Reynolds Building Systems Best Barns Meadowbrook-R Assembly Book page 20

Meadowbrook and Woodville 10'x 12' Barn kit
Qty.
2x4 & 2x6 Framing
4 Wall Plates
8 Truss - Bottom Cords
8 2x4 Boards Attached to Pallet
31 Wall Studs black ends
4 Wall Plates
4 Wall Plates
4 Wall Plates
1 Gable Studs & Framing
1 Gable Studs & Framing
4 Gable Studs & Framing
4 Gable Studs & Framing
9 Truss Ridge Blocks
6 Gable Nailing Blocks
4 2x6 Tie Plates for Sidewalls
2x3 Framing
4 Gable Overhangs
4 Gable Overhangs
2 Gable Blocks
Pre-built Components
14 Pre-built Truss Halves
2 32" x 72" Pre-built Barn Doors
2 18" x 29" Loft Door Frames
1 2x3 Door Header
Loft Floor & Roof Sheathing
2
42" x 80"
2
46" x 80"
2
48" x 48"
Miscellaneous Lumber
12 Wood Truss Ridge Gussets
20 Wood Bottom Truss Gussets
Size
120 "
116 1/4"
80 "
72 "
68 1/2"
65 1/2"
56 1/2"
36 "
35 3/4"
34 1/4"
21 1/2"
22 3/4"
15 3/4"
70 1/2"
47 "
42 1/4"
6 1/4"
67-1/2"
2
42" x 72"
2
46" x 72"
4
24" x 48"
8" x 24"
12" x 12"
Roof Shingles
Roof Material
by Owner
Roof 'drip' Edge
Qty.
Description
Whie Pine Trim
4 1x4 Gable Trim
4 1x4 Gable Trim
4 1x4 Corner Trim
4 1x4 Corner Trim
2 1x4 Door Trim
1 1x3 Top Door Trim
4 1x3 Lower Wall Trim
2 1x3 Loft Door Trim
1 1x3 Loft Door Trim
Exterior Siding & Soffit
3 48" x 77-1/4"
2 36" x 77-1/4"
2 16" x 77-1/4"
4 Siding for Roof Gables
4 Siding for Roof Gables
2 Siding For Door Header
4
8" x 48" Front Soffit Panels (Woodville model)
Hardware
3 lb. 10d Sinkers
3 lb. 8d Galv.
2 lb. 7d Sinkers
3 lb. 6d Common
1 lb. 6d Galv.
3 lb. Hanger Nails
4 4" Door Hinges
6 5" Door Hinges
22 1x4 Drive-on Plate
Miscellaneous
2 Center Truss Blocks w/gusset
7 bdl.
6 pcs.
Size
47 1/2"
43 "
75 3/4"
74 3/4"
72 "
72 "
62 "
29 1/4"
43 "
2
12" x 77-1/4"
4
48" x 75-3/4"
2
6" x 32-1/4"
48" x 48"
16" x 30"
6" x 32-3/4"
20 Truss Hangers
75 Hinge Screws
1 Door Hasp
2 4" Barrel Bolts
2 6" Barrel Bolts
12 2-1/2" Screws
36 1" Screws
24 1-5/8" Screws
3-1/2"x7-1/2"
