  • Page 1 COMPACT BAR SET UP GUIDE Table of contents: - Part List - Set Up Guide - Compact Bar Covers...

  • Page 2: Before You Begin The Installation

    BEFORE YOU BEGIN THE INSTALLATION • Read all the instructions before installing. • Remove all packing materials before you start. • Remove all protection films from acrylic panels. • This installation requires basic mechanical skills. • Proper installation is the responsibility of the installer. •...

  • Page 3: Part List

    PART LIST Main Frame Acrylic Panel QTY: 1 QTY: 4 Ice Bin Cover QTY: 1 QTY: 1 See page 7 Counter Top Cutting Board QTY: 1 QTY: 1 Speed Rail Lock Pin QTY: 1 QTY: 5 Note: Parts are not to scale.
  • Page 4 COMPACT BAR ASSEMBLY SET UP STEPS Figure 3 STEP 1: Remove the pins . Unlock the spring latches at the bottom ( Figure 1 STEP 3: Place the side pins as shown below ( Remove pins Figure 4 STEP 2: Open the doors as shown below.
  • Page 5 COMPACT BAR ASSEMBLY SET UP STEPS STEP 6: Insert the pin STEP 4: Lift the shelf and place the pins as shown below. Figure 7 Figure 5 STEP 7: Place the counter top as shown below. Lock the counter top in place using the two spring latches...
  • Page 6 COMPACT BAR ASSEMBLY SET UP STEPS Side Panel STEP 1: Remove screws . Then remove STEP 8: Place the speed rail and the ice bin as shown below. the side frame as shown below. Figure 9 Figure 10 STEP 2: Slide out the side panel.
  • Page 7 COMPACT BAR ASSEMBLY SET UP STEPS Figure 11. Full Assembly. Notes to remember Do not move bar long distances fully stacked. Roll up levelers before moving bar. Do not roll bar over uneven surfaces. Two persons required to move bar.
  • Page 8 COMPACT BAR ASSEMBLY SET UP STEPS Main frame cover Speed rail cover Counter cover...
  • Page 9 Contact us Tel # 877-958-7901 Fax # 866-659-3353 E-mail: info@theportablebarcompany.com Visit us at www.theportablebarcompany.com COMPACT BAR SET UP GUIDE - 10/2020...
