ENGLISH
INSTALLATION MANUAL
Thank you for buying this Briteq
please read these operating instructions very carefully before you start using this unit.
FEATURES
• This kit adapts the "BT-THEATRE YOKE" perfectly to the BT-THEATRE 100MZ and BT-THEATRE 200TW
theatre Fresnel.
• The kit consists of these extra parts:
• 2x Custom-made nylon cylinder
• 8x M4 "Phillips head" bolt L=25mm
• All installation accessories for easy installation are included
MECHANICAL ASSEMBLY:
DIFFERENT PARTS
You will not need all parts: here is a selection of the parts that you will need / not need anymore.
OLD BRACKET: NOT NEEDED ANYMORE
PARTS NEEDED FOR THE ASSEMBLY
BRITEQ
®
®
product. To take full advantage of all possibilities and for your own safety,
1/2
INSTALLATION MANUAL V1.0
BT-THEATRE YOKE ADAPTER-2
Advertisement
Related Manuals for Briteq BT-THEATRE YOKE
Summary of Contents for Briteq BT-THEATRE YOKE
- Page 1 To take full advantage of all possibilities and for your own safety, please read these operating instructions very carefully before you start using this unit. FEATURES • This kit adapts the “BT-THEATRE YOKE” perfectly to the BT-THEATRE 100MZ and BT-THEATRE 200TW theatre Fresnel. • The kit consists of these extra parts: •...
- Page 2 4. Remove the current black cylinders on both sides of the projector: not needed anymore! 5. Instead fix the new aluminum cylinder from the BT-THEATRE YOKE and the nylon cylinder from the ADAPTER-2 set on both sides of the projector. To do this, use the 8 new M4-bolts included with ADAPTER- 2 set 6.
