Net-2000™ Voice Codec Unit
User's Manual
Cmd parameter
Packet Type Nack'ed
Type
Table 19. cmd parameter.
reason
The reason element is used to indicate the reason for the Nack. This value is currently always
0xFFFF (invalid packet). Other values are reserved for future expansion.
Cmd parameter
Packet Type Nack'ed
Packet Invalid
Table 19. reason parameter.
DVSI Confidential Proprietary
Section 4 – Net-2000™ VCU Interface Protocol
Byte 16
7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0
x x x x x x x x x x x x x x x x
Byte 16
7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Byte 77
Hex Value
0xXXXX
Byte 77
Hex Value
0xFFFF
Page 36
