- Page 1 SDOC-5011 Access Control Systems Intercom Integrated...
-
Page 2: Standards Approvals
All rights strictly reserved. No part of this document may be reproduced, copied, adapted, or transmitted in any form or by any means without written permission from Sicunet. Standards Approvals This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. - Page 3 E-mail: tech@sicunet.com Notice It is important that this instruction manual be read and understood completely before installation or operation is attempted. It is intended that the installation of this unit will be performed only by persons trained and qualified in the installation of access control equipment. The important safeguards and instructions in this manual cannot cover all possible conditions and situations which may occur during installation and use.
- Page 4 History Update Description 04-05-2019 initial version N E P T U N E P A G E 4...
- Page 5 1.0 INTRODUCTION ..........6 2.0 INTERCOM ............. 6 2.1 Http Event Setup 2.2 Call Button Setup 2.3 Controller Setting 3.0 NEPTUNE ............. 10 3.1 Event Action Setting N E P T U N E P A G E 5...
- Page 6 This manual contains Information regarding the basic Intercom Integrated configuration of the Neptune Access Control 2.0 Intercom Intercom products integrated with NEPTUNE are described based on the DS05M Model of “Beward”. * Refer to the figure below for the connection between NEPTUNE and Intercom.
- Page 7 2.1 Http Event Setup ❒ Enable Select whether to use Http Event to link with Neptune Server. Basically, it must be checked to use. ❒ Protocol Protocol for interworking with Neptune Server should be selected as HTTP by default. ❒ Hostname Enter the IP address and port of the Neptune Server.
- Page 8 It activates the event alarm to the Neptune Server when an Intercom Call Button Event occurs. ❒ Time 1 Select the time to use Event Alarm to the Neptune Server when a Call Button Event occurs in Intercom. Basically, to use continuously, set the time as the default. The default time is 00:00 –...
-
Page 9: Controller Setting
: method name ( Default fixed “call”) door : Neptune Server Door List No. * Example : m=call&door=15 2.3 Controller Setting Controller type information may differ for each product of “BEWARD”. The product described in this manual is based on the “NC102P” product. - Page 10 ❒ Duration Default Duration Used. 3.0 NEPTUNE 3.1 Event Action Setting ❒ Adding an Event Action Click New and enter a name and description. In the Basic Section, name the event, fill in a Description, and select a Schedule for the time the Event Action will be active.
- Page 11 ❒ Action Select “Door” for Action Source Type. Select the door to open when a door open trigger occurs in Intercom. NEPTUNE Dash Board Log of Intercom Trigger Event N E P T U N E P A G E 11...
