of use, loss of time, loss of profits or income, resulting from any breach or warranty.
