Diablotek DHCV0303 Specifications

Model NO.: DHCV0303
UPC NO.: 843636002136
HDMI to ANALOG CONVERTER
Description:
(HDMI/DVI/SPDIF) TO (YPBPR/RL/SPDIF)
SPEC.: Inputs
Outputs
Display Selection
Vertical Frequency
Dimension
Power Adapter
Remote control
Feature:
•
•
•
•
•
•
•
•
•

Box Content:

•
•
HDMI
HDMIx1, SPDIFx1
HDMI x1, SPDIFx1, DVIx1, RCA x5
Push Button or remote control
50/60/75HZ.
10.3 x 4.5 x 1 in
Input :100-240V, Output : 12V
Infrared, discrete code
Input signal format: HDMI1.3 protocol compliant.
Output signal up support: Analog YUV 1080P, RL audio, SPDIF digital
audio.
Analog bandwidth 330M,
HDCP1.2 protocol compliant.
Deep color 36bit support.
SPDIF HIFI audio output from HDMI1.3 signal:
LPCM/Dolby-AC3/DTS7.1/DSD.
Support convert DVI to YUV
Manual or Remote, Switch input signal from 2HDMI/DVI to YUV.
LED indication
HDMI to Analog Converter
Remote Control
Power Adapter.
User's Manual
