- Page 1 XENEON 32QHD165 PУССКИЙ ENGLISH ITALIANO 日本語 FRANÇAIS ESPAÑOL 한국어 DEUTSCH PORTUGUÊS 简体中文...
-
Page 2: Table Of Contents
ENGLISH TABLE OF CONTENTS Precautions Package Contents Assembly Tilt, Swivel and Height Adjustment Cable Management, Camera Mount (optional) & Other Mounting options Connectivity Operation Controls On-Screen Display (OSD) OSD – Picture Settings OSD – OSD Setting OSD – System Setting OSD –... - Page 3 PRECAUTIONS • Only use the accessories that are provided with the monitor or that which are recommended by the manufacturer. • Keep the plastic packaging bag for the product in a place that cannot be reached by children. • Before connecting the monitor to the power outlet, make sure that the voltage rating of the power cable is compatible with the power specification in the country where you are located.
- Page 4 XENEON 32QHD165 DISPLAY CONTENTS — XENEON 32QHD165 DISPLAY PANEL — AC POWER CABLE — MOUNTING POST — DISPLAYPORT CABLE (1.5M) — STAND — HDMI CABLE (1.5M) — MOUNTING SCREWS (X4) — USB-C CABLE (1.5M) — AC ADAPTER...
-
Page 5: Assembly
ASSEMBLY Before you begin, you will need a Phillips head screwdriver. 1. Remove top layer of foam (see image 1) that includes accessories and stand to expose rear of panel. 2. Carefully open up the foam bag covering the panel to expose the mounting area. Do not remove the panel from the bag 3. -
Page 6: Tilt, Swivel And Height Adjustment
TILT, SWIVEL AND HEIGHT ADJUSTMENT Your Xeneon display features a sturdy and stylish stand that offers Tilt, Swivel and Height Adjustment • Tilt -5/+20 degrees • Swivel ± 30 degrees • Height Adjust Range 110mm (497mm ~ 607mm) Tilt Swivel & Height Adjustment... -
Page 7: Cable Management, Camera Mount (Optional) & Other Mounting Options
CABLE MANAGEMENT, CAMERA MOUNT (OPTIONAL) & OTHER MOUNTING OPTIONS Your Xeneon display has built-in RapidRoute cable management to keep your desktop tidy. There are 4 adjustable cable clips that slide up and down the monitor post to allow for customizing your cable management needs. Open each cable clip by pressing the thumb clasp to the left and pulling out on the cable clip. - Page 8 The top of the Xeneon display post features a ¼" connector to allow for the addition of the Elgato Flex Arm and Camera Mounting Adapter Kit (sold separately) to attach a camera to the top of your Xeneon display. These accessories are available to be purchased directly from Corsair. • Xeneon Camera Adapter & Ball Mount Kit (CM-8900001) •...
- Page 9 WALL MOUNT COMPATIBILITY Before mounting your display with compatible wall mount (VESA 100mm x 100mm), make sure that: • You have removed the stand from the display with a Phillips screwdriver • The wall mount bracket that you purchased supports the weight of this display Review the instructions that came with your wall mount for more information about how to correctly mount your display.
-
Page 10: Connectivity
CORSAIR iCUE functionality and downstream USB 3.0 ports. E. USB-IN Port – Upstream USB input port. This port or the USB Type-C Port must be connected to a USB-capable port on your host device to support CORSAIR iCUE functionality and downstream USB 3.0 ports. -
Page 11: Operation
Note that many of these settings can also be controlled in CORSAIR iCUE software if you have the USB hub connected to your computer via USB IN port. Please install the latest version of iCUE (4.16 or later) available at https://www.corsair.com/us/en/icue. -
Page 12: Osd - Picture Settings
OPERATION OSD – Picture Settings The first menu, labeled “Picture”, contains the following settings for adjusting the overall picture quality. - Page 13 OPERATION OSD – Picture Settings Setting Options Description Selects a display preset factory calibrated for general use and Standard best power savings. Movie Selects a display preset optimized for watching movies. Text Selects a display preset optimized for reading text. Selects a display preset factory calibrated to the sRGB sRGB Picture Mode...
