Upholstered twin bed and trundle grey linen
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Weight Limit: 400 Lb / 181 Kg For Daybed
225 Lb / 102 Kg For Trundle
K.W. - 2016/7/4
2014 Dorel Home Products All Rights Reserved
Upholstered Twin Bed and Trundle
Thank you for purchasing from DHP!
DO NOT RETURN TO THE STORE !
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/support-home
or call Toll-Free 1-800-267-1739
Date of Purchase
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
4099419
Jesse
Grey Linen
Lot Number
B34409941900 - 10125-M
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Jesse 4099419 and is the answer not in the manual?

Questions and answers

Related Manuals for DHP Jesse 4099419

Summary of Contents for DHP Jesse 4099419

  • Page 1 Upholstered Twin Bed and Trundle Grey Linen Weight Limit: 400 Lb / 181 Kg For Daybed Thank you for purchasing from DHP! 225 Lb / 102 Kg For Trundle DO NOT RETURN TO THE STORE ! If parts are missing or damaged, we will gladly ship your replacement parts free of charge.

  • Page 2: Warranty Information

    Warranty Information Read Before Beginning Assembly DHP warrants this product to be free from defects in material and workmanship and Call our toll free number if you need assistance. agrees to remedy any such defect. This warranty covers one year from the date of Work in a spacious area and near where the unit will be used, preferably on a original purchase.
  • Page 3 B34409941900...
  • Page 4 Parts Replacement Parts, Visit www.dhpfurniture.com/eng/support-home This item is packed in 2 boxes! All parts listed on this page are in Box A. If Box B is missing please contact your Retailer. There are inner box(es) that include components required to complete this assembly. Headboard Wooden Slat Footboard...
  • Page 5 Parts Replacement Parts, Visit www.dhpfurniture.com/eng/support-home This item is packed in 2 boxes! All parts listed on this page are in Box B. If Box A is missing please contact your Retailer. There are inner box(es) that include components required to complete this assembly. Front/Rear Rail Front/Rear Panel Front Panel...
  • Page 6 Hardware Pack: Daybed Hardware Pack #: T4099419A-00 1/4" X 3/4" 1/4" X1 3/16" X 12 X 16 1/4" X 1 9/16" X 12 5/16" X 1 3/4" Hardware Note: Please do not completely tighten all the hardware, until the entire assembly is complete, unless otherwise indicated in the step-by-step instructions.
  • Page 7 Hardware Pack: Trundle Hardware Pack #: T4099419B-00 1/4" 1/4" X 1 3/8" 1/4" X 1 9/16" X 12 Hardware Note: Please do not completely tighten all the hardware, until the entire assembly is complete, unless otherwise indicated in the step-by-step instructions.
  • Page 8 Step 1 The following instructions will illustrate how to assemble the Daybed from Step 1 to Step 6. Please use the Daybed Hardware Pack:T4099419A-00. 1.1 Attach (Z) to (A) and (B) with BOLTS 4; 1.2 Screw BOLTS 2 in (A) and (B). Do not completely tighten the bolts, leave half of the...
  • Page 9 Step 2 2.1 Attach (T) to (C) with BOLTS 1; 2.2 Attach (S) to (C) with BOLTS 1. Repeat the same procedure for the remaining parts (C), (S) and (T). Parts (S/T) should be orientated as illustrated. Please orient part (C) with these holes at the lower side before assembling .
  • Page 10 Step 3 Attach (E) to (C) with BOLTS 3. The narrow holes on brackets(T/S) Repeat the same procedure for the and slat holes on part (E) are facing remaining subassembly (C/S/T) and part (E). towards the same side as illustrated. X 12 B34409941900...
  • Page 11 Step 4 Hang (C) on (A and B) as illustrated, don't completely tighten the BOLT 2 until Step 5 is completed. B34409941900...
  • Page 12 Step 5 Slats holes must be on top side. Attach (F) to (A) and (B) with BOLT 2. Completely tighten all the bolts in this STEP. B34409941900...
  • Page 13 Step 6 6.1 Insert (O) into (X); 6.2 Press (X) into (E), repeat the same procedure for the opposite side. 6.3 Insert both ends of slats (O) into (Y), then press (Y) into (F) as illustrated. Repeat the same procedures going backwards for every row of slats.
  • Page 14 Step 7 Caster holes on (H) towards upward. Slat holes on part (I/J) towards floor as illustreated. The following instructions will illustrate how to assemble the Trundle from Step 7 to Step 11. Please use the Trundle Hardware Pack:T4099419B-00. 7.1 Lay (H) X2 on the floor with holes towards upward as illustrated.
  • Page 15 Step 8 8.1 Attach (J) X2 to (H) with BOLT 1 and NUT 3 using WRENCH 5. 8.2 Attach (I) to (H) with BOLT 1 and NUT 3 using WRENCH 5. B34409941900...
  • Page 16 Step 9 9.1 Attach (N) to (H) using WRENCH 6; 9.2 Attach (P) to (H) using WRENCH 6; B34409941900...
  • Page 17 Step 10 Turn over the subassembly obtained from STEP 9; Attach (G) x2 to (J) with BOLTS 2. X 12 B34409941900...
  • Page 18 Step 11 11.1 Insert (O) into (X); 11.2 Press (X) into (J), repeat the same procedure for the opposite side. 11.3 Insert both ends of slats (O) into (Y), then press (Y) into (I) as illustrated. Repeat the same procedures going backwards for every row of slats.

  • Page 19: Helpful Hints

    Move your new furniture carefully, with two people lifting and carrying the unit to its new location. Your DHP furniture can be disassembled and reassembled to move. Some parts have been pre-assembled for this item. They are illustrated on this page and available for replacement.
  • Page 20 Garant a Gracias por su compra DHP! DHP garantiza que este producto est libre de defectos de material y de fabricaci n, comprometi ndose a corregirlos en caso de ser hallados. Esta garant a es valida por Registra tu producto y participa para ganar! un a o a partir de la fecha de compra original.
  • Page 21 Lea antes de comenzar a ensamblar Partes Llame a nuestro numero gratuito si necesita asistencia. Piezas de reemplazo, visite www.dhpfurniture.com/spa/support-home Trabaje en un rea espaciosa y cerca de donde su producto ser utilizado, preferiblemente sobre una alfombra o utilice el cart n del empaque para proteger su piso y su producto.
  • Page 22 Cuelgue (S) Y (T) localizados en la parte (C) sobre los pernos pre-asamblados 2, Sus muebles DHP se pueden desmontar y volver a ensamblar en caso de como se ilustra. No ajuste completamente los pernos en este paso.

  • Page 23: Garantie

    S'IL VOUS PLA T LIRE ET CONSERVER POUR R F RENCE ULT RIEURE. Garantie Merci d'avoir achet un produit de DHP ! DHP garantit que ce produit est exempt de tout vice de mat riaux et de fabrication et Enregistrez votre produit et s'engage rem dier un tel d faut.

  • Page 24: Avant De Commencer L'assemblage

    Avant de commencer l'assemblage Pi ces Si vous avez besoin d'aide, appelez notre service la client le sans frais. Pi ces de rechange, visitez www.dhpfurniture/fre/support-home Travailler dans un endroit spacieux et pr s du lieu o l'unit sera utilis e, pr f rablement sur un tapis, ou sur un morceau de l'emballage pour prot ger le plancher et le produit.

  • Page 25: Conseils Utiles

    R p tez la m me proc dure et fort restant Assembl e SUV (C / S / T) et une partie Votre mobilier DHP peut tre d mont et reassembl pour faciliter les (E).
