(Administrator Mode Edition)
This manual introduces how to add a new print mode and how to
perform spot color printing using that mode.
The steps introduced here use spot color inks such as gloss and
white ink to create the desired effect for the product.
Thank you very much for purchasing this product.
• To ensure correct and safe usage with a full understanding of this product's performance, please be sure to read
through this manual completely and store it in a safe location.
• Unauthorized copying or transferal, in whole or in part, of this manual is prohibited.
• The specifications of this product and the contents of this operation manual are subject to change without notice.
• The operation manual and the product have been prepared and tested as much as possible. If you find any
misprints or errors, please inform us.
• Roland DG Corporation assumes no responsibility for any direct or indirect loss or damage that may occur through
use of this product, regardless of any failure to perform on the part of this product.
• Roland DG Corporation assumes no responsibility for any direct or indirect loss or damage that may occur with
respect to any article made using this product.
Special Color Ink Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the IU-1000F and is the answer not in the manual?

Questions and answers

Related Manuals for Roland IU-1000F

Summary of Contents for Roland IU-1000F

  • Page 1 • Roland DG Corporation assumes no responsibility for any direct or indirect loss or damage that may occur through use of this product, regardless of any failure to perform on the part of this product.
  • Page 2 Company names and product names are trademarks or registered trademarks of their respective holders. http://www.rolanddg.com/ Copyright © 2020 Roland DG Corporation...

  • Page 3: Table Of Contents

    Contents Contents ......................................3 Customizing Print Settings ................................4 Introduction ..................................4 Printing with Transparent Media and Matte Finishing .......................5 Using Emboss to Make Patterns and Characters Stand Out ..................10 Three-Layer Printing for Backlit Panels..........................14...

  • Page 4: Customizing Print Settings

    Adding a print mode is only possible in administrator mode. However, please note that adding print modes is not covered by the warranty. For information on how to log into administrator mode, refer to the IU-1000F Operating Instructions — Administrator Mode Guide.

  • Page 5: Printing With Transparent Media And Matte Finishing

    Printing with Transparent Media and Matte Finishing [1]: Gloss printing (matte finish) on the pattern [2]: Pattern printing [3]: White printing for improved color development [4]: Primer printing between the ink and the media to promote ink adhesion Procedure Create the print data and save it as a rasterized file. Create the print data using Adobe Illustrator or some other drawing software.
  • Page 6 Printing with Transparent Media and Matte Finishing Start Print Control and enter administrator mode. Open the file saved in with Print Control, and double-click the added job. The "Properties" window for the job appears. Click [Print Mode]. The "Print Edit mode" window appears. Create a new print mode.
  • Page 7 Printing with Transparent Media and Matte Finishing Create a new color mode and configure the settings. Enter a name for the new color mode. Click [New]. Set "White" to "RIP Data." Set "Gloss" to "RIP Data." Set "Primer" to "RIP Data." Select "More..."...
  • Page 8 Printing with Transparent Media and Matte Finishing Select the layout created in Select the newly created layout in the "Layout" pulldown list. Click [Save]. Click [Close]. The "Color Mode Setting" window closes, and the "Print Edit mode" window appears. Select the color mode created in Select the newly created color mode in the "Color Mode Setting"...
  • Page 9 Printing with Transparent Media and Matte Finishing Select the print mode created in and begin printing. Select the newly created print mode in the "Print Mode" pulldown list. Click [OK]. If the displayed media thickness is correct, click [Print]. If the maintenance station height is correct, click [Yes]. Printing starts.

  • Page 10: Using Emboss To Make Patterns And Characters Stand Out

    Using Emboss to Make Patterns and Characters Stand Out Using a gloss layer provides an uneven surface, creating an embossed product. Because the gloss layer can result in a slightly yellowish color, the gloss layer should be placed under the pattern. However, the color of the gloss can affect the color of the pattern, so a white layer must be printed between the gloss and the pattern.
  • Page 11 Using Emboss to Make Patterns and Characters Stand Out Start Print Control and enter administrator mode. Open the file saved in with Print Control, and double-click the added job. The "Properties" window for the job appears. Click [Print Mode]. The "Print Edit mode" window appears. Create a new print mode.
  • Page 12 Using Emboss to Make Patterns and Characters Stand Out Create a new color mode and configure the settings. Enter a name for the new color mode. Click [New]. Set "White" to "RIP Data." Set "Gloss" to "RIP Data." Set "Primer" to "Do not Print." Select "More..."...
  • Page 13 Using Emboss to Make Patterns and Characters Stand Out Select the layout created in Select the newly created layout in the "Layout" pulldown list. Click [Save]. Click [Close]. The "Color Mode Setting" window closes, and the "Print Edit mode" window appears. Select the color mode created in Select the newly created color mode in the "Color Mode Setting"...

  • Page 14: Three-Layer Printing For Backlit Panels

    Three-Layer Printing for Backlit Panels To minimize the difference between when the backlight is on or off, print the panel using three layers in the order of Pattern – White – Pattern. To print the entire printing area white, Print Control can be used for printing. Although the print data can include a white print layer, this section introduces how to print white using Print Control.
  • Page 15 Three-Layer Printing for Backlit Panels Create a new print mode. Enter a new name in "Current Mode." Click [New]. Click [Color Mode]. The "Color Mode Setting" window appears. Create a new color mode and configure the settings. Enter a name for the new color mode. Click [New].
  • Page 16 Three-Layer Printing for Backlit Panels Configure and save the settings for the new layout. Enter a name for the layout. (Example: 4C - Wh - 4C) Click [New]. Set the number of layers to 3. Configure the settings for each layer as shown in the figure. Click [Save].
  • Page 17 Three-Layer Printing for Backlit Panels Select the color mode created in Select the newly created color mode in the "Color Mode Setting" pulldown list. Click [Save]. Click [Close]. The "Print Edit mode" window closes, and the "Properties" window appears. Select the print mode created in and begin printing.
  • Page 18 FA02148 R1-200331...