-
Page 14: Osd - Osd Setting
OPERATION OSD – OSD SETTING The second menu, labeled “OSD Setting”, contains the following settings for adjusting the on-screen display. Setting Options Description English French German Italian Spanish Language Japanese Selects the OSD’s language. Korean Portuguese Russian Chinese (Traditional) Transparency ON or OFF Sets the OSD to be transparent or opaque. -
Page 15: Osd - System Setting
OPERATION OSD – System Setting The third menu, labeled “System Setting”, contains the following settings for adjusting the display’s internal settings. - Page 16 OPERATION OSD – System Setting Setting Options Description Selects the display’s aspect ratio. “Auto” will try to match the Auto, 4:3, Aspect Ratio display’s aspect ratio to the incoming video signal. Not available 16:9 with Adaptive Sync enabled. Enables or disables the adaptive sync functionality when connected to a compatible GPU.
-
Page 17: Osd - Audio
OPERATION OSD – Audio The fourth menu, labeled “Audio”, lets you control the display’s audio. Setting Options Description Adjusts the volume of the audio output from the Volume 0-100 headphone jack. Selects which input the display passes audio Auto, HDMI-1, HDMI-2, Audio Input to the headphone jack from. -
Page 18: Osd - Input Select
OPERATION OSD – Input Select The fifth menu, labeled “Input Select”, lets you switch between the display’s different inputs. Setting Description HDMI-1 Switches to the device connected to the HDMI-1 port. HDMI-2 Switches to the device connected to the HDMI-2 port. DisplayPort Switches to the device connected to the “DP”... -
Page 19: Osd - Information
OPERATION OSD – Information Provides current settings status for key features. -
Page 20: Frequently Asked Questions / Troubleshooting
Adjust the brightness/gamma/contrast settings via the OSD. Image too light/dark Reset the monitor to factory settings. Check the video output settings of the source device. Video signal not supported Supported input resolutions for the CORSAIR XENEON 32QHD165 Gaming Monitor are located on page... - Page 21 Check your source device, a faulty graphics card or game console may require contacting the manufacturer for assistance. CORSAIR provides a "Zero Dead Pixel" policy for monitor products, if 1 or more bright pixels or 6 or more dark subpixels Monitor has a dead pixel are found, the monitor will be exchanged during the 3-year warranty period.
- Page 22 PC's USB 3.0 port is properly connected. Avoid connecting the monitor through a USB hub or extension if possible. We strongly recommend using the USB-C cable provided with the CORSAIR XENEON monitor for best results. What adaptive refresh rate options are...
-
Page 23: Technical Specifications
APPENDIX Technical Specifications Product Name XENEON 32QHD165 Part Number CM-9020001 Device 32QHD165 / RDD0013 USB Hub ID CORSAIR USB 3.0 Hub Panel Size 32" Diagonal Display Surface Non-Glare Pixels per inch 91.8 Aspect Ratio 16:9 Native Resolution 2560 x 1440 @ 165Hz... -
Page 24: Supported Display Modes
APPENDIX Technical Specifications Power Consumption (On) Power Consumption (Sleep) <0.5W Power Consumption (Off) <0.3W VESA Compatibility 100mm x 100mm Dimensions 732mm x 607mm x 316mm (W x H x D) Weight 9.5kg Stand Tilt -5° / +20° Stand Swivel -30° / +30° Stand Height Adjustment Range 110mm AC Adapter... -
Page 25: Default Picture Preset Values
APPENDIX Default Picture Preset Values Setting Standard Movie Game Text Creative sRGB Varies by Brightness Region* Contrast Sharpness Color Temp Normal Normal Normal Warm Normal sRGB Normal Gamma sRGB Saturation Low Blue Light Response Time Fast Fast Fast Normal Normal Normal Fast MPRT... - Page 26 YouTube: youtube.com/corsairhowto © 2021 CORSAIR MEMORY, Inc. All rights reserved. CORSAIR and the sails logo are registered trademarks of CORSAIR in the United States and/or other countries. All other trademarks are the property of their respective owners. Product may vary slightly from those pictured.
