Quick Links

LI ION
EMERGENCY RESPONSE GUIDE
MACK LRBE
PRODUCTION START : 2021
Version:
Identi ication number:
06/2021
800077265

Advertisement

loading
Need help?

Need help?

Do you have a question about the LRBE and is the answer not in the manual?

Questions and answers

Related Manuals for Mack LRBE

Summary of Contents for Mack LRBE

  • Page 1 LI ION EMERGENCY RESPONSE GUIDE MACK LRBE PRODUCTION START : 2021 Version: Identi ication number: 06/2021 800077265...

  • Page 2: Table Of Contents

    Contents 0. Rescue sheet Page 1 1. Identi ication/recognition Page 3 2. Immobilisation/stabilization/lifting Page 3 3. Disable direct hazards/safety regulations Page 4 4. Access to the occupants Page 6 5. Stored energy/liquid/gases/solid Page 7 6. In case of ire Page 8 Page 8 7. In case of water submersion 8. Towing/transportation/storage Page 9 9. Important additional information Page 10 10. Explanation of pictograms used Page 10 Identi ication number Version number 800077265 06/2021...
  • Page 3 MACK LRBE PRODUCTION START : 2021 2 lithium-ion batteries at 33 ton vehicle rear side of the cab 3 axles LI ION LI ION LI ION LI ION 2 lithium-ion batteries at 2 lithium-ion batteries at left-hand side of the chassis...
  • Page 4 MACK LRBE PRODUCTION START : 2021 2 lithium-ion batteries at rear side of the cab 33 ton vehicle LI ION 3 axles LI ION LI ION LI ION 2 lithium-ion batteries at 2 lithium-ion batteries at left-hand side of the chassis...
  • Page 5 1. Identi ication/recognition Vehicle Identication Number (VIN) 2. Immobilisation/stabilization/lifting Always approach the truck from the sides to stay out of the potential travel path. Due to lack of noise it can be difficult to determine if the truck is running. Chock the wheels. Apply the parking brake.

  • Page 6: Disable Direct Hazards/Safety Regulations

    3. Disable direct hazards/safety regulations Primary procedure STOP Check the instrument cluster for any of the symbols (1) and (2) appearing with a beep sound. If yes, a thermal runaway is detected in the lithium-ion batteries. START Turn off the ignition and remove the key. Turn off...

  • Page 7: Access To The Occupants

    If the charging plug cannot be pulled out : retract the pin manually Turn off the chassis switch (up) to intiate the high voltage disconnection process. Rotate the lever (1) and remove the charging plug (2). 4. Access to the occupants Opening doors from the outside Insert the key (1) in door lock and turn in anticlockwise direction to unlock the right-hand side door.
  • Page 8 Steering column adjustment Pull the telescopic steering adjust lever (1) to adjust the telescopic length of the cloumn. Pull the telescopic steering adjust lever (1) to adjust the telescopic length of the cloumn. Windows and wind screen Note The wind screen and rear glasses are made of laminated glass (1). Window glasses are made of tempered glass (2).

  • Page 9: Stored Energy/Liquid/Gases/Solid

    5. Stored energy/liquid/gases/solid 12 V 600 V High-voltage component location 1. Traction Battery: Four Li-ion battery packs supply a 6. Charging inlet, CCS 1 type : The CCS inlet is used for maximum of 738V at 110A. Battery electrodes are made of 600V DC charging.

  • Page 10: In Case Of Ire

    6. In case of ire Use a large sustained volume of water to extinguish lithium-ion battery related fire. If other materials are involved, use class ABC fire extinguisher. In case of thermal runaway, the lithium-ion batteries can release hydrogen fluoride. In case of traction battery fire, breather valves (1) may emit large flames as a result of thermal runaway.

  • Page 11: Towing/Transportation/Storage

    8. Towing/transportation/storage f the traction batteries are damaged, there is a risk of thermal or chemical reaction. Park the fully electric truck involved in an accident in a suitable place maintaining a safe distance from other vehicles, buildings and combustible objects. Risk of delayed fire can happen after the fire suppression or if the lithium-ion batteries are damaged.

  • Page 12: Important Additional Information

    9. Important additional information Do not cut any orange cables. Do not touch any high voltage cables and electric components. Do not perform any operation on a damaged truck without appropriate Personal Protective Equipment (PPE). 10. Explanation of pictograms used Use water to extinguish the fire Use ABC powder to extinguish the fire General warning sign Warning, Electricity Use thermal Infrared camera...
