Stick Logger Quick Guide
Model:LSW-4
Notice:
Please read this manual carefully before using products and keep it
in the place where O&M providers can easily find.
Due to product upgrade and other factors, the content of this manual
might change from time to time. Please take actual product as standard
and get latest manual from www.solarman.cn or sales. Unless other-
wise agreed herein, this manual will only be used as guidance. Any
statement, information or suggestion in this manual will not take any
form of responsibility.
Without written permission, any content of this document (partly or en-
tirely) cannot be extracted, copied or transmitted in any form by any
company or individual.
Warning:
Please remove logger after power off.
for iOS
for Andriod
SOLARMAN for end user
SOLARMAN PRO for business
1. Stick Logger Installation
Type 1
Step1: Assemble logger to the inverter communication interface as shown
in the diagram.
1
Type 2
Step1: Assemble logger to the inverter communication interface as shown
in the diagram.
Warning:
Please do not hold the logger body to rotate while
install or remove the logger.
2. Logger Status
2.1 Check Indicator light
Lights
Implication
Status Description(All lights are single green lights.)
1.Light off: Connection to the router failed.
Communication
2.On 1s/Off 1s(Slow flash): Connection to the router succeeded.
with router
3.Light keeps on: Connection to the server succeeded.
NET
4.On 100ms/Off 100ms(Fast flash): Distributing network fast.
1.Light keeps on: Logger connected to the inverter.
Communication
2.Light off: Connection to the inverter failed.
with inverter
COM
3.On 1s/Off 1s(Slow flash): Communicating with inverter.
1
1.Light off: Running abnormally.
Logger running
2.On 1s/Off 1s (Slow flash): Running normally.
status
READY
3.On 100ms/Off 100ms(Fast flash): Restore factory settings.
The normal operation status of the stick logger, when router connected
to the network normally:
1.Connection to the server succeeded: NET light keeps on after the
logger powered on.
2.Logger running normally: READY light flashes.
3.Connection to the inverter succeeded: COM light keeps on.
3. Abnormal State Processing
If the data on platform is abnormal when the stick logger is running,
please check the table below and according to the status of indicator
lights to complete a simple troubleshooting. If it still can not be resol-
ved or indicator lights status do not show in the table below, please
contact Customer Support.
(Note: Please using the following table query after power-on for 2mins
at least.)
for iOS
for Andriod
NET
COM
READY
Fault Description
NET
COM
READY
1.Connection betw-
een stick logger and
inverter loosen.
Any
Slow
Communication with
OFF
2.Inverter does not
state
flash
inverter abnormal
match with stick log-
ger's communication
rate.
1.Stick logger does
Connection between
not have a network.
Slow
OFF
ON
logger and router
2.Antenna abnormal
flash
abnormal
3.Router WiFi signal
strength weak.
1.Router networking
Connection betwe-
abnormal.
en logger and router
2.The server point
Slow
Slow
normal, connection
ON
of logger is modified.
flash
flash
between logger and
3.Network limitation,
remote server
server cannot be
abnormal.
connected.
1.Connection betw-
een stick logger and
inverter loosen or
Power supply
abnormal.
OFF
OFF
OFF
abnormal
2.Inverter power in-
sufficient.
3.Stick Logger abn-
ormal.
Fast
Any
Any
SMARTLINK
flash
state
state
networking status
Any
Any
Fast
Restore
state
state
flash
factory settings
4. Usage methods and notices for Reset button
4.1 Usage methods and key-press descriptions for Reset button
Usage: Press
Key-press
Status Description
Short press 1s
SMARTLINK rapid networking status.
Long press 5s
Rebooting the stick logger.
Long press 10s
Resetting the stick logger.
4.2 Notices for Reset button
Notice:
Do not remove waterproof plug.
(It is not necessary to modify other information because APP has
obtained local electricity price and FIT already.)
Fault Cause
Solution
1.Check the connection between
stick logger and inverter. Remove
the stick logger and install again.
2.Check inverter's communication
rate to see if it matches with stick
logger's.
3.Long press Reset button for 5s,
reboot stick logger.
1.Check if the wireless network
configured.
2.Check the antenna, if there is any
damage or loose.
3.Enhance router WiFi signal
strength.
4.Long press Resetbutton for 10s,
reboot stick logger and networking
again.
1.Check if the router has access to
the network.
2.Check the router's setting, if the
connection is limited.
3.Contact our customer service.
1.Check the connection, remove the
stick logger and install again.
2.Check inverter output power.
3.Contact our customer service.
1.Exit automatically after 5mins.
2.Long press Reset button for 5s,
Normal
reboot stick logger.
3.Long press Reset button for 10s,
restore factory settings.
1.Exit automatically after 1mins.
2.Long press Reset button for 5s,
Normal
reboot stick logger.
3.Long press Reset button for 10s,
restore factory settings.
Light Status
NET light flashes fast for 100ms.
All lights are extinguished immediately.
1.All lights are extinguished after 4s.
2.READY light flashes fast for 100ms.
SN:1703520003
