Rapsodo HITTING 2.0 Quick Start Manual page 2

5. calıbratıon
Connect the RCE to the
application and calibrate
the monitor. To calibrate
the monitor place a tee,
bat or person on the
center of home plate.
red line
The in the
azimuth view should go
down the
directly
middle
of home plate
!
Angles should be as close to
90 20
degrees and degrees
as possible
DISPLAYs
RED BLUE
Not ready Processing
data (wait for
green light
GREEN
to hit again)
Data ready,
monitor ready
GREEN AMBER
Successfully Charging
(switched off)
Connected to
RCE through
USB
RED GRAY
Not connected Off
to RCE, Waiting
for USB Sync
Battery Power Monitor
Connection to App
RCE and Monitor RCE and monitor connected
Connected to application, needs
Calibrated or on 'Pause Mode'
Ready to Data Processing
record data
RCE switched off Warning for low battery,
and charging please recharge monitor
RCE turned on, not RCE turned on, connected to
connected to app app but not the monitor
and monitor
MAINTENANCE
The monitor and RCE
must be charged
separately to ensure a
complete charge for
each device.
USB Cables Charger
Federal Communication
Commission (FCC)
Interference Statement
The FCC Interference
Statement can be found
on our website,
www.rapsodo.com/fcc
HITTING 2.0
QUICK START GUIDE
www.rapsodo.com
support@rapsodo.com
For additional user information download the
HITTING 2.0 user manual at
www.rapsodo.com/downloads
