Summary of Contents for Excelsecu Data Technology eSecu FIDO2 Pro Security Key
- Page 1 FIDO2 Pro Security Key User Manual (V2.2) Excelsecu Data Technology Co., Ltd. www.excelsecu.com...
- Page 2 CONFIDENTIAL information of Excelsecu Data Technology Co., Ltd. NO WARRANTIES OF ANY NATURE ARE EXTENDED BY THIS DOCUMENT. Any product and related material disclosed herein are only furnished pursuant and subject to the terms and conditions of a duly executed Program Product Licence or Agreement to purchase or lease equipment.
-
Page 3: Table Of Contents
Table of Content Product Overview ..........................4 Product Picture ............................. 4 The Basic Operation ..........................5 3.1. Register (First Time Only) ......................5 3.2. Signing-In (After Completing Registration) ................5 3.2.1. Bluetooth Pairing Mode (First Time Only) ..............5 3.2.2. Bluetooth Mode (Paired Before) ................. -
Page 4: Product Overview
Thank You for Using eSecu FIDO2 Pro Security Key IMPORTANT INSTRUCTIONS Please read this manual before operating your eSecu FIDO2 Pro Security Key and keep it for future reference. 1. Product Overview eSecu FIDO2 Pro Security Key is a hardware authenticator supporting FIDO2 standard and FIDO U2F standard, as well as Bluetooth, NFC and USB communication interfaces. -
Page 5: The Basic Operation
Steady white light: 1. When the eSecu FIDO2 Pro Security Key is plugged into a computer’s USB port. 2. When the eSecu FIDO2 Pro Security Key is placing on an NFC card reader or on the NFC sensor of a mobile device. -
Page 6: Bluetooth Mode (Paired Before)
3. Input 6-digits PIN as printed on the back of the eSecu FIDO2 Pro Security Key. When paired successfully, the blue light should start blinking. 4. When an authentication request is received, the light blinks white, simply press the button on your eSecu FIDO2 Pro Security Key to complete the authentication. -
Page 7: How To Use Fido2 Pro Security Key For 2-Step Verification
4. How to use FIDO2 Pro Security Key for 2-Step Verification 4.1. Register Register FIDO2 Security Key with your Google account to make it become the second authentication factor. The registration can only be done from a non-mobile device. Log in to the website: https://www.google.com and click Sign In on the top right corner. - Page 8 You will be asked to log in again. Click ADD SECURITY KEY. You will be prompted to insert your FIDO2 security key into a USB port. Click NEXT to continue. www.excelsecu.com...
- Page 9 When the white light of the key is flashing, short press the button on the eSecu FIDO2 Pro Security Key. Rename the your security key, click DONE to finish. www.excelsecu.com...
- Page 10 The eSecu FIDO2 Pro Security Key becomes the default second authentication factor of your account. You will be asked to use it to complete 2-Step Verification when sign in to Google in the future. www.excelsecu.com...
-
Page 11: Sign In (Usb Mode)
(e.g. 4-digit PIN) without compromising security. 2. Insert eSecu FIDO2 Pro Security Key to a USB port and tap the button on the key. You will be authorized to access your Google account now. -
Page 12: Sign In (Bluetooth + Android Mobile Device)
Click Revoke All to clear the trusted device and restore the use of two-step verification. 4.3. Sign in (Bluetooth + Android Mobile Device) When using the eSecu FIDO2 Pro Security Key on an Android mobile device for the first time with Bluetooth connection, you need to pair them first. - Page 13 4. Press and hold the button on your eSecu FIDO2 Pro Security Key for over 5 seconds to active the Bluetooth pairing mode, the blue indicator light on the key shall steady on. 5. When the Android device detects the signal of the key, the serial number printed on the back of the key will show on the page.
- Page 14 Google service will automatically verify your security key. 6. When the eSecu FIDO2 Pro Security Key receives an authentication request, the indicator light changes to flashing white from flashing blue, short press the button on the key to confirm the authentication, then you will be authorized to login with your account.
-
Page 15: Sign In (Nfc + Android Mobile Device)
7. When you are asked to do the 2-Step Verification on a paired Android device again, go through the Step 1~3 above, no need click on Pair another Security Key, just short press the button on the eSecu FIDO2 Pro Security Key to enter the Bluetooth mode, and the indicator light shall flash blue. When the key receives an authentication request, the indicator light changes to flashing white from flashing blue, short press the button again on the key to confirm the authentication, then you will be authorized to login with your account. - Page 16 Key for verification, click on Use your Security Key with NFC. Hold your registered eSecu FIDO2 Pro Security Key flat against the NFC sensor of your mobile device, a white indicator light on the key shall steady on. www.excelsecu.com...
-
Page 17: Sign In (Bluetooth + Iphone)
The authentication will complete in a while, and you will be authorized to login with your account. 4.5. Sign in (Bluetooth + iPhone) When using the eSecu FIDO2 Pro Security Key on an iPhone for the first time with Bluetooth connection, you need to pair them first. - Page 18 If the 2-step Verification of your Google account is turned on, then you will be asked to use your Security Key, and make sure the Google Smart Lock app is installed. Click on Install if it’s not installed. Then click on Already installed, and open it. Click on More options, select Pair another Bluetooth security key.
- Page 19 The indicator light of the key shall flash blue and the Google service will automatically verify your security key. When the eSecu FIDO2 Pro Security Key receives an authentication request, the indicator light changes to flashing white from flashing blue, short press the button on the key to confirm the authentication, then you will be back to Safari automatically with your Google account logged in.
-
Page 20: Sign In (Nfc Mode + Ios 13.3 And Above)
When you are asked to do the 2-Step Verification on a paired iPhone again, go through the Step 1~3 above, after you open the Smart Lock app, short press the button on the eSecu FIDO2 Pro Security Key to enter the Bluetooth mode, and the indicator light shall flash blue. When the key receives an authentication request, the indicator light changes to flashing white from flashing blue, short press the button again on the key to confirm the authentication, then you will be back to Safari automatically with your Google account logged in. - Page 21 Use security key. Hold your registered eSecu FIDO2 Pro Security Key near the top of your iPhone, a white indicator light on the key shall steady on. The authentication will complete in a while, and you will be authorized to login automatically.
-
Page 22: Usage Of Fido Manager And Otp
5. Usage of FIDO Manager and OTP The Software used to configure the FIDO and OTP (HOTP/TOTP) is described in document of “Excelsecu Manager User Manual”, you can refer to it for more details. 6. FAQ Question 1: I have two Gmail accounts, how many FIDO2 Pro Security Keys do I need to protect two gmail account. -
Page 23: Question 4: Why Does Github Say "This Browse Doesn't Support Security Key" On My Iphone
Answer: When a red indicator blinks every 5 seconds a time, the FIDO2 Pro Security Key is in low power state. Charging process starts automatically when FIDO2 Pro Security Key is plugged in the USB port of the PC. 7. Product Spec Product eSecu FIDO2 Pro Security Key (FD203) System Windows, macOS, Linux Browser Edge, Chrome, Firefox, Opera, Safari...
