PROPER USE GUIDELINES
Cumulative Trauma Disorders can result from the prolonged use of manually powered hand tools. Hand tools are intended for occasional
use and low volume applications. A wide selection of powered application equipment for extended-use, production operations is available.
CRIMP TOOLING
SDE-SA TOOL
2378005-1
INTRODUCTION
SDE-SA Commercial Hand Tool Assembly 2378005-1 for the FAKRA-HF straight plug and straight jack consist
of the tool and die set shown in Figure1. The tool consists of the SDE-SA Frame Assembly 9-1478240-0
(Instruction Sheet 408-8851) and the die assembly listed in Figure 1. This tool is used to crimp the terminal part
numbers provided in the table in Figure 1.
NOTE
Dimensions in this instruction sheet are in millimeters with [inches in brackets]. Figures and illustrations are for
reference only and are not drawn to scale.
Read these instructions thoroughly before crimping connectors.
© 2020 TE Connectivity Ltd. family of companies.
All Rights Reserved.
*Trademark
TE Connectivity, TE connectivity (logo), and TE (logo) are trademarks. Other logos, product, and/or company names may be trademarks of their respective owners.
SDE-SA Commercial Hand Tool
Assembly; PN 2378005-1 with
Die Assembly PN 2378005-2
TERMINAL P/N
DIE ASSY ONLY
2378005-2
Figure 1.
PRODUCT INFORMATION 1-800-522-6752
FERRULE P/N
2311484-3
2311486-3
2311485-3
This controlled document is subject to change.
For latest revision and Regional Customer Service,
visit our website at www.te.com.
Instruction Sheet
408-35125
Rev 1
27 OCT 20
CABLE TYPE
RTK 031
1 of 5
Advertisement
Table of Contents
Related Manuals for ete SDE-SA
Summary of Contents for ete SDE-SA
- Page 1 SDE-SA Commercial Hand Tool Assembly 2378005-1 for the FAKRA-HF straight plug and straight jack consist of the tool and die set shown in Figure1. The tool consists of the SDE-SA Frame Assembly 9-1478240-0 (Instruction Sheet 408-8851) and the die assembly listed in Figure 1. This tool is used to crimp the terminal part numbers provided in the table in Figure 1.
- Page 2 408-35125 DESCRIPTION The tool frame features two jaws, a handle, ratchet adjustment wheel, and an emergency ratchet release. The die set consist of a crimper (upper die) and an anvil (lower die). The tool frame holds a die assembly with one or more crimping chambers.
- Page 3 408-35125 Figure 2. 5. CRIMP HEIGHT INSPECTION Crimp height inspection is performed using a micrometer with a modified anvil, commonly referred to as a crimp-height comparator. TE Connectivity does not manufacture or market crimp height comparators. Detailed information on obtaining and using crimp-height comparators can be found in Instruction Sheet 408-7424. 1.
- Page 4 408-35125 6. RATCHET (CRIMP HEIGHT) ADJUSTMENT (Figure 5.) Although the ratchet is preset prior to shipment, it is important to verify the crimp height using a micrometer or caliper. General use and subsequent wear may cause the tool to go out of adjustment. It is recommended that crimp height be inspected, and the ratchet be adjusted, if necessary, on a regular basis.
- Page 5 408-35125 9. REVISION SUMMARY Revisions to this instruction sheet include: Initial release of this document. Rev 1 5 of 5...
